Page 1
CANTILEVER UMBRELLA B A N K S I A A S S E M B L Y G U I D E Warranty...
Page 2
3.5m/11'6" 2.82m/9'3" 2.2m/7'3" BANKSIA STEP 1 Take all parts out of boxes 1 and 2 and ensure they are all present. Box 1 a) Lower pole x 1 b) 360˚ Swivel system x 1 c) Screws x 4 (M8 x 15)
Page 3
A S S E M B L Y G U I D E STEP 2 Check that cross base pieces are secured to the under side of (n). Attach wheels (o) to the underside of (n) (optional). STEP 3 Using screws (d) and washers (e) fix the 360°...
Page 4
STEP 6 Place the umbrella frame pole (f) onto the lower pole (a). Push plastic cover (i) down to sit neatly on plastic cone (j). Secure poles together using the screw with plastic cap (h). STEP 7 Using the easy glide handle, push in an upwards direction towards the top of the umbrella pole until it locks into the lowest position.
Sun Smart steps: slip on clothing, slop on sunscreen, slap on a hat, slide on sunglasses and seek shade. To register your product go to coolaroo.com.au. The product code can be found printed above the barcode on the product packaging, alternatively you can find it on the relevant coolaroo.com.au product page.
Page 6
The best under the sun Coolaroo is the leader in shade fabric technology. Our extensive range of attractive shade solutions is carefully manufactured to protect your home, garden and family from the harsh sun. coolaroo.com.au WARNING When assembling and using this product, safety precautions should always be followed to reduce the risk of personal injury and damage to equipment.
