Racelogic LabSat RLLSP01 Manual

Hide thumbs

Advertisement

Table of Contents

10 - LabSat Replaying GPS Data

Note: Applicable to RLLSP01 and RLLSR01 LabSat Models.
Any LabSat unit can replay a recorded scenario file to any connected GNSS device capable of receiving the L1 GPS/
Galileo signal.
Note: LabSat is designed for direct connection to a GNSS receiver via a suitably screened cable. If testing is to
be performed on GNSS equipment without an external antenna connection, it is the responsibility of the user to
ensure that this is done in a fully RF screened environment.
Contact Racelogic for more information.
The LabSat is connected as illustrated in the diagram below:
1. Connect the high speed USB cable from the LabSat to the computer the Scenario data file will be replayed from.
2. Connect power to the LabSat, and the recipient GNSS device.
3. The LabSat comes supplied with a number of adaptor cables which allow connection to a number of GNSS
devices. Select the appropriate antenna cable for the device to be connected.
4. Connect the RF-OUT connector of the LabSat (illustrated below) to the GNSS antenna input of the device.
5. Start the LabSat software.
6. The LabSat is now ready to replay GNSS data to the DUT (Device under Test). Select the Replay Mode tab on
the LabSat. The LabSat is now ready to replay GNSS RF data.
https://racelogic.support//LabSat/LabSat__-_User_Manual/10_-_LabSat_Replaying_GPS_Data
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LabSat RLLSP01 and is the answer not in the manual?

Questions and answers

Related Manuals for Racelogic LabSat RLLSP01

Summary of Contents for Racelogic LabSat RLLSP01

  • Page 1 GNSS equipment without an external antenna connection, it is the responsibility of the user to ensure that this is done in a fully RF screened environment. Contact Racelogic for more information. The LabSat is connected as illustrated in the diagram below: 1.
  • Page 2 7. Once the GNSS device is powered and ready to receive data, press the Browse button to locate and select the scenario required for the test. The Info button will display a summary of the scenario. https://racelogic.support//LabSat/LabSat__-_User_Manual/10_-_LabSat_Replaying_GPS_Data...
  • Page 3 You can also specify a time delay between repeats, for example to allow time for a cold-start of the DUT before the scenario re-starts. In the example shown, four repeats have been selected, with a delay of 30 seconds between each repeat of the scenario replay. https://racelogic.support//LabSat/LabSat__-_User_Manual/10_-_LabSat_Replaying_GPS_Data...
  • Page 4 15. GPS Monitor displays the NMEA Output from the internal LabSat GPS Receiver during scenario replay. https://racelogic.support//LabSat/LabSat__-_User_Manual/10_-_LabSat_Replaying_GPS_Data...
  • Page 5 Video recording file. Wait for the file to load in the software and then click on the play button as normal. The LabSat scenario file will then play in synchronisation with the Video VBOX video. Please ensure that the GPS monitor is enabled and is showing the live data from the LabSat scenario. https://racelogic.support//LabSat/LabSat__-_User_Manual/10_-_LabSat_Replaying_GPS_Data...
  • Page 6 The video VBOX video shown in the software can be expanded by clicking on it to the full screen size of the computer screen. 17. Click Stop, to halt replay of GNSS RF data and the video replay. https://racelogic.support//LabSat/LabSat__-_User_Manual/10_-_LabSat_Replaying_GPS_Data...
