- Page 1 XMCspan Installation and Use...
- Page 2 The information in this manual has been checked and is believed to be accurate and reliable. HOWEVER, NO RESPONSIBILITY IS ASSUMED BY EMERSON NETWORK POWER, EMBEDDED COMPUTING FOR ITS USE OR FOR ANY INACCURACIES. Specifications are subject to change without notice. EMERSON DOES NOT ASSUME ANY LIABILITY ARISING OUT OF USE OR OTHER APPLICATION OF ANY PRODUCT, CIRCUIT, OR PROGRAM DESCRIBED HEREIN.
-
Page 3: Table Of Contents
Contents Declaration of Conformity............6 Legal Notes.................7 Trademarks....................7 Notice......................7 Limited and Restricted Rights Legend............7 Contact Address...................7 About this Manual...............8 Abbreviations....................8 Conventions....................8 Summary of Changes..................9 Comments and Suggestions...............10 Safety Notes................11 EMC......................11 Operation....................12 Installation....................12 Environment....................12 Sicherheitshinweise..............13 EMV......................13 Betrieb......................14 Installation....................14 Umweltschutz....................15 Introduction................16 Features of the XMCspan................16 Standard Compliances................16 Ordering Information..................17 Hardware Preparation and Installation........19... - Page 4 Backplane Power Requirements............21 XMC/PMC Power Limitations............21 Checking the Box Contents.................21 Installing a Mezzanine Card................22 Installing the Primary XMCspan..............24 Installing a Secondary XMCspan..............26 Removing the XMCspan................28 Resetting the XMCspan.............29 Controls, LEDs, and Connectors..........30 Board Layout....................30 Face Plate....................30 Connectors....................32 VME Connectors................33 PCI Express Expansion Connectors...........34 Functional Description..............36 Block Diagram....................36 PEX8533 PCI Express Switch...............37...
- Page 5 Manufacturers' Documents.................43 Related Specifications.................44 6806800H03A | XMCspan Installation and Use |...
-
Page 6: Declaration Of Conformity
Declaration of Conformity | XMCspan Installation and Use | 6806800H03A... -
Page 7: Legal Notes
Legal Notes © Copyright 2008 Emerson Network Power, Embedded Computing, Inc. All rights reserved. TRADEMARKS Emerson is a trademark registered in the U.S. Patent and Trademark Office. All other product or service names are the property of their respective owners. NOTICE While reasonable efforts have been made to assure the accuracy of this document, Emerson assumes no lia- bility resulting from any omissions in this document, or from the use of the information obtained therein. -
Page 8: About This Manual
About this Manual This manual describes how to install the mezzanine cards supported by the XMCspan, and how to install the XMCspan on the VME base board. ABBREVIATIONS This document uses the following terms and abbreviations: Abbreviation Definition CPLD Complex Programmable Logic Device EEPROM Electrically Erasable Programmable Read-Only Memory IEEE... -
Page 9: Summary Of Changes
About this Manual Notation Description bold Used to emphasize a word Screen Used for on-screen output and code-related elements or commands in body text Courier + Bold Used to characterize user input and to separate it from sys- tem output Reference Used for references and for table and figure descriptions File >... -
Page 10: Comments And Suggestions
About this Manual COMMENTS AND SUGGESTIONS We welcome and appreciate your comments on our documentation. We want to know what you think about our manuals and how we can make them better. Mail comments to us by filling out the following online form: http://www.emersonnetworkpowerembeddedcomputing.com Contact Us Online Form... -
Page 11: Safety Notes
Safety Notes This section provides warnings that precede potentially dangerous procedures throughout this manual. In- structions contained in the warnings must be followed during all phases of operation, service, and repair of this equipment. You should also employ all other safety precautions necessary for the operation of the equipment in your operating environment. -
Page 12: Operation
Safety Notes OPERATION Product Damage High humidity and condensation on the board surface causes short circuits. Do not operate the board outside the specified environmental limits. Make sure the board is completely dry and there is no moisture on any surface before applying power. Damage of Circuits Electrostatic discharge and incorrect installation and removal can damage circuits or shorten their life. -
Page 13: Sicherheitshinweise
Sicherheitshinweise Dieses Kapitel enthält Hinweise, die potentiell gefährlichen Prozeduren innerhalb dieses Handbuchs vor- rangestellt sind. Beachten Sie unbedingt in allen Phasen des Betriebs, der Wartung und der Reparatur des Systems die Anweisungen, die diesen Hinweisen enthalten sind. Sie sollten außerdem alle anderen Vorsichts- maßnahmen treffen, die für den Betrieb des Produktes innerhalb Ihrer Betriebsumgebung notwendig sind. -
Page 14: Betrieb
Sicherheitshinweise verliert. Boardprodukte werden in einem repräsentativen System getestet, um zu zeigen, dass das Board den oben aufgeführten EMV-Richtlinien entspricht. Eine ordnungsgemässe Installation in einem System, welches die EMV-Richtlinien erfüllt, stellt sicher, dass das Produkt gemäss den EMV-Richtlinien betrieben wird. Verwenden Sie nur abgeschirmte Kabel zum Anschluss von Zusatzmodulen. -
Page 15: Umweltschutz
Sicherheitshinweise Beschädigung des Produktes und von Zusatzmodulen Fehlerhafte Installation von Zusatzmodulen, kann zur Beschädigung des Produktes und der Zusatzmodule führen. Lesen Sie daher vor der Installation von Zusatzmodulen die zugehörige Dokumentation. UMWELTSCHUTZ Entsorgen Sie alte Batterien und/oder Blades/Systemkomponenten/RTMs stets gemäß der in Ihrem Land gültigen Gesetzgebung, wenn möglich immer umweltfreundlich. -
Page 16: Introduction
Introduction This chapter gives an overview of the features of the XMCspan, lists the standard compliances, and details the ordering information for the board. FEATURES OF THE XMCSPAN The XMCspan is a carrier module that provides PCI Express expansion capability to the VME base board. The XMCspan has the following features: •... -
Page 17: Ordering Information
Introduction Standard Description IEC 60950-1 CAN/CSA C22.2 No. 60950-1 SN29500/8 Reliability requirements MIL-HDBK-217F IEC 68-2-1/2/3/13/14 Climatic environmental requirements The XMCspan can only be used in a restricted temperature range. IEC 68-2-6/27/32 Mechanical environmental requirements EN 50081-1 EMC requirements on system level EN 50082-2 FCC Part 15 Class B EN 300 386... - Page 18 Introduction Model Number Description XMCSPAN-001 XMC Expansion for MVME7100 with IEEE handles, 6E XMCSPAN-002 XMC Expansion for MVME7100 with SCANBE handles, 6E | XMCspan Installation and Use | 6806800H03A...
-
Page 19: Hardware Preparation And Installation
Hardware Preparation and Installation This chapter discusses the installation of a mezzanine card and XMCspan module. The following procedures are detailed: • Installing a Mezzanine Card on page 22 • Installing the Primary XMCspan on page 24 • Installing a Secondary XMCspan on page 26 •... -
Page 20: Power Requirements
Hardware Preparation and Installation Requirement Operating Non-Operating Forced Air Flow Relative Humidity 5% to 95% non-condensing at +40°C 5% to 95% non-condensing at +40°C (+104°F) (+104°F) Altitude -300m to 3,000m -300m to 13000m Vibration 0.1g from 5 to 100 Hz and back to 5 Hz at a 5-20 Hz at 0.01 g rate of 0.1 octave/minute 20-200 Hz at -3.0 dB/octave... -
Page 21: Backplane Power Requirements
Hardware Preparation and Installation Chassis Type Available Power Power with PMCs 3-Row 70 W maximum Below 70 W 5-Row 90 W maximum Below 90 W 1 Keep below power limit. Cooling limitations must be considered. Backplane Power Requirements The following table lists the backplane power requirements. Voltage Maximum Current Available Power... -
Page 22: Installing A Mezzanine Card
Hardware Preparation and Installation 1. Make sure that you have received the following items: printed Getting Started manual or Quick Start guide, XMCspan board, any optional items ordered. 2. Check the items for damages, and report any damage or difference to customer service. 3. - Page 23 Hardware Preparation and Installation 6. Slide the module port connector into the slot opening on the XMCspan front panel. 7. Align the module over the XMCspan. 8. Align the connectors on the underside of the module with the corresponding connectors on the XMCspan. Mezzanine Card Slot Connectors Mezzanine Card Slot 1...
-
Page 24: Installing The Primary Xmcspan
Hardware Preparation and Installation INSTALLING THE PRIMARY XMCSPAN The XMCspan mounts on the VME base board. To upgrade or install an XMCspan, refer to the figure shown below and proceed as follows. This procedure assumes that you have read the Installation and Use manual of the VME base board, and that you have properly configured the board according to the information found in the manual. - Page 25 Hardware Preparation and Installation Dangerous voltages, capable of causing death, are present in this equipment. Use extreme caution when handling, testing, and adjusting. Inserting or removing modules with power applied may result in damage to module components. Avoid touching areas of integrated circuitry as static discharge can damage these circuits.
-
Page 26: Installing A Secondary Xmcspan
Hardware Preparation and Installation INSTALLING A SECONDARY XMCSPAN The secondary XMCspan mounts on top of a primary XMCspan module. To install on your VME base board, do the following steps while referring to the figure shown below. | XMCspan Installation and Use | 6806800H03A... - Page 27 Hardware Preparation and Installation Dangerous voltages, capable of causing death, are present in this equipment. Use extreme caution when handling, testing, and adjusting. Inserting or removing modules with power applied may result in damage to module components. Avoid touching areas of integrated circuitry as static discharge can damage these circuits.
-
Page 28: Removing The Xmcspan
Hardware Preparation and Installation REMOVING THE XMCSPAN This procedure is applicable to the primary and secondary XMCspan. Dangerous voltages, capable of causing death, are present in this equipment. Use extreme caution when handling, testing, and adjusting. Inserting or removing modules with power applied may result in damage to module components. Avoid touching areas of integrated circuitry as static discharge can damage these circuits. -
Page 29: Resetting The Xmcspan
Resetting the XMCspan Reset Sources There are many ways to reset the XMCspan. The following sources will generate a board-level hardware reset for the whole XMCspan, including the PEX8533 and other devices connected to one of the PCI/PCI-X buses: • Power-up reset This reset occurs when the XMCspan is powered on. -
Page 30: Controls, Leds, And Connectors
Controls, LEDs, and Connectors This chapter summarizes the LEDs and connectors used in the XMCspan. BOARD LAYOUT The following figure shows the components, LEDS, and connectors on the XMCspan. FACE PLATE The following shows the face plate and the two variants of the handles for the XMCspan. | XMCspan Installation and Use | 6806800H03A... - Page 31 Controls, LEDs, and Connectors Figure 1: XMCspan with SCANBE Handles 6806800H03A | XMCspan Installation and Use |...
-
Page 32: Connectors
Controls, LEDs, and Connectors Figure 2: XMCspan with IEEE Handles CONNECTORS The XMCspan module connectors provide I/O and interfaces to the MVME7100 processor modules and to other XMCspan modules. The pin assignments for the XMCspan connectors are detailed in the succeeding sections. -
Page 33: Vme Connectors
Controls, LEDs, and Connectors Location Function J11 to J14, J21 to J24 PMC sites J15, J25 XMC sites Connection to MVME7100 PCI Express expansion connector located on the bottom side of the board Connection to secondary XMCspan PCI Express expansion connector located located on the top side of the board VME Connectors The VMEbus connector P1 is used for the XMCspan power supply. -
Page 34: Pci Express Expansion Connectors
Controls, LEDs, and Connectors Row Z Row A Row B Row C Row D PMC2IO_17 PMC1IO_22 PMC1IO_21 PMC2IO_16 PMC1IO_24 PMC1IO_23 PMC2IO_18 PMC2IO_20 PMC1IO_26 PMC1IO_25 PMC2IO_19 PMC1IO_28 PMC1IO_27 PMC2IO_21 PMC2IO_23 PMC1IO_30 PMC1IO_29 PMC2IO_22 PMC1IO_32 PMC1IO_31 PMC2IO_24 PMC2IO_26 PMC1IO_34 PMC1IO_33 PMC2IO_25 PMC1IO_36 PMC1IO_35 PMC2IO_27 PMC2IO_29... - Page 35 Controls, LEDs, and Connectors • Output connector J3 connects with a second XMCspan module. 6806800H03A | XMCspan Installation and Use |...
-
Page 36: Functional Description
Functional Description This chapter describes the physical structure of the XMCspan. It shows the detailed block diagram of the XM- Cspan and its primary interfaces. BLOCK DIAGRAM The following figure gives an overview of the main function blocks of the XMCspan and how they are intercon- nected. -
Page 37: Pex8533 Pci Express Switch
Functional Description PEX8533 PCI EXPRESS SWITCH The XMCspan provides an eight-lane (x8) PCI Express interface that expands the VME bus board. This PCI Express interface is available at connector J3, and connected to the uplink port Port 0 of the PCI Express Switch PEX8533. The PEX8533 gives PCI Express switching capability that conforms to the latest revision of the PCI Express Base specification. -
Page 38: Xmc.3 Support
Functional Description XMC.3 SUPPORT The XMCspan implements only the primary XMC.3 connector receptacles at locations J15 and J25. Each primary connector uses 16 differential pairs: 8 defined as transmit, and 8 defined as receive, plus one 100 MHz differ- ential pair for the PCI Express clock reference. A single four-lane PCI Express interface is connected between each connector and the PEX8533 PCI Express Switch. -
Page 39: I2C Bus Structure
Functional Description C BUS STRUCTURE The VME base board can access the I C bus devices through two singals on PCI Express expansion connector The following devices are connected to the I C bus: • Serial EEPROM for VPD • XMC modules VPD •... -
Page 40: Debugging Support
Functional Description The PCI/PCI-X bus clocks are generated by the Tsi384 internal clock generator. The clock generator uses REFCLK positive and negative inputs to generate the clock on PCI_CLK0 outputs. The clock frequency is determined by PCI_PCIXCAP, PCI_M66EN, and PCI_SEL100. The CPLD on the XMCspan automatically drives PCI_SEL100 high if a PCI-X module is plugged, but an assembly option is provided so that a 133 MHz bus can be selected. - Page 41 Functional Description Position Default Function SW1-7 Factory use only SW1-8 Factory use only 6806800H03A | XMCspan Installation and Use |...
-
Page 42: Contacting Technical Support
Contacting Technical Support Make sure you have the serial number of your product on hand before contacting technical support. The serial number is printed on a label that is attached to the back of the product. The serial number label is directly below the label stating where the product was assembled. -
Page 43: References
References EMERSON DOCUMENTS The Emerson Network Power - Embedded Computing publications listed below are referenced in this manual. You can obtain electronic copies of these publications by contacting your local Emerson sales office or by vis- iting our Web site at http://emersonnetworkpower.com/embeddedcomputing, and then doing the following: 1. - Page 44 References RELATED SPECIFICATIONS For additional information, refer to the following table for related specifications. Organization Document Title IEEE IEEE Standard for a Common Mezzanine Card (CMC) Family, IEEE 1386-2001 IEEE Standard Physical and Environmental Layers for PCI Mezzanine Cards (PMC), IEEE 1386.1-2001 VITA PCI Express Base Specification, PCI SIG Revision 2.0 PCI-X Addendum to the PCI Local Bus Specification, PCI SIG Revision 1.0a...
- Page 45 Index block diagram 36 layout board layout 30 board 30 box contents 21 bridge Tsi384 38 manuals 43 mezzanine cards supported 37 clocking scheme 39 modules compliances 16 installing 22 configuration PEX8533 37 connector pin-outs 32 ordering 17 debugging support 40 PCI buses 38 PCI Express Switch 37 PEX8533 37...
- Page 46 specifications 44 XMC.3 support 38 XMCspan resetting 29 stacking 26 Tsi384 38 | XMCspan Installation and Use | 6806800H03A...
- Page 47 Notes ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________...
- Page 48 ■ ■ ■ AC Power Systems Embedded Power Precision Cooling Emerson Network Power ■ ■ ■ Connectivity Integrated Cabinet Solutions Services The global leader in enabling ■ ■ ■ DC Power Systems Outside Plant Site Monitoring Business-Critical Continuity ™ ■ ■...
