KALEA BAY FIREPLACE
SEE-THROUGH CONVERSION KITS
Kits: 73230 (36" Fireplace)
74230 (48" Fireplace)
75230 (60" Fireplace)
76230 (72" Fireplace)
Installation Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS PRODUCT
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
Advertisement
Table of Contents
Related Manuals for Firegear 73230
Summary of Contents for Firegear 73230
- Page 1 KALEA BAY FIREPLACE SEE-THROUGH CONVERSION KITS Kits: 73230 (36” Fireplace) 74230 (48” Fireplace) 75230 (60” Fireplace) 76230 (72” Fireplace) Installation Instructions IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO NOT ATTEMPT TO INSTALL OR OPERATE THIS PRODUCT PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE...
- Page 2 Fig. 1. Note: In some applications not all screws will be used. OFP-36LECO-N OFP-48LECO-N OFP-60LECO-N OFP-72LECO-N Kit Model # 73230 Kit Model # 74230 Kit Model # 75230 Kit Model # 76230 (1) KB-36-73120 Glass...
- Page 3 Step 1: REMOVING BACK REAR PANEL Look at the back side of the fireplace. Around the outer perimeter area of the back wall are several 1/4” hex head screws that must be removed (See the shaded area in Fig. 2). Only remove the top and bottom screws on the rear panel. The nailing flange will remain in place.
- Page 4 Step 2: INSTALLING HOOD The fireplace requires a hood to be installed into each side of the firebox. One hood would have come with the single sided fireplace, the other hood is supplied with this kit. All models require five (5) screws (#77129) to secure the hood to the fireplace except the 72-inch model, which uses seven (7) screws to secure the hood.
- Page 5 Bottom Tab Fig. 5 Installing windshield into clips (glass holders). Refer to original Kalea Bay manual for any additional questions. FOR TECHNICAL SERVICE, CALL: (855) 498-8324 Firegear Outdoors 9230 Conservation Way Fort Wayne, IN 46809 (260) 459-1703 Sales Support: (888) 699-6167 WEB SITE: www.firegearoutdoors.com...
