Procon MelcoBEMS MINI Installation Manual page 43

Brine Outlet Temperature 1
(signed)
Brine Outlet Temperature 1
Brine Outlet Temperature 2
(signed)
Brine Outlet Temperature 2
Condensing Temperature 2
(signed)
Condensing Temperature 2
Water Outlet Temperature 2
(signed)
Water Outlet Temperature 2
Evaporating Temperature 2
(signed)
Evaporating Temperature 2
Water Pump 1 – PWM Duty
Water Pump 1 – PWM Duty
Feedback
3-Way Valve 1
H/C Control Type
MRC Prohibit
Version of Protocol (upper)
Version of Protocol (lower)
Version of Model (upper)
Version of Model (lower)
Capacity of Supplying Electricity
Model Profile 1
Model Profile 2 (refrigerant
address)
Page 39 of 47
Temperature value in ºC multiplied by 100.
131 30132
(see note *)
Temperature value in ºC multiplied by 100.
132 30133
(see note **)
Temperature value in ºC multiplied by 100.
133 30134
(see note *)
Temperature value in ºC multiplied by 100.
134 30135
(see note **)
Temperature value in ºC multiplied by 100.
135 30136
(see note *)
Temperature value in ºC multiplied by 100.
136 30137
(see note **)
Temperature value in ºC multiplied by 100.
137 30138
(see note *)
Temperature value in ºC multiplied by 100.
138 30139
(see note **)
Temperature value in ºC multiplied by 100.
139 30140
(see note *)
Temperature value in ºC multiplied by 100.
140 30141
(see note **)
Duty value in %
141 30142
0 = 0% ... 100 = 100%
Duty value in %
142 30143
0 = 0% ... 100 = 100%
0 = OFF (stop)
143 30144
1 = ON (run)
0 = Heating
144 30145
1 = Cooling
Bit packed value:
Bit 0 – System On/Off (0 = ON, 1 = Prohibit)
Bit 1 – Running Mode (0 = ON, 1 = Prohibit)
Bit 2 – Setting Temp (0 = ON, 1 = Prohibit)
145 30146
Bit 3 – Undefined (always 0)
Bit 4 – Function Setting (0 = Normal, 1 = Function
Setting)
Bits 5, 6 and 7 – Undefined (always 0)
Version of Protocol is a value in BCD
146 30147
e.g. V3.01 = 3 (upper) and 1 (lower)
Version of Protocol is a value in BCD
147 30148
e.g. V3.01 = 3 (upper) and 1 (lower)
Version of Model is a value in BCD
148 30149
e.g. V2.00 = 2 (upper) and 0 (lower)
Version of Model is a value in BCD
149 30150
e.g. V2.00 = 2 (upper) and 0 (lower)
Value in Watts
0 = 0,0 W
150 30151
...
255 = 25,5 W
0 = FTC2B
1 = FTC4
2 = FTC5
128 = CAHV1A
151 30152
129 = CAHV1B
130 = CRHV1A
131 = CRHV1B
144 = PWFY1
0 = Address 0
...
152 30153 255 = Address 255
(addresses 7 – 255 not used for FTC)










