- Page 1 T A E e v o T e c h M I N I ATER CHILLERS TAEevo Tech MINI 02÷10 O P E R A T I N G A N D M A I N T E N A N C E M A N U A L...
-
Page 2: - User's Quick Guide
Press the key to confirm or wait for the time-out. TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited... -
Page 3: Table Of Contents
Location ............................17 Freeze protection.........................18 Limit operating conditions......................18 Plumbing connections.........................18 Electrical connections .........................19 TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited... - Page 4 Chapter 10 .........................28 ROUBLE SHOOTING Chapter 11 ......................31 ISK ANALYSIS RESIDUAL RISK TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited...
-
Page 5: General Information
H o w t o i n t e r p r e t t h e m o d e l MODEL DESCRIPTION TAEevo Tech MINI XXX Guideline power of compressor expressed in HP E = hermetic compressor A = air-cooled condenser T = tank;... -
Page 6: Safety
TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited... -
Page 7: Lifting And Transport Precautions
The weight values shown in the table below were obtained with the unit empty and in the basic configuration. The manufacturer does not supply load spreaders, lifting straps or hooks with the unit. Model TAEevo Tech MINI Weight (kg) NOTE Weight values are guideline, with the water circuit empty. -
Page 8: Disposal
TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited... -
Page 9: Refrigerant Gases
2 . 8 R e f r i g e r a n t g a s e s The units are charged with R134a refrigerant (TAEevo Tech MINI 02-03) or with R410A refrigerant (TAEevo Tech MINI 05÷10). Do not replace or mix one gas with another because different gases are not mutually compatible. - Page 10 Global warming potential HGWP 0.28 (R11=1): Ozone depletion potential ODP (R11=1): Considerations on disposal: Usable with reconditioning TAEevo Tech MINI 05÷10 Denomination: R410A (50% Difluoromethane (R32); 50% Pentafluoroethane (R125)). INDICATION OF HAZARDS Major hazards: Suffocation. Specific hazards: Rapid evaporation can cause frostbite.
- Page 11 Ozone depletion potential ODP (R11=1): Considerations on disposal: Usable with reconditioning. TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited...
-
Page 12: Technical Data
These values are defined at the time of the offer. TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited... -
Page 13: Declaration Of Conformity
See attached drawings. 3 . 2 . 2 C h a r a c t e ri s t i c s o f p u m p a n d f a n Model TAEevo Tech MINI Tank water volume... - Page 14 OPERATING AND MAINTENANCE MANUAL Chapter 3 - Technical data Available head TAEevo Tech MINI 02-03 Prevalenza utile M02-M03 Portata m3/h Flow [m Available head TAEevo Tech MINI 05÷10 Prevalenza utile M05-M10 Portata m3/h Flow [m NOTE The pump must never run dry.
-
Page 15: Sound Level Measurements
So u n d l e v e l m e a s u r e me n t s Lp dB(A) * Lw dB(A) ** TAEevo Tech MINI 02 TAEevo Tech MINI 03 TAEevo Tech MINI 05 TAEevo Tech MINI 08 TAEevo Tech MINI 10 * at distance of 1 m (3.2 FT) -
Page 16: Description
R e f r i g e r a t i o n c o m p r e s s o r Of alternative hermetic type (TAEevo Tech MINI 02-03) and of rotary hermetic type (TAEevo Tech MINI 05-10), cooled by the aspirated refrigerant and equipped with thermal cutout protection. -
Page 17: Overall Dimensions
When it exits the evaporator, the refrigerant is again sucked by the compressor and the cycle repeats itself. The refrigerant circuit is also furnished with a high pressure switch (HP) of manual reset type (TAEevo Tech MINI 05-10). 4 . 5 E l e c t r i c a l c i r c u i t See the enclosed electrical diagrams. -
Page 18: Installation
8. Do not install the plant in sites exposed to strong winds; if unavoidable, install suitable windscreens. See point 1. TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited... -
Page 19: Freeze Protection
TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited... -
Page 20: Electrical Connections
Chapter 5 - Installation ATTENTION Before starting the pump, ensure that the circuit is full of water. Evaporator water connections sizes: Unit model TAEevo Tech MINI 02÷10 Evaporator IN/OUT water 1/2” female connections 5 . 6 E l e c t r i c a l c o n n e c t i o n s The unit’s connection to the power supply must be made in compliance with laws and prescriptions in force in the place of... -
Page 21: Start Up
3. Check that the ambient temperature is within the limits indicated on the machine data plate. 4. Check that the main switch is in the OFF position (TAEevo Tech MINI 08-10). 5. Check that the power supply voltage is correct. -
Page 22: Lectronic Control Unit
Access to programming mode (held down for 3") Quit programming mode. TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited... -
Page 23: Switching The Unit On/Off
2. The screen shows “Hi” and the maximum temperature reached. 3. Press the key to return to the current temperature. TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited... -
Page 24: Modifying The Value Of A Parameter
If the control temperature is higher than SET+HY, the compressor is on; if it is below SET, the compressor is shut down. TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited... -
Page 25: Alarms
Refer to the wiring diagram for the relative connections. In TAEevo Tech MINI 08-10 models a green light remains on to indicate that there are no alarms in the unit. If an alarm occurs, the light turns red to indicate its presence. -
Page 26: High Pressure Switch (Hp)
( H P ) I G H P R E S S U R E S W I T C H TAEevo Tech MINI 05÷10 models are furnished with a high pressure switch (HP), not present in TAEevo Tech MINI 02-03 models. -
Page 27: Operation And Maintenance
Removing the front panel "A" gives access to the electrical panel, the pump, the water circuit and the refrigeration circuit components. TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited... -
Page 28: Maintenance Schedule
In some installations it may be necessary to increase the frequency of maintenance. TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited... -
Page 29: Rouble Shooting
• run a high water flow against the stream. Install a filter upstream from the chiller. TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited... - Page 30 Change the fuse. TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited...
- Page 31 TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited...
- Page 32 Strictly observe all manual electrostatic discharge due to contact instructions. phenomena. 5.6 “Electrical connections” TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited...
- Page 33 Chapter 9 system. “Operation and maintenance“ TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited...
- Page 34 Strictly observe all manual graphic safety signs. instructions. Chapter 1 “General information“ TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited...
- Page 35 TAEevo Tech MINI 02÷10 The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited...
