CANTILEVER UMBRELLA
HAMPTON
3M ROUND
3.5M ROUND | 3M SQUARE
2x3M RECTANGLE | 3x4M RECTANGLE
ASSEMBLY GUIDE AND
OPERATING INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the HAMPTON 3M ROUND and is the answer not in the manual?

Questions and answers

Summary of Contents for Coolaroo HAMPTON 3M ROUND

  • Page 1 CANTILEVER UMBRELLA HAMPTON 3M ROUND 3.5M ROUND | 3M SQUARE 2x3M RECTANGLE | 3x4M RECTANGLE ASSEMBLY GUIDE AND OPERATING INSTRUCTIONS...
  • Page 2: Care And Maintenance

    WARNING When assembling and using this product, safety precautions should always be followed to reduce the risk of personal injury and damage to equipment. Please read all instructions before assembly and use. Two or more people are recommended for safe assembly. Keep all children and pets away from assembly area.
  • Page 3 ASSEMBLY GUIDE HAMPTON CANTILEVER UMBRELLA 3M SQUARE 2x3M RECTANGLE 3x4M RECTANGLE 510466 510473 510497 2.7m 2.1m 2.8m 2.1m 2.3m 3M ROUND 3.5M ROUND 510459 510480 3.5m 2.7m 2.1m 2.7m 2.1m...
  • Page 4 STEP 1 Take all of the parts out of box 1 and 2 to ensure they are all present before starting construction. Box 1 a) Umbrella frame and cover (Ø16xØ8.2x2) b) Lower pole 360 degree swivel d) Plastic cover e) Bolts x4 (M8x25) Bolts x4 (M8x14) g) Washers x8 h) Crank handle...
  • Page 5 STEP 3 Attach the lower pole (b) to the swivel base using screws (f) and washers (g). Use allen key (I) to tighten. STEP 4 Fill base (k) with water or sand. Place plastic cover (d) over lower pole (b).
  • Page 6: Step 6 - To Operate

    STEP 5 Place umbrella frame and cover(a) over lower pole (b) so it slides inside the plastic cover (d). STEP 6 - TO OPERATE inserting and winding the crank handle (h).
  • Page 7 STEP 7 To open the canopy, wind the crank handle (h) in a clockwise direction. To close the canopy, wind the crank handle in an anti clockwise direction. STEP 8 - ROTATING THE CANOPY Use the foot pedal on the swivel base (c) to rotate the canopy in a clockwise, or anti clockwise direction.
  • Page 8: Step 10 - Install The Cover

    STEP 9 - CLOSING THE UMBRELLA To close the umbrella, wind the canopy down with the crank handle in the anti clockwise direction. Move the easy glide handle to the bottom position and wrap the Velcro straps around the canopy. ®...
  • Page 9 WARRANTY CLAIMS AND LIMITATION OF LIABILITY 1) Upon purchasing the Product, the customer must register their warranty by completing the Coolaroo online warranty registration at www.coolaroo.com. ACN 082 263 778 (Gale). Gale provides the following Alternatively, the customer can contact Coolaroo warranty in relation to Coolaroo products (“Product”).
  • Page 10 WARNING: SHADE DOES NOT PROVIDE 100% PROTECTION Coolaroo umbrella fabric is tested to meet UPF50+ and the highest Always combine shade with clothing, sunscreen, a hat and sunglasses. PROTECT YOURSELF IN FIVE WAYS FROM SKIN CANCER Slip Slop Slap Seek...
  • Page 11 coolaroo.com...
  • Page 12 Smart steps: slip on clothing, slop on sunscreen, slap on a hat, slide on sunglasses and seek shade under your premium Coolaroo umbrella. To register your product, go to coolaroo.com. The product code can be found printed above the barcode on the product packaging, alternatively coolaroo.com...
