TV Stand
Assembly Instructions - Please keep for future reference
Important – Please read these instructions before assembly
If you need help or have damaged or missing parts, email:
linsyhome@outlook.com
LS209M1-A
Dimensions
Width -
55.11inch
Depth -
17.32inch
Height -
19.69inch
1
Advertisement
Table of Contents
Related Manuals for LINSY HOME LS209M1-A
Summary of Contents for LINSY HOME LS209M1-A
- Page 1 TV Stand Assembly Instructions - Please keep for future reference LS209M1-A Dimensions Width - 55.11inch Depth - 17.32inch Height - 19.69inch Important – Please read these instructions before assembly If you need help or have damaged or missing parts, email:...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly Assemble on a soft level surface Check that if you have all the Do not stand or put weight on the to avoid damaging the unit or your components and tools listed on the product, which could cause damage.
- Page 3 Components If you need help or have damaged or missing parts, email: linsyhome@outlook.com Please check you have all the pieces listed below Part List Reference Description Speci cations(mm) Quantity Material Top Frame 1400*440*20 Steel Reference Description Speci cations(mm) Quantity Material Left Frame 470*440*20 Steel...
- Page 4 Components If you need help or have damaged or missing parts, email: linsyhome@outlook.com Please check you have all the pieces listed below M6x12 x 26 pcs M6x30 x 8 pcs M6 x 4 pcs Spare Parts S4 x 1 pc Spare Parts x 1 pc Assembly Instructions Step 1...
- Page 5 Assembly Instructions Step 2 A x 4 pcs D x 1 pc Don’t screw tightly before all the screws are put into the corresponding holes Step 3 A x 2 pcs B x 2 pcs D x 1 pc Don’t screw tightly before all the screws are put into the corresponding holes...
- Page 6 Assembly Instructions Step 4 Don’t screw tightly before all the screws B x 6 pcs are put into the corresponding holes D x 1 pc Step 5 A x 12 pcs C x 4 pcs D x 1 pc Don’t screw tightly before all the screws are put into the corresponding holes DO NOT USE THE WRONG SCREWS.
- Page 7 Assembly Instructions Step 6 D x 1 pc All screws should be tightly screwed...
