- Page 1 Treadmill Touchscreen Program Manual Before using this product, read this manual and follow all safety rules and operating instructions.
- Page 2 Operating Hours: 9.00h - 17.00h (CET) Telephone: (+852) 2575.6262 Fax: (+852) 2575.6894 Service Email: HongKongEnquiry@lifefitness.com Sales/Marketing Email: * Also check www.lifefitness.com for local representation or distributor/dealer Marketing.HK.Asia@lifefitness.com * Order online 24/7 at www.SCIFIT.com Operating Hours: 9.00h - 17.00h Service Operating Hours: 9.00h - 18.00h...
- Page 3 Operation Manuals and other Product Information available at http://www.scifit.com/resources/specifications-manuals/ عقوملا ىلع ةحاتم زاهجلا نع ىرخأ تامولعمو ليغشتلا ةلدأ http://www.scifit.com/resources/specifications-manuals/ 操作マニュアルおよびその他の製品情報については、 をご覧く ださい。 http://www.scifit.com/resources/specifications-manuals/ http://www.scifit.com/resources/specifications-manuals/ 如需操作手册和其他产品信息，请登录： 操作手冊和其他產品資訊請見 http://www.scifit.com/resources/specifications-manuals/ 작동 설명서 및 기타 제품 정보는 http://www.scifit.com/resources/specifications-manuals/ 에서 찾을 수 있습니다. http://www.scifit.com/resources/specifications-manuals/ Trobareu el manual de funcionament i altra informació de producte a Mae Llawlyfrau Gweithredu a Gwybodaeth Arall am Beiriannau ar gael yn http://www.scifit.com/resources/specifications-manuals/...
-
Page 4: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION MAINTENANCE CONSOLE OVERVIEW TACTILE KEY OVERVIEW PRODUCT PROGRAM MENUS AC5000 AC5000M DC1000 TOUCHSCREEN DATA ENTRY WORKOUT PROGRAMS uick tart (ac5000/Dc1000) anual Forward (AC5000M) (ac5000M O everSe eart raDe rOfile PeeD rOfile ADDITIONAL KEY FEATURES 10-11 SET-UP MODE ACCESS 12-15 HEART RATE TRANSMITTER... -
Page 5: Safety Information
• If warnings are missing or damaged, please contact SCIFIT immediately for replacement warning labels. Warning labels are shipped with every product and should be installed before product is used. SCIFIT is not responsible for missing or damaged warning labels. -
Page 6: Maintenance
SAFETY INFORMATION FCC Warning - Possible Radio / Television Interference This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 7: Tactile Key Overview
TACTILE KEY OVERVIEW ATTENTION The tactile keys on the membrane switch are fully functional and may be used for data entry, workout selection, etc., if so chosen. Use to select a workout program or activating a special feature. ENTER STOP Confirms the user’s Stops the workout value selection during... -
Page 8: Product Program Menus
PRODUCT PROGRAM MENUS AC5000 and DC1000 AC5000M Quick Start Quick Start More More Grade Speed Speed Heart Grade Heart Manual Forward Reverse Profile Rate Profile Profile Profile Rate TOUCHSCREEN DATA ENTRY Manual Time 05:32 Accept Back Delete Numerical keypad to directly enter user data information. Returns the screen to the previous category. -
Page 9: Workout Programs
WORKOUT PROGRAMS Quick Start (AC5000/AC5000M/DC1000) Allows the user to get on and go. The workout has no set time limit, speed and elevation levels are manually controlled and the timer will count upward. Quick Start Adjusting Speed and Elevation: Touch the word Menu to activate the screen pop-up menu. - Page 10 WORKOUT PROGRAMS Speed: Touch the Speed icon and a speed adjustment box will appear on the screen. Grade Pace Pause Speed Use the UP or DOWN arrows to adjust the speed of the treadmill. Pace: Touch the Pace icon and a speed adjustment box will appear on the screen. Grade Pace Pause...
-
Page 11: M Anual (Ac5000/Dc1000)
WORKOUT PROGRAMS Manual (AC5000/DC1000) Forward (AC5000M) Allows the user to set the workout time, speed, grade and user weight to begin the workout. During the workout speed and grade can be changed manually using the console or grade/speed buttons on the left/right handrails. Manual Forward Screen 1:... -
Page 12: Heart Rate
WORKOUT PROGRAMS Screen 1: Enter the time length of the workout. Screen 2: Enter the starting speed of the treadmill (Max. 4 mph (6.4 kph)). After entering and excepting the speed a caution message will appear showing the speed selected associated running pace. -
Page 13: Grade Profile
WORKOUT PROGRAMS Screen 4: Enter the user weight. Commence workout The grade (elevation) tactile buttons, touchscreen and handrail keys will adjust the grade during the workout, but if the user’s heart rate is at or above the target heart rate, grade (elevation) adjustment will not be allowed. The speed tactile buttons, touchscreen and handrail keys will adjust the speed during the workout, but if the user’s heart rate is at or above the target heart rate, speed adjustment will not be allowed. -
Page 14: Speed Profile
WORKOUT PROGRAMS Speed Profile (AC5000/AC5000M/DC1000) Provides seven different speed dependent profiles that may be selected. The speed will automatically adjust faster or slower as the workout progresses. Speed and grade can be adjusted manually during the workout. Speed Profile Screen 1: Enter the time length of the workout. - Page 15 ADDITIONAL KEY FEATURES Pop-up menu with additional features. Grade Pace Pause Speed Grade Pace Allows the user to change Allows the user to adjust the amount of time (in minutes) the grade (elevation) of the to complete 1 mile during the workout. Increasing the pace treadmill during the workout.
-
Page 16: Set-Up Mode Access
SET-UP MODE ACCESS Method 1: Touchscreen Access In Sequence: (1) Touch the upper left corner of the screen, (2) Then touch the left side of the “Quick Start” icon, (3) Finally touch the upper left corner of the screen again. Quick Start More Heart... - Page 17 SET-UP MODE ACCESS Overlay Treadmill Model AC5000 Language English Step 1: Category Selection Cancel Accept Overlay Treadmill Model AC5000 Step 2: Changing Parameters Language English NOTE: There will be times the screen will change to a data entry view to make adjustments. After making the adjustments touch the “Accept”...
- Page 18 SET-UP MODE ACCESS Treadmill Categories When the “Set-Up Mode” is accessed it will show categories for both rotary and treadmill. The following information will only list categories concerning the treadmill machines. Overlay: (Factory Set) Treadmill Indicates the type of key array selection for the membrane switch that is attached. Model: (Factory Set) AC5000, AC5000M, DC1000 Configures the type of machine the console has been mounted too.
-
Page 19: Heart Rate Transmitter
SET-UP MODE ACCESS Speed Control: Default: Continuous Allows the sensitivity of the speed buttons to be either: 1. Continuous - Speed increases as long as the button is pressed. 2. Incremental - Speed only increases with each press of the button. HEART RATE TRANSMITTER WARNING ATTENTION... -
Page 20: Information Screens
1. Website. 2. Touch the ‘Safety Advice” icon to display additional recommended safety information. Service Information: 1. Website. 2. Current console firmware installed. Version: TMX.XXT KX.X Prescribed for Progress Intelli-Fit Information: 1. Description summary of the console programs available (Machine dependent). -
Page 21: Warranty
Operation Manual (“Manual”). above limitations or exclusions may not apply to you. Warranty coverages and terms may differ outside the United States. Please contact the SCIFIT One type RJ45 interchangeable Network ready and Fitness office servicing your country (contact information found at the front of this Entertainment port is supplied with the Product. - Page 22 NOTES...
- Page 23 NOTES...
- Page 24 A6872A (10/2016)
