Foldable Shaped End Table
Assembly Instructions - Please keep for future reference
Important – Please read these instructions before assembly
If you need help or have damaged or missing parts, email:
linsyhome@outlook.com
LS200J2-C
Dimensions
Width -
18.90inch
Depth -
11.73inch
Height -
23.43inch
1
Advertisement
Related Manuals for LINSY HOME LS200J2-C
Summary of Contents for LINSY HOME LS200J2-C
- Page 1 Foldable Shaped End Table Assembly Instructions - Please keep for future reference LS200J2-C Dimensions Width - 18.90inch Depth - 11.73inch Height - 23.43inch Important – Please read these instructions before assembly If you need help or have damaged or missing parts, email:...
-
Page 2: General Information
Safety and Care Advice Important – Please read these instructions fully before starting assembly Assemble on a soft level surface Check that if you have all the Do not stand or put weight on the to avoid damaging the unit or your components and tools listed on the product, which could cause damage. -
Page 3: Part List
Components If you need help or have damaged or missing parts, email: linsyhome@outlook.com Please check you have all the pieces listed below Part List Reference Description Speci cations(mm) Quantity Material Top Frame 352.5*288*18 Steel 470*288*16 Bottom Frame Steel 521*60*16 Steel Front Tube Back Tube 521*50*16... - Page 4 Components If you need help or have damaged or missing parts, email: linsyhome@outlook.com Please check you have all the pieces listed below M6x10 x 6 pcs M6x25 x 8 pcs M6 x 4 pcs Spare Parts S4 x 1 pc Spare Parts x 1 pc Assembly Instructions Step 1...
- Page 5 Assembly Instructions Step 2 A x 6 pcs B x 4 pcs D x 1 pc Don’t screw tightly before all the screws are put into the corresponding holes Step 3 Put the slide tube in the chute...
- Page 6 Assembly Instructions Step 4 B x 4 pcs D x 1 pc Don’t screw tightly before all the screws are put into the corresponding holes Step 5 Please side the tube (NO.5) out if you need to open the paneol;if not ,please slide it in the chute.
- Page 7 Assembly Instructions Step 6 D x 1 pc All screws should be tightly screwed...
