Setup
1. Performance Box Touch V1 has an internal patch antenna. This means that where the unit has a clear view of the
sky without any interference, an additional antenna is not required in most circumstances.
However, if it is required, you should mount the external GPS antenna (RLACS284) in the centre of the roof of the
vehicle, away from roof bars and other antennas. You can find more information about how to mount your external
antenna here.
2. If you are using an external antenna, connect it to the Performance Box Touch.
3. Connect the Battery (RLACS290) if required. You can find more information about the battery here.
4. Connect the Swivel Neck Richter Suction Mount (RLACS277) to the rear of the unit (or the battery if applicable)
and attach the suction mount to the vehicle's windscreen. You can find more information about the mounting of the
unit here.
5. Connect the power via the
and hold the Power button on the battery for a few seconds.
6. Insert the SD card into the
available space.
7. When the unit has booted, select the
https://en.racelogic.support//Product_Info/Performance_Meters/Performance_Box_Touch/Performance_Box_Touch_V1/
Power socket, or if you are using the battery independent of a power source, press
SD card slot. The SD Card Icon
Mode Button
Quick_Start_Guide_%E2%80%93_Performance_Box_Touch_V1/Quick_Start_Guide%3A_Lap_Timing_Mode_-
should display in green as long as the card has
and press LAP TIMING if it is not already selected.
