Dimensions

Base module/expansion module
a
[mm] a
XIOC-BP-XC –
XIOC-BP- 90
XC1
XIOC-BP-2 –
XIOC-BP-3 90
XIOC-BP- 90
EXT
Screw fixing of the modules on the mounting plate
16 mm 22.75 mm
(0.63") (0.89")
XIOC-BP-XC1 (XIOC-BP-3/EXT)
b c d
60 100 22
– 100 22
60 100 22
– 100 22
– 100 22
37.25 mm
(1.47")
b
[inch] a
XIOC-BP-XC –
XIOC-BP- 3.54
XC1
XIOC-BP-2 –
XIOC-BP-3 3.54
XIOC-BP- 3.54
EXT
16 mm 22.75 mm
(0.63") (0.89")
XIOC-BP-XC (XIOC-BP-2)
d
b c d
2.36 3.94 0.87
– 3.94 0.87
2.36 3.94 0.87
– 3.94 0.87
– 3.94 0.87
￫ M4
8.5 mm
(0.33")
4.5 mm
(0.18")
7/8
