8. Status LEDs

There are two status LEDs on the MelcoBEMS MINI (A1M). The LED indications are as follows:
LED Name

AC ACK

RS-485 ACK

8.1. AC ACK
If this LED is permanently lit and does not flash, check the CN105/CN92 connection is secure.
8.2. RS-485 ACK
If this LED is permanently lit and does not flash it could be due to a physical RS-485 connection problem, or incorrect
Modbus/RS-485 configuration.
Page 14 of 47
Colour
Lit when A1M is powered, flashing indicates valid communication
Green
with the indoor unit.
Lit when A1M is powered, flashing indicates valid Modbus
Green
communication.
Functionality
