Outdoor Thermocouple Piloted
Safety Ignition (TPSI) Fire Pits
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
NOTE: All TPSI models come shipped from the factory as Natural gas or Propane (LP)
gas. They must be order specifically as Natural gas or Propane models and cannot be
This system requires a minimum 18 square inches (per side) of cross ventilation.
Failure to provide proper ventilation will void the warranty.
Warning: For Outdoor Use Only
MODELS
Description
19" Rd Drop-In Pan with 16" Stainless Spur Burner
25" Rd Drop-In Pan with 22" Stainless Spur Burner
29" Rd Drop-In Pan with 22" Stainless Spur Burner
33" Rd Drop-In Pan with 31" Stainless Spur Burner
20" Sq Drop-In Pan with 16" Stainless Spur Burner
26" Sq Drop-In Pan with 22" Stainless Spur Burner
32" Sq Drop-In Pan with 31" Stainless Spur Burner
field converted from one gas to another.
INSTALLATION PRECAUTION:
PN#90261
DO NOT DISCARD. THIS MANUAL
HAS IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS.
LEAVE WITH THE HOMEOWNER.
MODEL:
SERIAL #:
#20-025
Propane Gas Models
FPB-19RBS16TPSI-P
FPB-25RBS22TPSI-P
FPB-29RBS22TPSI-P
FPB-33RBS31TPSI-P
FPB-20SBS16TPSI-P
FPB-26SBS22TPSI-P
FPB-32SBS31TPSI-P
Advertisement
Table of Contents
Related Manuals for Firegear FPB-19RBS16TPSI-N
Summary of Contents for Firegear FPB-19RBS16TPSI-N
- Page 1 MODEL: SERIAL #: #20-025 MODELS Natural Gas Models Description Propane Gas Models FPB-19RBS16TPSI-N 19” Rd Drop-In Pan with 16” Stainless Spur Burner FPB-19RBS16TPSI-P FPB-25RBS22TPSI-N 25” Rd Drop-In Pan with 22” Stainless Spur Burner FPB-25RBS22TPSI-P FPB-29RBS22TPSI-N 29” Rd Drop-In Pan with 22” Stainless Spur Burner...
- Page 2 CARBON MONOXIDE HAZARD DANGER This appliance can produce carbon monoxide which has no odor. Using it in an enclosed area can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. DANGER WARNING FIRE OR EXPLOSION HAZARD...
-
Page 3: Table Of Contents
CALIFORNIA PROPOSITION 65 WARNING This product is designed to operate with one of the following fuel sources: Liquid Propane or Natural Gas. The fuel used to operate this product, and the products of combustion of such fuel, can expose you to chemicals including Benzene which is known to the State of California to cause cancer, birth defects and other reproductive harm and Carbon Monoxide which is known to the State of California to cause birth defects or other reproductive harm. -
Page 4: Specifications
Natural Gas (NG) Propane Gas (LP) Inside Ground Side Min/Max Combustible Combustible Depth Level Wall Ceiling Floor Install Opening FPB-19RBS16TPSI-N FPB-19RBS16TPSI-P 2 ¾” 19 ¼” - 20” 19” 8” 36” 96” 18” FPB-25RBS22TPSI-N FPB-25RBS22TPSI-P 2 ¾” 25 ¼”- 26” 25”... -
Page 5: Gas Pipe Sizing Chart
REFERENCE GAS PIPE SIZING CHART GAS PIPE SIZING NATURAL GAS : PIPE SIZING CHART Length of Pipe in Feet 1/2” 3/4” 1” 1 - 1/4” 1 - 1/2” 2” 2 - 2 1/2” 3” 4” • Natural Gas (NG) flow is given in 1237 2259 3640... -
Page 6: Preparation For Non-Combustible Structure
This appliance must be isolated from the gas supply piping system by closing its manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½” psig (3.5kPa) Examples of Cross Ventilation 2- Firegear 6 x12 vents (Part #VENT-KIT-6x12) HIGH ELEVATION INSTALLATION... -
Page 7: Installation Into An Approved Enclosure
13. Ensure proper water drainage is also incorporated into the fire pit enclosure. NOTICE Firegear Outdoors fire pits are constructed and tested to follow the rigid ANSI standards for gas appliances and manufactured safely providing dependable and certified products. If these fire pits are not installed according to the installation manual (i.e. -
Page 8: Removing Parts From Carton
REMOVING PARTS FROM CARTON Valve Assembly Flexible Gas Line Thermocouple Lead Piezo Wires Pilot Tubing Control Panel Hardware Carton Contents Fig. 4 Removing contents from carton. This fire pit is comes partially assembled from the factory. The pilot tubing and thermocouple leads are 48” in total length, therefore, when mounting the Gas Valve/Piezo Burner Pan mounting plate, ensure the mounting plate is close enough... -
Page 9: Control Panel, Pilot Assembly & Media Installation
Thermocouple PIEZO48WH Connection PIEZO25WH Pilot Gas Remove red button cap and install battery into Piezo ignitor module. Line Outlet To Burner Inlet Gas Mounting Plate Supply Plastic Nut Red Button Cap Piezo Ignition Control Knob Fig. 8 Installing battery into Piezo. Fig. - Page 10 Non-Combustible Enclosure Spur Burner Burner Pan Pilot Tube Piezo Wires Gas Valve Thermocouple Gas Supply Piezo Shut-O Gas valve and flexible gas lines are supplied; E-Stop shut-off is not supplied, but available in accessories page. Flex lines with flared fittings do not require Teflon tape or pipe compound. Ensure not to “kink” the flex lines to allow better gas flow of gas.
-
Page 11: Operation
OPERATION CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance. WARNING: Do not use this appliance if any part has been under water. -
Page 12: Replacement Parts
FPB ROUND AND SQUARE TPSI REPLACEMENT PARTS Drawings Not to Scale Burning Spur Round and Square Fire Pits with TPSI System REV. A Page 12... -
Page 13: Replacement Parts List
FPB ROUND AND SQUARE TPSI REPLACEMENT PARTS Qty. Description Item Part Number 19-inch Round Stainless Pan PAN-SS19R 25-inch Round Stainless Pan PAN-SS25R 29-inch Round Stainless Pan PAN-GV29RP2 33-inch Round Stainless Pan PAN-GV33RP2 20-inch Square Stainless Pan PAN-SS20S 26-inch Square Stainless Pan PAN-SS26S 32-inch Square Stainless Pan PAN-SS32S... -
Page 14: Maintenance/ Trouble Shooting
FIRE PIT MAINTENANCE 1. The fire pit should be inspected and cleaned before initial use at least annually by a qualified field service person. 2. Any component that is found faulty must be replaced with an approved component. 3. Any tampering or modifying with the fire pit is dangerous and voids all warranties. 4. -
Page 15: Optional Accessories
TPSI-LPK41 - 75,000 Btu models Model: PAVER-CP-TPSI TPSI-LPK47 - 50,000 Btu models - Kits include main burner orifice and PSE-SUB163 pilot orifice. NOTE: See the Firegear Outdoors catalogue for other accessories also available. FOR TECHNICAL SERVICE, CALL: (800) 966-8126 Firegear Outdoors 17322 Gothard St. - Page 16 Expande Thermocouple Manua Fire Pi Spur Burner Optional Cutout Template for TMS Face Plate Male Threads: Requires Compound or Tape Note: Use joint compound or Te on tape resistant to all gasses on all male NPT threads; not ared ttings. Ensure all connections are tight and check for gas leaks before and after assembly is complete.
- Page 17 FIREGEAR LIMITED WARRANTY - 2022 ed View of Firegear Outdoors hereby warrants to the end user that products will be free from material and workmanship al (TMS) Safety Fire Pit defects that prevent safe and correct operation of the product. The warranty commences from date of sale to the end user for the following period: CONSUMER RESIDENTIAL APPLICATIONS –...
- Page 18 COMMERCIAL APPLICATIONS – MANUFACTURED AFTER 12/02/2019 BURNER SYSTEMS, BURNERS, COMPONENTS AND ACCESSORIES • TWO (2) YEAR WARRANTY ON CONSTRUCTION AND MANUFACTURER DEFECTS • TWO (2) YEAR WARRANTY - STAINLESS STEEL BURNERS AND PANS • TWO (2) YEAR WARRANTY - BRASS BURNERS •...
- Page 19 Product to be returned should; be packed so as not to incur damages during transportation. Firegear is not responsible for damages on returned items. RMA is valid for thirty (30) days from the date issued. The RMA must be clearly marked on the outside of the package.
- Page 20 We do not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or replacement of its equipment, and or such representation are binding. Firegear Outdoors 17322 Gothard St.
- Page 21 NOTES: REV. A Page 21 Burning Spur Round and Square Fire Pits with TPSI System...
- Page 22 Having problems getting the fire pit to operate? Don’t leave the job site! We want to help! Call 800.966.8126 for Technical Support between the hours of 8:00AM to 5:00PM PST. BEFORE YOU CALL WE WILL NEED THIS INFORMATION Model Number: ___________________________ Serial Number: ___________________________ How long is the gas line run? Nat Gas ____ LP Gas ____ What size is gas line? _____...
