4 Tier Ladder Shelf
Assembly Instructions - Please keep for future reference
Important – Please read these instructions before assembly
If you need help or have damaged or missing parts, email:
linsyhome@outlook.com
LS200P1-A
Dimensions
Width -
21.65inch
Depth -
15.00inch
Height -
66.93inch
1
Advertisement
Related Manuals for LINSY HOME LS200P1-A
Summary of Contents for LINSY HOME LS200P1-A
- Page 1 4 Tier Ladder Shelf Assembly Instructions - Please keep for future reference LS200P1-A Dimensions Width - 21.65inch Depth - 15.00inch Height - 66.93inch Important – Please read these instructions before assembly If you need help or have damaged or missing parts, email:...
-
Page 2: General Information
Safety and Care Advice Important – Please read these instructions fully before starting assembly Assemble on a soft level surface Check that if you have all the Do not stand or put weight on the to avoid damaging the unit or your components and tools listed on the product, this could cause damage. -
Page 3: Part List
Components If you need help or have damaged or missing parts, email: linsyhome@outlook.com Please check you have all the pieces listed below Part List Reference Description Speci cations(mm) Quantity Material Top panel 520*122*15 Particle Board Upper middle panel 520*197*15 Particle Board Lower middle panel 520*272*15 Particle Board... - Page 4 Components If you need help or have damaged or missing parts, email: linsyhome@outlook.com Please check you have all the pieces listed below M7x48 x 16 pcs M6x15 x 8 pcs M6x12 x 8 pcs S4 x 2 pcs 2 pcs S2.5 x 1 pc 1 pc M4 x 4 pcs...
- Page 5 Assembly Instructions Step 2 B x 4 pcs C x 4 pcs D x 2 pcs Don’t screw tightly before all the screws are put into the corresponding holes Step 3 A x 8 pcs D x 1 pc Don’t screw tightly before all the screws are put into the corresponding holes...
- Page 6 Assembly Instructions Step 4 A x 8 pcs D x 1 pc Don’t screw tightly before all the screws are put into the corresponding holes Step 5 J x 4 pcs...
- Page 7 Assembly Instructions Step 6 G x 4 pcs H x 4 pcs I x 4 pcs F x 1 pc All screws should be tightly screwed Step 7 E x 2 pcs...
