OPERATING AND MAINTENANCE MANUAL
11
Chapter 3 - Technical data
EN
The data plate affixed to the unit bears the following technical data:
MODEL and CODE
MANUAL
SERIAL NUMBER
MANUFACTURING YEAR
VOLTAGE/PHASE/FREQUENCY
MAX CURRENT DRAW (I max)
INSTALLED POWER (P max)
PROTECTION RATING
REFRIGERANT
REFRIGERANT QUANTITY
MAX REFRIG. PRESS.
MAX. REFRIG. TEMP.
USER CIRC. FLUID
MAX WORKING PRESSURE
MAX. TEMPERATURE
CONDENSER COOLING FLUID
MAX WORKING PRESSURE
MAX. TEMPERATURE
SOUND PRESSURE LEVEL
AMBIENT TEMPERATURE
WEIGHT
ATTENTION
The performance of the unit depends mainly on the flow rate and temperature of water in the user circuit, and the
condenser thermal exchange fluid temperature. These values are defined at the time of the offer.
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
C
HAPTER
T
E C H N I C A L D A T A
The model number and the code identify the size of the unit and the type of
construction.
Code number of the manual.
Construction number of the unit.
Year of unit's final testing.
Electrical power supply characteristics.
Unit current draw in limit operating conditions.
Unit power input in limit operating conditions
According to European standard EN 60529.
Refrigerant fluid in the unit.
Quantity of refrigerant fluid contained in the unit.
Refrigerant circuit design pressure
Refrigerant circuit design temperature
Type of user fluid utilised by the unit (normally water)
Max. design pressure of the user circuit.
Maximum design temperature of the user circuit; this should not be confused
with the maximum working temperature which is established when the offer is
made.
Fluid used by the unit to cool the condenser (this data is not present if the unit is
air cooled condensed).
Max. design pressure of the condenser cooling circuit (this data is not present if
the unit is air cooled condensed).
Condenser cooling circuit maximum design temperature (this information is not
given if the unit's condenser is air-cooled).
Free field sound pressure level in hemispherical radiation conditions (open
field) at a distance of 1 m from the condenser side of the unit and a height of 1.6
m from the ground.
Minimum and maximum values of ambient air temperature.
Approximate weight of the unit before packing.
3
TAEevo Tech MINI 02÷10
