3.3. Protocol selection
The RS485 protocol is set using DIP switch 7.
When the switch is in the ON position the Modbus RTU protocol is selected.
3.4. Deadband mode
The Deadband feature can be enabled using DIP switch 8.
When the switch is in the OFF position the Deadband feature is disabled.
When the switch is in the ON position the Deadband feature is enabled.
Page 7 of 47
Switch 7
OFF
ON
Switch 8
OFF
ON
Protocol selection
BACnet MS/TP
Modbus RTU
Deadband feature
Disabled
Enabled
