Coolaroo MACKAY Assembly Manual And Operating Instructions

Cantilever umbrella
Hide thumbs

Advertisement

Quick Links

Download this manual
CANTILEVER UMBRELLA
MACKAY
ASSEMBLY GUIDE AND
OPERATING INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the MACKAY and is the answer not in the manual?

Questions and answers

Related Manuals for Coolaroo MACKAY

Summary of Contents for Coolaroo MACKAY

  • Page 1 CANTILEVER UMBRELLA MACKAY ASSEMBLY GUIDE AND OPERATING INSTRUCTIONS...

  • Page 2: Care And Maintenance

    WARNING When assembling and using this product, safety precautions should always be followed to reduce the risk of personal injury and damage to equipment. Please read all instructions before assembly and use. Two or more people are recommended for safe assembly. Keep all children and pets away from assembly area.
  • Page 3 ASSEMBLY GUIDE 2.8m STEP 1 Take all of the parts out of box 1 and 2 to ensure they are all present before starting construction. Box 1 a) Umbrella frame and cover (Ø16XØ8.2X2) b) Lower pole 360 degree swivel d) Plastic cover e) Screws x4 (M8x25) Screws x4 (M8x14) g) Washers x8...
  • Page 4 STEP 2 Attach the swivel base (c) to the water base (k) using screws (e) and washers (g). Use allen key (I) to tighten. e (M8X25) STEP 3 Attach the lower pole (b) to the swivel base using screws (f) and washers (g). Use allen key (I) to tighten.
  • Page 5 STEP 4 Fill base (k) with water or sand. Place plastic cover (d) over lower pole (b). STEP 5 Place umbrella frame and cover(a) over lower pole (b) so it slides inside the plastic cover (d).

  • Page 6: Step 6 - To Operate

    STEP 6 - TO OPERATE Ensure ribs are free to move by fluffing open the canopy. Pull the trigger on the easy glide handle and lift until it locks into the lowest position. Open the umbrella by inserting and winding the crank handle (h). STEP 7 To open the canopy, wind the crank handle (h) in a clockwise direction.
  • Page 7 STEP 8 - ROTATING THE CANOPY Use the foot pedal on the swivel base (c) to rotate the canopy in a clockwise, or anti clockwise direction. The canopy can be rotated 360 degrees in either direction. 360 ° STEP 9 - CLOSING THE UMBRELLA To close the umbrella, wind the canopy down with the crank handle in the anti clockwise direction.

  • Page 8: Step 10 - Install The Cover

    STEP 10 - INSTALL THE COVER With the cover open, use the stay poles to position the cover over the closed umbrella. Use the Velcro to close and secure the cover over the umbrella. ® Ensure canopy is closed when not in use. Close in windy conditions or when a storm approaches. Never allow the umbrella to flap in the wind;...
  • Page 9 AND LIMITATION OF LIABILITY 1) Upon purchasing the Product, the customer must register their warranty by completing the Coolaroo Coolaroo products are manufacture by Gale Pacific Limited online warranty registration at www.coolaroo.com. ACN 082 263 778 (Gale). Gale provides the following Alternatively, the customer can contact Coolaroo warranty in relation to Coolaroo products (“Product”).
  • Page 10 WARNING: SHADE DOES NOT PROVIDE 100% PROTECTION Coolaroo umbrella fabric is tested to meet UPF50+ and the highest UV effectiveness, but some UV can still reach you in the shade by reflecting off surrounding surfaces. Always combine shade with clothing, sunscreen, a hat and sunglasses.
  • Page 11 coolaroo.com...
  • Page 12 Smart steps: slip on clothing, slop on sunscreen, slap on a hat, slide on sunglasses and seek shade under your premium Coolaroo umbrella. To register your product, go to coolaroo.com. The product code can be found printed above the barcode on the product packaging, alternatively you can find it on the relevant coolaroo.com product page.
