Co ee Table
Assembly Instructions - Please keep for future reference
Important – Please read these instructions before assembly
If you need help or have damaged or missing parts, email:
linsyhome@outlook.com
LS209M3-A
Dimensions
Width -
43.31inch
Depth -
21.65inch
Height -
17.72inch
1
Advertisement
Table of Contents
Related Manuals for LINSY HOME LS209M3-A
Summary of Contents for LINSY HOME LS209M3-A
- Page 1 Co ee Table Assembly Instructions - Please keep for future reference LS209M3-A Dimensions Width - 43.31inch Depth - 21.65inch Height - 17.72inch Important – Please read these instructions before assembly If you need help or have damaged or missing parts, email:...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly Assemble on a soft level surface Check that if you have all the Do not stand or put weight on the to avoid damaging the unit or your components and tools listed on the product, which could cause damage.
- Page 3 Components If you need help or have damaged or missing parts, email: linsyhome@outlook.com Please check you have all the pieces listed below Part List Reference Description Speci cations(mm) Quantity Material Wide Frame 320*427*35 Steel Narrow Frame 200*427*35 Steel Upper Panel 1100*550*15 Particle board Bottom Panel...
- Page 4 Components If you need help or have damaged or missing parts, email: linsyhome@outlook.com Please check you have all the pieces listed below M6x10 x 20 pcs M6 x 4 pcs S4 x 1 pc Spare Parts Spare Parts x 1 pc Assembly Instructions Step 1 A x x 7 pcs...
- Page 5 Assembly Instructions Step 2 A x 7 pcs C x 1 pc Don’t screw tightly before all the screws are put into the corresponding holes. Step 3 A x 6 pcs B x 4 pcs C x 1 pc...
- Page 6 Assembly Instructions Step 4 C x 1 pc All screws should be tightly screwed.
