7 . 1 0 A l a r m s

7 . 1 0 . 1 A l a r m m e s s a g e s

When the unit is on, an alarm icon flashes
Message
P1 Thermostatic control probe failure
P2 Room temperature probe failure
HA Thermostatic control probe high temperature alarm
LA Thermostatic control probe low temperature alarm
CA High pressure switch alarm
NOTE
The alarm relay switches status for all alarms.

7 . 1 0 . 2 A l a r m r e l a y

The Electronic Control Unit has an alarm signalling relay. Its contact is closed during normal operation and is opened in the
case of an alarm or a power blackout.
Refer to the wiring diagram for the relative connections.
In TAEevo Tech MINI 08-10 models a green light remains on to indicate that there are no alarms in the unit.
If an alarm occurs, the light turns red to indicate its presence.
7 . 1 1 P a r a m e t e r l i s t
Every parameter has a corresponding access level:
U= user level
ATTENTION
Changing the default parameters may prevent the unit from functioning correctly.
Parameter Level
SEt U Setpoint
Hy U Compressor control hysteresis
LS U Minimum setpoint
rES U Resolution (per °C): decimal, integer
ALU U Thermostatic control high temperature alarm setpoint
ALL U Thermostatic control low temperature alarm setpoint
dP1 U Thermostatic control temperature value
dP2 U Room temperature probe temperature value
TAEevo Tech MINI 02÷10
and the alarm message appears. The possible alarm messages are listed below:
Cause
Description
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
OPERATING AND MAINTENANCE MANUAL
Chapter 7 - Electronic control unit
Outputs
Compr. Pump
OFF ON
OFF ON
ON ON
ON ON
OFF ON
Default
Range
settings
LS - US 7
(0,1°C÷25,5°C) 4
(0°F÷45°F)
(-55,0°C÷SET) 5
(-67°F÷SET)
dE – in dE
0,0÷50,0°C rel. 40
or ALL÷150°C
(302°F)
0.0÷50°C rel. 4
or -55°C
(-67°F)÷ALU;
read-only --
(probe value)
read-only --
(probe value)
24
