Coolaroo Cantilever Umbrella Water Base Installation Instructions

Congratulations on the purchase of your Coolaroo
instructions before using your umbrella.
1

SETUP CANTILEVER UMBRELLA BASE

Install Cantilever base cross beams and pole
according to Cantilever umbrella instruction
manual (Fig.1).
Fig. 1
3

FILL THE BASE

Fill all four bases with water or sand until it is
filled, then secure base with cap. (Fig. 3).
Fig. 3
Questions or Comments? Contact us at:
GALE Pacific USA | www.coolaroousa.com | 1-800-560-4667
© by GALE Pacific Limited. All rights reserved. Coolaroo
CANTILEVER UMBRELLA
Water Base
Cantilever Umbrella Water Base. Please be sure to read the
®
2
Fig. 2
4
Fig. 4
is a registered trademark of GALE Pacific Limited.
®
INSTALLATION
INSTRUCTIONS

REMOVE CAP

Remove cap from base unit (Fig. 2).

PLACE BASE UNITS

Place filled base units on the cross
bars (Fig. 4).
Register and order
replacement parts online:
www.coolaroousa.com
5.04.004.179
