AS4000
Wireless Local Loop System
Demand Assignment
Access Concentrator
Installation and Commissioning
605-0000-453
Issue 1.2dr Date 7/02/00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS4000 and is the answer not in the manual?

Questions and answers

Related Manuals for Airspan AS4000

Summary of Contents for Airspan AS4000

  • Page 1 AS4000 Wireless Local Loop System Demand Assignment Access Concentrator Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00...
  • Page 2 AS4000 Access Concentrator Preface Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Intentionally Blank Page 2 of 8...
  • Page 3 ACC provides a range of comprehensive training courses specifically aimed at providing operators/users of AS4000 products with the prerequisite skills to install, commission and or maintain the product. The courses can be tailored to provide the level of training required by the operator/user.
  • Page 4 AS4000 Access Concentrator Preface Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Intentionally Blank Page 4 of 8...
  • Page 5 AS4000 Access Concentrator Preface Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Safety Instructions - Warnings and Cautions SAFETY 1. Read and follow all warning notices and instructions marked on the product or included in this manual 2. Do not allow anything to rest on any power cord and do not locate the product where persons could step or walk on a power cord.
  • Page 6 Substances Hazardous to Health Regulations 1989’ , and the ‘ Dangerous Substances Regulations 1990’ ). At the end of any Airspan product’ s life cycle, the customer should consult with Airspan to ensure that the product is disposed of in conformance with the...
  • Page 7 AS4000 Access Concentrator Preface Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 User Response Form Mail: Airspan Communications Limited Fax: (44) 01895-467182 Cambridge House Oxford Road Uxbridge Middlesex UB8 1UN Document Rating Excellent Good Average Below Average Poor Accuracy / Completeness...
  • Page 8 AS4000 Access Concentrator Preface Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Intentionally Blank Page 8 of 8...
  • Page 9 August 2000 DLP-008 August 2000 DLP-009 August 2000 DLP-010 August 2000 DLP-011 August 2000 Appendix 1 April 2000 Appendix 2 April 2000 Appendix 3 April 2000 Appendix 4 April 2000 Page 1 of 2 © Copyright Airspan Communications Corporation 2000...
  • Page 10 AS4000 Access Concentrator ICL 001 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 CHANGE TYPE/DATE PURPOSE PAGES AFFECTED Draft Issue #, Month Year Page 2 of 2...

  • Page 11: Table Of Contents

    2.4. Cable Trays......................3 2.5. Delivery Inspection .....................3 2.6. Unpacking Inspection..................4 Rack Installation....................DLP-002 Positioning and Securing Racks ................1 1.1. Installing Rack in a Suite..................1 1.2. Securing Rack Base ....................2 Page 1 of 6 © Copyright Airspan Communications Corporation 2000...
  • Page 12 AS4000 Access Concentrator IXL 001 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 1.3. Securing the rack using overhead Ironwork............3 1.4. Securing a Rack to a Wall ...................4 Access Concentrator Rack Cabling..............DLP-003 DC Power .......................1 Rack Earthing ......................3 Alarm Unit (Type 55B) External Connections............3...
  • Page 13 AS4000 Access Concentrator IXL 001 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 1.1. Test Equipment Calibration.................1 Site Acceptance ....................DLP-011 Site Inspection ......................1 Site Acceptance Forms....................1 BNC Terminations to Coax ................Appendix 1 Procedure in case of card boot-up failure............Appendix 2 Procedure in case of card boot-up failure ................1...
  • Page 14 Figure 5. Securing Rack To Wall DLP-003 Figure 6. DC Termination on Combiner Shelf. Figure 7. Rack Earthing Figure 8. AS4000 Alarm Unit Connections Figure 9. Access Concentrator Interface Panel (1010 Board) Figure 10. Access Concentrator Interface Panel (1026 Board) DLP-004 Figure 11.
  • Page 15 AS4000 Access Concentrator IXL 001 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 List of Tables Table Page GSI-003 Table 1. Physical Characteristics. Table 2. Environmental Specifications. Table 3. Power Requirements. DLP-001 Table 4. Required Test Equipment. DLP-003 Table 5. DC Power Cables.
  • Page 16 AS4000 Access Concentrator IXL 001 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Abbreviations Alternating Current Automatic Gain Control Analogue Unit Analogue/Digital Customer Premises Equipment Customer Radio Unit Central Terminal Concentrated Tributary Unit (Access Terminal Shelves) Compression Unit Demand Assignment...
  • Page 17 AS4000 Access Concentrator IXL 001 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Related Documentation 605-0000-450 System Overview 605-0000-451 System Operations and Maintenance Manual 605-0000-452 Central Terminal - Installation & Commissioning 605-0000-433 Central Terminal - Antenna/Feeder Installation & Commissioning 605-0000-454 Subscriber Terminal - Installation &...
  • Page 18 AS4000 Access Concentrator IXL 001 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Intentionally Blank Page 8 of 6...

  • Page 19: Introduction

    The courses can be tailored to provide the level of training required by the operator/user. This manual is intended for use by persons familiar with the AS4000 product having attended the ACC Access Concentrator Installation and Commissioning training course prior to performing the procedures in this practice.
  • Page 20 AS4000 Access Concentrator GSI 001 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Intentionally Blank Page 2 of 2...

  • Page 21: Overview

    • Task 8 — Connection to management system. • Task 9 — Work Area Inspection and Cleaning • Task 10 — Acceptance Procedure Safety Personnel installing the ACC AS4000 System should follow ACC safety procedures W090 0001 001 Issue 01 April 96 2.1. Hazardous Voltages There are hazardous voltages present in the shelves of this equipment.

  • Page 22: Esd

    AS4000 Access Concentrator GSI 002 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 2.2. Electro-Static Discharge. Many circuits contain devices that are susceptible to damage from high impedance voltage sources. To avoid such risks always follow anti-static procedures. Page 2 of 2...

  • Page 23: Technical Specifications

    AS4000 Access Concentrator GSI 003 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 TECHNICAL SPECIFICATIONS Access Concentrator The following tables provide technical specifications for the AS4000 Access Concentrator. Physical Characteristics AC Rack Dimensions, (without brackets): Width 600mm Height 2175mm Depth...

  • Page 24: Table 3. Power Requirements

    AS4000 Access Concentrator GSI 003 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 POWER REQUIREMENTS DC Input Voltage Operating Range. (N.B. Maximum Range, -21.8V DC to This supply to be a guaranteed SELV from -60.aV DC @ 540W an EN60950 approved source.) DC Input Current (Fully populated AC 25 Amps max.

  • Page 25: Preparatory Tasks

    PREPARATORY TASKS Installation Tools and Equipment The following lists of tools and equipment are required to successfully install and test the AS4000 Access Concentrator Racks. 1.1. Required Tools • Combination Spanners: 8 mm, 13 mm, 17 mm, & 19 mm.

  • Page 26: Required Equipment

    AS4000 Access Concentrator DLP 001 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 1.2. Required Equipment Item Description Recommended Model Quantity Digital Multimeter Fluke 77 or similar Table 4. Required Test Equipment. Site Readiness Verify that the site is ready for the installation of the AC Rack.

  • Page 27: Site Earth

    AS4000 Access Concentrator DLP 001 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 2.2. Site Earth Confirm the position of the grounding point using the site survey. 2.3. Flooring Ensure that flooring is substantial enough to support the rack and can provide a secure fixing.

  • Page 28: Unpacking Inspection

    AS4000 Access Concentrator DLP 001 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 2.6. Unpacking Inspection The contents of each box must be checked against the relevant part lists provided with the box, for the correct part numbers and quantities, and for damage. Any shortage or...

  • Page 29: Rack Installation

    Either a proprietary system or fabricated steelwork will be required - see site survey. Manoeuvre the racks into position. Figure 2. Access Concentrator Rack. Page 1 of 4 © Copyright Airspan Communications Corporation 2000...

  • Page 30: Securing Rack Base

    AS4000 Access Concentrator DLP 002 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 1.2. Securing Rack Base Using the base of the rack as a template, mark the floor locating positions through the cut-outs in the Rack Frame. Using a 13mm diameter drill bit, drill four holes to a depth of approximately 25mm.

  • Page 31: Securing The Rack Using Overhead Ironwork

    AS4000 Access Concentrator DLP 002 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 1.3. Securing the rack using overhead Ironwork Assemble the overhead steelwork as required and secure the rack to the overhead structure using suitable fixings in compliance with local requirements. Remove all burrs and sharp edges.

  • Page 32: Securing A Rack To A Wall

    AS4000 Access Concentrator DLP 002 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 1.4. Securing a Rack to a Wall If the rack is to be positioned against a wall, attach the two right-angled wall brackets (these brackets are part on the packaging) to the top of the rack and finger tighten with the provided M12 screws.

  • Page 33: Access Concentrator Rack Cabling

    Note: Do not insert fuses until instructed to do so in the commissioning stage of installation. Run the DC cables through the top right hand side of the rack, into the fuse and alarm panel. Page 1 of 8 © Copyright Airspan Communications Corporation 2000...

  • Page 34: Figure 6. Dc Termination On Combiner Shelf

    AS4000 Access Concentrator DLP 003 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Remove clear plastic cover protecting the DC input terminals. Trim cables and strip 7mm. Crimp a spade terminal or terminal ring onto the wire and attach to terminals inside the Fuse and Alarm panel at the appropriate connection points.

  • Page 35: Rack Earthing

    AS4000 Access Concentrator DLP 003 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Rack Earthing Using the site survey, locate the building central [safety] grounding point. Run an earth cable rated at 30A to each rack and connect it to the centre earth stud located at the top or bottom (not both) of the rack.

  • Page 36: Access Concentrator Interface Panel

    Alarm Fuse Box 0V Return - 48V Figure 8. AS4000 Alarm Unit Connections The 10 way alarm ribbon from the AU55B should be connected to P7 on the alarm panel. Access Concentrator Interface Panel All cabling to the access concentrator connects to the interface panel. Slots 4,5 and 6 can be used for 75Ω...

  • Page 37: Figure 9. Access Concentrator Interface Panel (1010 Board)

    AS4000 Access Concentrator DLP 003 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 RS232 PORTS CARD SLOT 4 CARD SLOT 5 CARD SLOT 9 E1IN E1OUT E1IN E1OUT E1IN E1OUT CARD SLOT 4 CARD SLOT 7 E2IN E2OUT E2IN E2OUT...

  • Page 38: Mbit/S Cabling (Ct Link)

    AS4000 Access Concentrator DLP 003 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 CTU Slots 4- 6 XTU Slots 7-14 (Top) XTU Slots 7-14 (Bottom) Overall Overall Overall Screen Screen Screen SCR 8 OUT SCR 8 SCR 8 SCR 8 IN...

  • Page 39: Mbit/S Cabling (Switch Link)

    AS4000 Access Concentrator DLP 003 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 2Mbit/s Cabling (Switch Link) From the site survey, confirm the location of the Digital Distribution Frame (DDF) if a DDF is to be used or the Switch if the 2Mbit/s feeds are fed direct to the equipment.
  • Page 40 AS4000 Access Concentrator DLP 003 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Pair Designation Screen Screen Screen Screen Screen Screen Screen Screen Overall Screen Page 8 of 8...
  • Page 41 AS4000 Access Concentrator DLP 003 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Pair Designation Screen Screen Screen Screen Screen Screen Screen Screen Overall Screen Page 9 of 8...
  • Page 42 AS4000 Access Concentrator DLP 003 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Intentionally Blank Page 10 of 8...

  • Page 43: Card Installation

    SHELF PROTECTION Figure 12. Access Concentrator Rack Fuse and Alarm Panel Ensure that the end of suite fuses are adequately rated and insert these into the respective fuse holder positions. Page 1 of 4 © Copyright Airspan Communications Corporation 2000...
  • Page 44 AS4000 Access Concentrator DLP 004 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Card Insertion Insert the cards into the shelves, recording the serial numbers and revision status in the test form. See DLP007. The actual cards provided will depend upon the customer configuration.
  • Page 45 AS4000 Access Concentrator DLP 004 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Figure 14. Typical card set for V5.2 Page 3 of 4...
  • Page 46 AS4000 Access Concentrator DLP 004 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Intentionally Blank Page 4 of 4...

  • Page 47: General

    General The following procedures need to be carried out in order to verify the functionality and operation of all cards fitted into the Access Concentrator prior to placing the AS4000 system into service. If during testing, a fault occurs preventing the continuation of the test, the faulty module or card should be replaced and the test repeated for the card and all tests that are affected by the performance of that card.

  • Page 48: Psu Voltage Ac Shelves: (Test 2A)

    AS4000 Access Concentrator DLP 005 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 2.1. PSU Voltage AC Shelves: (Test 2a) Using the DMM, measure and record the DC voltage at the front panel test points on each of the PSU’ s on the AC Shelf.
  • Page 49 AS4000 Access Concentrator DLP 005 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Start AC Commissioning Rack Turn up and DC Measurements DLP-006 System Build on Sitespan DLP-007 Software Downloads DLP-008 Configure Access Concentrator DLP-009 End of AC Commissioning Page 3 of 4...
  • Page 50 AS4000 Access Concentrator DLP 005 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Intentionally Blank Page 4 of 4...

  • Page 51: Turn-Up And Dc Measurements

    The two breakers duplicate power to each shelf and the shelves will still function if one power supply fails though the LED indicators on the power supplies will not be on. Page 1 of 2 © Copyright Airspan Communications Corporation 2000...

  • Page 52: Psu Voltage Ac Shelves: (Test 2A)

    AS4000 Access Concentrator DLP 006 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Using the DMM check that the DC voltage supply across the input terminals (TB1(-); TB2+;.for Supply 1 and TB4(-); TB5(+) for supply 2). Ensure that the voltage measured complies with the site nominal voltage and is within the limits specified on the test results sheet.

  • Page 53: Setting Up System Using Sitespan

    4. From the client view, open ‘ template.ssd’ from the file menu 5. Highlight the ‘ object list, server’ and ‘ create server’ from the ‘ edit menu’ Page 1 of 14 © Copyright Airspan Communications Corporation 2000...
  • Page 54 AS4000 Access Concentrator DLP 007 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 6. If using the fixed network, select the name of the PC that Sitespan is running on. 7. Connect the server from the ‘ edit menu’ 8. To create the AC Site select the server from the object list and select Create Site from the ‘...
  • Page 55 AS4000 Access Concentrator DLP 007 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 9. From the Object List, Site click right mouse button and select Site Properties 10. Enter Site Details 11. Repeat Steps 8-10 for each of the CT sites.

  • Page 56: Setting Up Ct Rack And Shelf Configuration On Sitespan

    1. Highlight the site, click right mouse button and select ‘ Create Child Element’ 2. Select ‘ Airspan DA CT rack’ 3. Highlight the rack in Object List, and create ‘ Airspan DA CT modem shelf’ from the ‘ edit menu’...
  • Page 57 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 4. Select ‘ 1 (Top) ’ (to set up modem shelf 1) 5. Highlight shelf, and edit ‘ parent properties’ 6. Select ‘ Airspan DA CT Modem Shelf’ Page 5 of 14...

  • Page 58: Assign Central Terminal Card Slots

    RX sensitivity is set) Assign Central terminal Card Slots 3.1. DTU Card 1. Highlight shelf, click right mouse button, click ‘ element view’ , and select ‘ Airspan DA CT Modem Shelf’ Page 6 of 14...
  • Page 59 2. Highlight slot 5 for the DTU ( Slot 5 is the first slot available for assigning as a DTU) and click right mouse button select ‘ Create Aux’ from the ‘ edit menu’ 3. Select ‘ Airspan DA DTU’ 4. Display the shelf view and select the DTU card. Click right mouse button and select ‘...

  • Page 60: Setting Up Ac Rack And Shelf Configuration On Sitespan

    Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Setting up AC Rack and Shelf configuration on Sitespan 1. Highlight the site, click right mouse button and select ‘ Create Child Element’ 2. Select Airspan AC Rack Page 8 of 14...
  • Page 61 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 3. Highlight the rack in Object List, click right mouse button and select create ‘ Airspan DA AC shelf’ 4. Select the position for the AC shelf. 5. From the object list shelf click right mouse button and select Parent Properties...
  • Page 62 605-0000-453 Issue 1.2dr Date 7/02/00 6. Choose Airspan DA AC Shelf 7. Enter Shelf Name, Reference Clock Source to derive timing from the network. This is usually the first E1 on the first XTU card i.e slot 5 E1-1. The Com Port is the Sitespan PC port connected to the AC shelf.

  • Page 63: Assign Access Concentrator Card Slots

    AS4000 Access Concentrator DLP 007 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Assign Access Concentrator Card Slots 1. From Object List, Shelf select Access Concentrator, click right mouse button and select Element View 2. Position mouse over Aux card position to insert card, click right mouse button and select Create AUX 3.

  • Page 64: Configure Ac Cards

    1. With Shelf view displayed. Position mouse over the CAS Card( if CAS card installed) position to insert card, click right mouse button and select Airspan CAS Properties. Click left mouse button in the box alongside each E1 link provisioned to the Switch. Set the impedance of each link.

  • Page 65: Data

    1. With Shelf view displayed. Position mouse over the DATA Card (if DATA card installed) position to insert card, click right mouse button and select Airspan DATA Properties. Click left mouse button in the box alongside each E1 link provisioned to the Switch. Set the impedance of each link.

  • Page 66: V5.1

    1. With Shelf view displayed. Position mouse over the V5.1 Card (if V5.1 card installed) position to insert card, click right mouse button and select Airspan V5.1 Properties. Click left mouse button on each E1 linkTab provisioned to the Switch. Enable Channel, set the impedance of each link.

  • Page 67: Shelf Controller Software Downloads

    3. The following procedure must be followed on Sitespan to download the software to the SC card: Highlight shelf, click right mouse button and edit ‘ Parent Properties’ . 4. Select ‘ Software Downloads’ Page 1 of 4 © Copyright Airspan Communications Corporation 2000...
  • Page 68 AS4000 Access Concentrator DLP 008 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 5. ‘ Double click’ item of software to download. 6. Check that the version for download is the latest version, select ‘ download’ . 7. Repeat steps 5 and 6 for all the software files to be loaded. Download progress is shown on the main software download screen.
  • Page 69 LED only, follow the procedure in Appendix 3 14. Each card must be reset from Sitespan. Select card on shelf view ‘ double click’ the card, or click right mouse button and select Airspan (card type) View Page 3 of 4...
  • Page 70 AS4000 Access Concentrator DLP 008 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 15. Click Reset button to reset Page 4 of 4...
  • Page 71 6. The TU cards l display the following LED sequence: Note: The boot-up procedure for these cards takes approximately 15minutes. d) Red LED, amber LEDs & green surface mount LEDs all ON. Green LED FLASHING Page 1 of 6 © Copyright Airspan Communications Corporation 2000...
  • Page 72 AS4000 Access Concentrator DLP 009 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 e) Red LED ON, green LED FLASHING, amber LEDs OFF & green surface mount LEDs showing download progress. f) Green LED ON, green surface mount LEDs indicate card configuration as...

  • Page 73: Alarm And Status Indications (Test 3)

    AS4000 Access Concentrator DLP 009 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 STEP PROCEDURE Alarm and Status Indications (Test 3) 1. Verify that the alarms and status indications (LED’ s) on the system comply with those detailed in the following tables.

  • Page 74: Self Test (Test 4)

    AS4000 Access Concentrator DLP 009 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Position Colour Description Status TOP 1 FUSE FAIL: Illuminated if either input fuse has blown. Green OK Card is Active. I/P A FAIL input voltage A (BATTNEG0) not...
  • Page 75 AS4000 Access Concentrator DLP 009 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 17. Click Self Test button to reset. Check that each card passes 18. This concludes the setting up at the access concentrator. The CT site can now be commissioned STOP.
  • Page 76 AS4000 Access Concentrator DLP 009 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Intentionally Blank Page 6 of 6...
  • Page 77 Issue 1.2dr Date 7/02/00 COMMISSIONING TEST RESULTS Commissioning Test Results Please photocopy test results sheet for use with each system 1.1. Test Equipment Calibration Item Description Model Serial No Calibration Date Digital Multimeter Page 1 of 4 © Copyright Airspan Communications Corporation 2000...
  • Page 78 AS4000 Access Concentrator DLP 010 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 CUSTOMER:............. SITE LOCATION: ..........RACK ID: ............ENGINEER:............DATE:..............ACShelf 1 Card Type Serial Number Rev Level PSU 1 PSU 2 AUX 1 AUX 2 AUX 3...
  • Page 79 AS4000 Access Concentrator DLP 010 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Rack ID......PARA TASK / TEST LIMIT RESULT Site Inspection & Verification 2 Mbit/s AC Shelf 1 Cabling AC Shelf 2 System Commissioning Tests Test 1a Exchange DC Voltage -21.8 to -60.0V DC...
  • Page 80 AS4000 Access Concentrator DLP 010 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 Rack ID… ......PARA. TASK / TEST RESULT Test 4 AC Shelf 1 SC Card System Configuration AUX 1 Self test from Sitespan AUX 2 AUX 3...
  • Page 81 Check all work areas are free of debris i.e. cable off-cuts, braid, dust and packaging and that the site is as found. Site Acceptance Forms ACC and customer copies of site acceptance forms are provided on the following pages. Page 1 of 6 © Copyright Airspan Communications Corporation 2000...
  • Page 82 AS4000 Access Concentrator DLP 011 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This page left blank. Page 2 of 6...
  • Page 83 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 AS4000- ACCESS CONCENTRATOR ACCEPTANCE FORM CONTRACT OR CUSTOMER'S REF. NO:..............AS4000 COMMUNICATIONS CORPORATION LTD REF. NO:......SITE IDENTITY:......................The Customer accepts that the following equipment has been supplied, installed and tested............................................................
  • Page 84 AS4000 Access Concentrator DLP 011 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This page left blank. Page 4 of 6...
  • Page 85 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 AS4000- ACCESS CONCENTRATOR ACCEPTANCE FORM CONTRACT OR CUSTOMER'S REF. NO:..............AS4000 COMMUNICATIONS CORPORATION LTD REF. NO:......SITE IDENTITY:......................The Customer accepts that the following equipment has been supplied, installed and tested............................................................
  • Page 86 AS4000 Access Concentrator DLP 011 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Left Blank Page 6 of 6...
  • Page 87 Slide the sleeve along the cable, until it butts against the body sub- assembly. Crimp using VQ die. Crimp Here Page 1 of 2 © Copyright Airspan Communications Corporation 2000...
  • Page 88 AS4000 Access Concentrator Appendix Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Intentionally Blank Page 2 of 2...
  • Page 89 NOTE: Try swapping the SC cards between the AC and the CT shelf, because all the latest software should be installed on both cards. This way it is easy to tell if the SC card is faulty or not. Page 1 of 2 © Copyright Airspan Communications Corporation 2000...
  • Page 90 AS4000 Access Concentrator Appendix Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Intentionally Blank Page 2 of 2...
  • Page 91 Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 LAT SETTINGS LAT connected to SC The following pictures show the Terminal Settings used when connecting a LAT terminal to the Shelf Controller: Page 1 of 2 © Copyright Airspan Communications Corporation 2000...
  • Page 92 AS4000 Access Concentrator Appendix Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Intentionally Blank Page 2 of 2...
  • Page 93 3. Ensure that server34.olg & server34.svd files DO NOT exist on the root C: drive of your 4. If there is a server34.olg or server34.svd file in the directory then delete it/them. 5. Run the Sitespan V3.4 “trans” program Page 1 of 6 © Copyright Airspan Communications Corporation 2000...
  • Page 94 AS4000 Access Concentrator Appendix Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 6. Run the Sitespan Server for Sitespan V2.5 7. In the “Trans” program connect to the V2.5 Server by selecting “Create” and Select OK when asked to connect to the Remote Machine Name 8.
  • Page 95 AS4000 Access Concentrator Appendix Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 9. Disconnect the Source Server (V2.5). 10. Shut down the Sitespan V2.5 Server program 11. Start the Destination Server V3.4 Page 3 of 6...
  • Page 96 AS4000 Access Concentrator Appendix Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 12. Connect to the Destination Server 1. The destination server will indicate that it is connected and ready 2. Click on the Transfer button. This will start converting the V2.5 database to the new V3.4 format 3.
  • Page 97 AS4000 Access Concentrator Appendix Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 4. Close the V3.4 Server and exit the “trans” program. The files C:server34.olg & C:server34.svd should now be created on your PC. Your Database is now compatible with the new V3.4 Server & Client applications.
  • Page 98 AS4000 Access Concentrator Appendix Installation and Commissioning 605-0000-453 Issue 1.2dr Date 7/02/00 This Page Intentionally Blank Page 6 of 6...
