  • Page 1 ION 5200 Hardware Reference docs.paloaltonetworks.com...
  • Page 2 Alto Networks. A list of our trademarks can be found at www.paloaltonetworks.com/company/ trademarks.html. All other marks mentioned herein may be trademarks of their respective companies. Last Revised September 2, 2022 ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc. ©...

  • Page 3: Table Of Contents

    ION 5200 Hardware Specifications..................12 ION 5200 Front Panel......................14 ION 5200 Back Panel......................15 ION 5200 Compliance Statement..................16 Install the ION 5200..................21 Install the ION 5200 Using the Four-Post Rack Mount Kit..........22 ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc. ©...
  • Page 4 Table of Contents ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc. ©...

  • Page 5: Before You Begin

    Before You Begin Learn about the product safety and compliance before you begin: > Tamper Proof Statement > Product Safety Warnings > Third-Party Component Support...

  • Page 6: Tamper Proof Statement

    • The integrity of the tamper-proof tape used to seal the box or crate is not compromised. • The integrity of the warranty label on the firewall or appliance is not compromised. ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc.

  • Page 7: Third-Party Component Support

    Before You Begin Third-Party Component Support Before you consider installing third-party hardware, read the Palo Alto Networks Third-Party Component Support statement. ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc. ©...

  • Page 8: Product Safety Warnings

    Mettez au rebut les batteries usagées conformément aux instructions. • I/O ports are intended for intra-building connections only and not intended for OSP (Outside Plant) connections or any network connections subject to external voltage surge events. ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc. ©...
  • Page 9 French Translation: (Tous les appareils Palo Alto Networks avec au moins deux sources d’alimentation) Débranchez tous les cordons d’alimentation (c.a. ou c.c.) des entrées d’alimentation et mettez le matériel hors tension. ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc. ©...
  • Page 10 Before You Begin ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc. ©...

  • Page 11: Ion 5200 Overview

    Prisma SD-WAN ION 5200 is a next generation software-defined device that can be deployed in a large branch or a data center. With the introduction of ION 5200, accelerate your SASE deployment to a large branch or a DC by leveraging WAN connectivity without installing additional hardware to enable rapid deployments.

  • Page 12: Ion 5200 Hardware Specifications

    ION 5200 Overview ION 5200 Hardware Specifications Learn the hardware specifications of the ION 5200 device. Feature ION 5200 Description Enterprise large branch and data center. Ports Console Port 1 x RJ-45, UART/Micro USB Type B Console WAN/LAN ports Ports 1-19 are ethernet ports...
  • Page 13 -4ºF - 158ºF (-20ºC - 70ºC) Operating humidity (non-condensing) 5-90% Storage humidity (non-condensing) 5-95% Physical Dimensions (DxWxH) 361.44mm x 434.90mm x 43.20mm (14.22” x 17.12” x1.70”) Weight (lbs) 15.5 Mount options Four-post Rack ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc. ©...

  • Page 14: Ion 5200 Front Panel

    ION 5200 Overview ION 5200 Front Panel The following table describes the front panel components of the ION 5200. Item Component Description ByPass Pair Ports 1 - 4 are ByPass pairs. PoE Ports Ports 9 - 12 are PoE ports.

  • Page 15: Ion 5200 Back Panel

    ION 5200 Overview ION 5200 Back Panel The following table describes the back panel components of the ION 5200. Item Component Description Fan Exhaust Provides ventilation and cooling for the device. The fans are not field replaceable. Ground stud Use the single post ground stud to connect the firewall to earth ground (ground cable not included).

  • Page 16: Ion 5200 Compliance Statement

    ION 5200 Overview ION 5200 Compliance Statement The following compliance statements apply to this ION device: • VCCI—This section provides the compliance statement for the Voluntary Control Council for Interference by Information Technology Equipment (VCCI), which governs radio frequency emissions in Japan.
  • Page 17 • Korean Communications Commission (KCC) Class A Statement—This equipment is an electromagnetic compatible device for business purposes (Class A). The provider or user should be aware that the equipment is intended for use outside the home. ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc. ©...
  • Page 18 ION 5200 Overview • Taiwan Declaration of the Presence Condition of the Restricted Substances Marking. ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc. ©...
  • Page 19 ION 5200 Overview ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc. ©...
  • Page 20 ION 5200 Overview ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc. ©...

  • Page 21: Install The Ion 5200

    Install the ION 5200 The ION 5200 ships with rack-mount brackets for installation in a four-post 19” equipment rack. Learn how to install the device using the four-post rack mount kit. > Install the ION 5200 Using the Four-Post Rack Mount Kit...

  • Page 22: Install The Ion 5200 Using The Four-Post Rack Mount Kit

    Install the ION 5200 Install the ION 5200 Using the Four-Post Rack Mount The following procedure describes how to install the ION 5200 in a 19” four-post equipment rack using the four-post rack kit. STEP 1 | Attach one rack-mount bracket to each side of the ION 5200 in the front-mount position using four #6-32 x 5/16”...
  • Page 23 Install the ION 5200 1/2”) for your rack and torque to 25 in-lbs. Use cage nuts to secure the screws if the rack has square holes. ION 5200 Hardware Reference 2022 Palo Alto Networks, Inc. ©...
  • Page 24 Install the ION 5200 STEP 4 | Slide one back rack-mount bracket into each of the two previously installed side rack-mount rails and secure the brackets to the back rack-posts using the appropriate screws for your rack (#10-32 x 3/4” or #12-24 x 1/2”) and torque to 25 in-lbs.
