- Page 1 O P E R A T I N G I N S T R U C T I O N S UE10-3OS Expansion module for basic devices SR-UE10...
-
Page 2: Table Of Contents
Technical specifications..............14 11.1 Data sheet....................11.2 Dimensional drawings................O P E R A T I N G I N S T R U C T I O N S | UE10-3OS 8022191/2017-11-24 | SICK Subject to change without notice... -
Page 3: Ordering Information
Plug-in spring termi‐ SR-UE10 1092502 nals 8022191/2017-11-24 | SICK O P E R A T I N G I N S T R U C T I O N S | UE10-3OS Subject to change without notice... -
Page 4: Scope
(yy = year, ww = calender week, xxxx = serial number). These operating instructions are original operating instructions. O P E R A T I N G I N S T R U C T I O N S | UE10-3OS 8022191/2017-11-24 | SICK... -
Page 5: On Safety
— any warranty claim against SICK AG shall become void. 8022191/2017-11-24 | SICK O P E R A T I N G I N S T R U C T I O N S | UE10-3OS Subject to change without notice... -
Page 6: General Safety Instructions And Protective Measures
(e.g. European Waste Code 16 02 14). O P E R A T I N G I N S T R U C T I O N S | UE10-3OS 8022191/2017-11-24 | SICK Subject to change without notice... -
Page 7: Product Description
K1 O Green Channel 1 switched Channel 2 switched K2 OGreen 8022191/2017-11-24 | SICK O P E R A T I N G I N S T R U C T I O N S | UE10-3OS Subject to change without notice... -
Page 8: Mounting
Mounting in accordance with EN 50274. Mounting on a 35 mm mounting rail (EN 60715). O P E R A T I N G I N S T R U C T I O N S | UE10-3OS 8022191/2017-11-24 | SICK... -
Page 9: Electrical Installation
B2 and B4. 8022191/2017-11-24 | SICK O P E R A T I N G I N S T R U C T I O N S | UE10-3OS Subject to change without notice... -
Page 10: Commissioning And Regular Tests
O P E R A T I N G I N S T R U C T I O N S | UE10-3OS 8022191/2017-11-24 | SICK... -
Page 11: In The Event Of Faults Or Errors
After rectifying a fault, perform a complete function test. 8022191/2017-11-24 | SICK O P E R A T I N G I N S T R U C T I O N S | UE10-3OS Subject to change without notice... -
Page 12: Compliance With Eu Directives
Complete EU declaration of conformity for download: www.sick.com O P E R A T I N G I N S T R U C T I O N S | UE10-3OS 8022191/2017-11-24 | SICK Subject to change without notice... -
Page 13: Internal Circuitry
Figure 1: Internal circuitry UE103OS Figure 2: Basic circuit UE103OS 8022191/2017-11-24 | SICK O P E R A T I N G I N S T R U C T I O N S | UE10-3OS Subject to change without notice... -
Page 14: Technical Specifications
With DC = 99 % and MTTFd = 100 a (according to EN ISO 13 849, Tab. K1 and formula C.7) and 8760 switching operations/a. Depending on the basic device, e.g. ESPE connected. O P E R A T I N G I N S T R U C T I O N S | UE10-3OS 8022191/2017-11-24 | SICK... - Page 15 To achieve overvoltage category III see note in chapter "Electrical installation", page 8022191/2017-11-24 | SICK O P E R A T I N G I N S T R U C T I O N S | UE10-3OS Subject to change without notice...
-
Page 16: Dimensional Drawings
93,7 Figure 3: Dimensional Drawing UE10-3OS with removable terminals O P E R A T I N G I N S T R U C T I O N S | UE10-3OS 8022191/2017-11-24 | SICK Subject to change without notice... - Page 17 Phone +36 1 371 2680 Phone +386 591 788 49 E-Mail office@sick.hu E-Mail office@sick.si India South Africa Phone +91 22 6119 8900 Phone +27 11 472 3733 Further locations at www.sick.com E-Mail info@sick-india.com E-Mail info@sickautomation.co.za SICK AG | Waldkirch | Germany | www.sick.com...
