Coolaroo Myrtle Assembly Manual

Market umbrella

MARKET UMBRELLA

M Y R T L E / G R E V I L L E A

5YR

A S S E M B L Y G U I D E

Warranty

Table of Contents

Need help?

Do you have a question about the Myrtle and is the answer not in the manual?

Page 1 MARKET UMBRELLA M Y R T L E / G R E V I L L E A A S S E M B L Y G U I D E Warranty...
Page 2 3.3m/10'10" 2 x 3m/6'7" x 9'10" 2.72m/8'11" 2.2m/7'2" 2.72m/8'11" 2.3m/7'3" MYRTLE 3.3m/10'10" 2 x 3m/6'7" x 9'10" /7'2" 2.72m/8'11" 2.3m/7'3" GREVILLEA...
Page 3 A S S E M B L Y G U I D E STEP 1 Take all parts out of the box and ensure they are all present. a) Umbrella frame with canopy x 1 b) Lower pole x 1 c) Finial x 1 STEP 2 Screw the finial into the pre-drilled hole...
Page 4 STEP 3 To assemble the umbrella, screw the top pole into the bottom pole until secure. STEP 4 To open the umbrella, pull the cord down until the canopy is up past the pin hole, place the stop pin into the desired hole to hold the umbrella in place.
Page 5 Sun Smart steps: slip on clothing, slop on sunscreen, slap on a hat, slide on sunglasses and seek shade. To register your product go to coolaroo.com.au. The product code can be found printed above the barcode on the product packaging, alternatively you can find it on the relevant coolaroo.com.au product page.
Page 6 The best under the sun Coolaroo is the leader in shade fabric technology. Our extensive range of attractive shade solutions is carefully manufactured to protect your home, garden and family from the harsh sun. coolaroo.com.au WARNING When assembling and using this product, safety precautions should always be followed to reduce the risk of personal injury and damage to equipment.
