Natural Gas
FPB-19RBSTMSI-N
FPB-25RBSTMSI-N
FPB-29RBSTMSI-N
FPB-33RBSTMSI-N
FPB-16SBSTMSI-N
FPB-20SBSTMSI-N
FPB-26SBSTMSI-N
FPB-32SBSTMSI-N
FPB-38SBSTMSI-N
Outdoor Thermocouple Manual Safety
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
This system requires a minimum 18 square inches (per side) of cross ventilation.
Failure to provide proper ventilation will void the warranty.
Warning: For Outdoor Use Only
MODELS
Description
19" Round Stainless Pan & Spur Kit
25" Round Stainless Pan & Spur Kit
29" Round Stainless Pan & Spur Kit
33" Round Stainless Pan & Spur Kit
16" Square Stainless Pan & Spur Kit
20" Square Stainless Pan & Spur Kit
26" Square Stainless Pan & Spur Kit
32" Square Stainless Pan & Spur Kit
38" Square Stainless Pan & Spur Kit
(TMSI) Fire Pits
INSTALLATION PRECAUTION:
PN#90003
DO NOT DISCARD. THIS MANUAL
HAS IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS.
LEAVE WITH THE HOMEOWNER.
MODEL:
SERIAL #:
#20-025
Propane
FPB-19RBSTMSI-P
FPB-25RBSTMSI-P
FPB-29RBSTMSI-P
FPB-33RBSTMSI-P
FPB-16SBSTMSI-P
FPB-20SBSTMSI-P
FPB-26SBSTMSI-P
FPB-32SBSTMSI-P
FPB-38SBSTMSI-P
REV. B
Page 1
Advertisement
Related Manuals for Firegear FPB-16SBSTMSI-N
Summary of Contents for Firegear FPB-16SBSTMSI-N
- Page 1 25” Round Stainless Pan & Spur Kit FPB-29RBSTMSI-N FPB-29RBSTMSI-P 29” Round Stainless Pan & Spur Kit FPB-33RBSTMSI-N FPB-33RBSTMSI-P 33” Round Stainless Pan & Spur Kit FPB-16SBSTMSI-N FPB-16SBSTMSI-P 16” Square Stainless Pan & Spur Kit FPB-20SBSTMSI-N FPB-20SBSTMSI-P 20” Square Stainless Pan & Spur Kit FPB-26SBSTMSI-N FPB-26SBSTMSI-P 26”...
- Page 2 CARBON MONOXIDE HAZARD DANGER This appliance can produce carbon monoxide which has no odor. Using it in an enclosed area can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. DANGER WARNING FIRE OR EXPLOSION HAZARD...
-
Page 3: Table Of Contents
CALIFORNIA PROPOSITION 65 WARNING This product is designed to operate with one of the following fuel sources: Liquid Propane or Natural Gas. The fuel used to operate this product, and the products of combustion of such fuel, can expose you to chemicals including Benzene which is known to the State of California to cause cancer, birth defects and other reproductive harm and Carbon Monoxide which is known to the State of California to cause birth defects or other reproductive harm. - Page 4 29” 8” 19” 69” 18” FPB-33RBSTMSI-N FPB-33RBSTMSI-P 2 ¾” 34 ¼ - 35” 33” 8” 19” 69” 18” FPB-16SBSTMSI-N FPB-16SBSTMSI-P 2 ¾” 16 ¼” - 17” 16” 8” 19” 54” 18” FPB-20SBSTMSI-N FPB-20SBSTMSI-P 2 ¾” 20 ¼”- 21” 20” 8”...
- Page 5 REFERENCE GAS PIPE SIZING CHART GAS PIPE SIZING NATURAL GAS : PIPE SIZING CHART Length of Pipe in Feet 1/2” 3/4” 1” 1 - 1/4” 1 - 1/2” 2” 2 - 2 1/2” 3” 4” • Natural Gas (NG) flow is given in 1237 2259 3640...
-
Page 6: Hard Piping To Fire Pit
This appliance must be isolated from the gas supply piping system by closing its manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½” psig (3.5kPa) Examples of Cross Ventilation 2- Firegear 6 x12 vents (Part #VENT-KIT-6x12) Fire Pit... - Page 7 INSTALLATION OF FIRE PIT INTO AN APPROVED ENCLOSURE REQUIREMENTS Only non-combustible materials should come in direct contact with any part of the fire pit. If the area underneath should is a flat level combustible surface according to the clearances specified in this manual on page 4. 2.
- Page 8 Piezo Ground Tab Illustration shows side view of valve and Piezo ignitor. PIEZO48WH PIEZO23WH Bottom of Burner Pan PIEZO48WH Illustration above shows ground tab Thermocouple connection underneath the burner pan. Lead Remove red button cap and install battery into Piezo ignitor module.
- Page 9 Non-Combustible Enclosure Spur Burner Burner Pan Gas Valve TC Wire Gas Supply Piezo Shut-O Gas valve and flexible gas lines are supplied; E-Stop shut-off is not supplied, but available in accessories page. Flex lines with flared fittings do not require Teflon tape or pipe compound. Ensure not to “kink” the flex lines to allow better gas flow of gas.
-
Page 10: Operation
OPERATION CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance. WARNING: Do not use this appliance if any part has been under water. -
Page 11: Replacement Parts
FPB ROUND AND SQUARE TMSI REPLACEMENT PARTS Drawings Not to Scale TMSI Burning Spur Fire Pits REV. B Page 11... - Page 12 FPB ROUND AND SQUARE TMSI REPLACEMENT PARTS Qty. Description Item Part Number 19-inch Round Stainless Pan PAN-SS19R 25-inch Round Stainless Pan PAN-SS25R 29-inch Round Stainless Pan PAN-GV29RP2 33-inch Round Stainless Pan PAN-GV33RP2 16-inch Square Stainless Pan PAN-SS16S 20-inch Square Stainless Pan PAN-SS20S 26-inch Square Stainless Pan PAN-SS26S...
-
Page 13: Maintenance/ Trouble Shooting
FIRE PIT MAINTENANCE 1. The fire pit should be inspected and cleaned before initial use at least annually by a qualified field service person. 2. Any component that is found faulty must be replaced with an approved component. 3. Any tampering or modifying with the fire pit is dangerous and voids all warranties. 4. -
Page 14: Optional Accessories
L-Sedona (Sedona) 19pc (200lbs) Model: ESTOP2-5H 2.5hr. timer Model: PAVER-VENT-4-LNTS Driftwood Twigs 326-930 6pc (20lbs) Model: PAVER-VENT-6-LNTS NOTE: See the Firegear Outdoors catalogue for other accessories also available. FOR TECHNICAL SERVICE, CALL: (800) 966-8126 Firegear Outdoors 17322 Gothard St Huntington Beach, CA 92647 Web Site: www.firegearoutdoors.com... - Page 15 TMSI Burning Spur Fire Pits REV. B Page 15...
- Page 16 Expande Thermocouple Manua Fire Pi Spur Burner Male Threads: Requires Compound or Tape Note: Use joint compound or Te on tape resistant to all gasses on all male NPT threads; not ared ttings. Optional Cutout Template for Ensure all connections are tight and check for gas leaks before and after TMS Face Plate assembly is complete.
- Page 17 ed View of Expanded View of al (TMS) Safety Fire Pit Thermocouple Manual (TMS) Safety Fire Pit it Pan Fire Pit Pan Spur Burner / ” Washer / ” Washer Male Threads: Requires Brass Nut Brass Nut Compound or Tape OASNG# OASNG# (Burner Ori ce)
- Page 18 FIREGEAR LIMITED WARRANTY - 2020 Firegear Outdoors hereby warrants to the end user that products will be free from material and workmanship defects that prevent safe and correct operation of the product. The warranty commences from date of sale to the end user for the following period: CONSUMER RESIDENTIAL APPLICATIONS –...
- Page 19 COMMERCIAL APPLICATIONS – MANUFACTURED AFTER 12/02/2019 BURNER SYSTEMS, BURNERS, COMPONENTS AND ACCESSORIES • TWO (2) YEAR WARRANTY ON CONSTRUCTION AND MANUFACTURER DEFECTS • TWO (2) YEAR WARRANTY - STAINLESS STEEL BURNERS AND PANS • TWO (2) YEAR WARRANTY - BRASS BURNERS •...
- Page 20 The manufacturer may request defective products returned with an RMA (Return Merchandise Authorization) issued by Firegear Outdoors for specific products, which is considered to be the nature of the defect and or warranty claim. Product to be returned should; be packed so as not to incur damages during transportation.
- Page 21 We do not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or replacement of its equipment, and or such representation are binding. Firegear Outdoors 17322 Gothard Street, Huntington Beach, CA 92647 www.firegearoutdoors.com Phone: 800-966-8126 Email: order@firegearoutdoors.com...
- Page 22 Having problems getting the fire pit to operate? Don’t leave the job site! We want to help! Call 800.966.8126 for Technical Support between the hours of 8:00AM to 5:00PM PST. BEFORE YOU CALL WE WILL NEED THIS INFORMATION Model Number: ___________________________ Serial Number: ___________________________ How long is the gas line run? Nat Gas ____ LP Gas ____ What size is gas line? _____...
