Summary of Contents for HIKVISION DS-2DF6236-CX

  • Page 1 Explosion-proof Dome User Manual...
  • Page 2 SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
  • Page 3 This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements. Warning: This is a class A product. In a domestic environment this product may cause radio inter-ference in which case the user may be required to take adequate measures. © Hikvision...
  • Page 4  Do not aim the lens at the strong light such as sun or incandescent lamp. The strong light can cause fatal damage to the product.  The sensor may be burned out by a laser beam, so when any laser equipment is being used, © Hikvision...
  • Page 5  Use a soft and dry cloth when clean inside and outside surfaces of the product cover. Do not use alkaline detergents. © Hikvision...

  • Page 6: Table Of Contents

    Configuring Recording Schedule ..................33 5.1.2 Configuring Capture Schedule ................... 35 5.1.3 Configuring Net HDD ......................36 ....................... 39 ASIC VENT ONFIGURATION 5.2.1 Configuring Motion Detection ................... 39 5.2.2 Configuring Video Tampering Alarm ................. 44 5.2.3 Configuring Video Loss ...................... 45 © Hikvision...
  • Page 7 6.3.4 Configuring Image Parameters Switch................93 ....................94 ONFIGURING YSTEM ETTINGS 6.4.1 System Settings ........................94 6.4.2 Maintenance ........................98 6.4.3 Security ..........................101 6.4.4 User Management ......................103 APPENDIX ............................107 SADP S ......................107 OFTWARE NTRODUCTION © Hikvision...

  • Page 8: Chapter 1 Overview

    In the client software, use the left key of mouse to click on the desired position in the video image and drag a rectangle area in the lower right direction, then the camera system will move the position to the center and allow the rectangle area to zoom in. Use the left key of mouse to © Hikvision...
  • Page 9 The programmable actions include: auto scan, random scan, patrol 1-8 ,pattern 1-4, preset 1-8,frame scan, panorama scan, tilt scan, day, night, reboot, PT adjust, Aux Output, etc.  Park Action This feature allows the camera to start a predefined action automatically after a period of © Hikvision...
  • Page 10 Comparing with the general 2D digital noise reduction, the 3D digital noise reduction function processes the noise between two frames besides processing the noise in one frame. The noise will be much less and the video will be clearer. © Hikvision...

  • Page 11: Chapter 2 Network Connection

    Figure 2-1.  Refer to the Figure 2-2 to set the network camera over the LAN via a switch or a router. Network Cable Network Speed Dome Computer Figure 2-1 Connecting Directly © Hikvision...

  • Page 12: Activating The Camera

    The password should be something of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product. © Hikvision...
  • Page 13 Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user.s. 4. Click Activate to start activation. You can check whether the activation is completed on the popup window. If activation failed, make sure that the password meets the requirement and © Hikvision...
  • Page 14 Get the client software from the supplied disk or the official website, and install the software according to the prompts. Follow the steps to activate the camera. Steps: Run the client software and the control panel of the software pops up, as shown in Figure 2-6. © Hikvision...
  • Page 15 Figure 2-7 Device Management Interface Check the device status from the device list, and select an inactive device. Click Activate to pop up the Activation interface. Create a password and input the password in the password field, and confirm the password. © Hikvision...
  • Page 16 Figure 2-9 Modifying the Network Parameters Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the Enable DHCP checkbox. Input the password to activate your IP address modification. © Hikvision...

  • Page 17: Optional) Setting Security Question

    Connecting the network camera with static IP directly You can also save the static IP in the camera and directly connect it to the internet without using a router. Refer to Section 2.1.2 for detailed IP address configuration of the camera. © Hikvision...

  • Page 18: Dynamic Ip Connection

    This camera supports the PPPoE auto dial-up function. The camera gets a public IP address by ADSL dial-up after the camera is connected to a modem. You need to configure the PPPoE parameters of the network camera. Refer to Section 6.1.1 Configuring PPPoE Settings for detailed configuration. © Hikvision...
  • Page 19 1. Apply a domain name from a domain name provider. 2. Configure the DDNS settings in the DDNS Settings interface of the network camera. Refer to Section 6.1.1 Configuring DDNS Settings for detailed configuration. 3. Visit the camera via the applied domain name. © Hikvision...

  • Page 20: Chapter 3 Accessing To The Network Speed Dome

    6. Install the plug-in before viewing the live video and operating the camera. Follow the installation prompts to install the plug-in. You may have to close the web browser to install the plug-in. Reopen the web browser and log in again after installing the plug-in. © Hikvision...

  • Page 21: Accessing By Client Software

    The product CD contains the client software. You can view the live video and manage the camera with the client software. Follow the installation prompts to install the client software and WinPcap. The configuration interface and live view interface of client software are shown in Figure 3-3. Figure 3-3 iVMS-4200 Control Panel © Hikvision...
  • Page 22 If you use third party VMS software, contact technical support of our branch for camera firmware.  For detailed information about client software of our company, refer to the user manual of the software. This manual mainly introduces accessing to the network camera by web browser. © Hikvision...

  • Page 23: Chapter 4 Basic Operations

    Configure the following settings:  Live View Parameters: Set the protocol type, play performance, rules and image format.  Protocol Type: TCP, UDP, MULTICAST and HTTP are selectable. TCP: Ensures complete delivery of streaming data and better video quality, yet the © Hikvision...

  • Page 24: Live View Page

    The live video page allows you to view live video, capture images, realize PTZ control, set/call presets and configure video parameters. Log in the network camera to enter the live view page, or you can click on the menu bar of the main page to enter the live view page. © Hikvision...

  • Page 25: Starting Live View

    Configure the image size, stream type, plug-in type, and two-way audio of the live video. 4.4 Starting Live View In the live view window as shown in Figure 4-3, click on the toolbar to start the live view of the network. © Hikvision...
  • Page 26 4:3/16:9/ original/self-adaptive window size.  Click to select from and display live video with the main/ sub/third stream. The main stream is with a relatively high resolution and needs much bandwidth. The default setting of stream type is © Hikvision...

  • Page 27: Operating Ptz Control

     Setting the OSD text on live video in Section 6.3.2 Configuring OSD Settings. 4.5 Operating PTZ Control Purpose: In the live view interface, you can use the PTZ control buttons to control panning, tilting and zooming. PTZ functions vary depending on different camera models. © Hikvision...

  • Page 28: Ptz Control Panel

    Click and the camera keeps PTZ Control Panel panning, the icon turns into Click the icon again to stop the camera. Click , the lens zooms in, click Zoom out/in , and the lens zooms out. © Hikvision...

  • Page 29: Auxiliary Functions

    Table 4-3 Descriptions of Buttons Buttons Description Start the selected patrol/pattern. Stop current patrol/pattern. Set the selected preset/patrol. Delete the selected preset/patrol/pattern. Start recording a pattern. Stop recording the pattern. 4.5.2 Auxiliary Functions The Auxiliary functions panel is shown in Figure 4-5. © Hikvision...
  • Page 30 For detailed information of setting one-touch patrol, refer to 4.5.5 One-touch Patrol.  One-touch Park Click to save the current view as the preset No. 32 and start park at the the current position. © Hikvision...

  • Page 31: Setting/Calling A Preset

    In the PTZ control panel, select a defined preset from the list and click to call the preset. Figure 4-7 Calling a Preset For convenient preset selection, refer to the following steps to navigate to the preset you want. © Hikvision...
  • Page 32 Call patrol 8 Figure 4-8 Special Preset You may need to use the OSD (On Screen Display) menu when controlling the camera remotely. To display the OSD menu on the live view screen, you can call the preset number © Hikvision...

  • Page 33: Setting/Calling A Patrol

    6. Repeat the steps from 3 to 5 to add more presets. 7. Click OK to save all the patrol settings.  Calling a Patrol: In the PTZ control panel, select a defined patrol from the list and click to call the patrol, as shown in Figure 4-10. © Hikvision...

  • Page 34: One-Touch Patrol

    2. Call preset No. 45, and the camera moves as patrol path 8. 3. Click to enter the patrol settings interface and start/stop one-touch patrol, edit the patrol time and the speed. 4. You can click of the PTZ control panel to start one-touch patrol. Figure 4-11 Patrol Path 8 © Hikvision...

  • Page 35: Setting/Calling A Pattern

    5. Click to save all the pattern settings.  Buttons on the Patterns interface: Buttons Description Start the selected patrol/pattern. Stop current patrol/pattern. Set the selected preset/patrol. Delete the selected preset/patrol/pattern. Start recording a pattern. Stop recording the pattern. © Hikvision...

  • Page 36: Playback

    This section explains how to view the video files stored in the network disks or memory cards. 4.6.1 Play Back Video Files Steps: Click on the menu bar to enter playback interface. Figure 4-13 Playback Interface Select the date and click © Hikvision...
  • Page 37 Drag the progress bar with the mouse to locate the exact playback point. You can also input the time and click to locate the playback point in the Set playback time field. You can also click to zoom out/in the progress bar. Figure 4-16 Set Playback Time © Hikvision...

  • Page 38: Downloading Video Files

    Check the checkbox in front of the video files that you need to download. Click to download the video files. 4.7 Pictures Purpose: This section explains how to view the captured picture files stored in the network disks or the memory cards and download the captured pictures. © Hikvision...
  • Page 39 Select the file type of capturing the pictures from the list as timing, alarm, motion, etc. Set the start time and end time. Click Search. The corresponding picture files will be listed. Check the checkbox in front of the files that you need to download. Click to download the files. © Hikvision...

  • Page 40: Chapter 5 System Configuration

    Configuration > Storage > Schedule Settings > Record Schedule Figure 5-1 Recording Schedule Interface 2. Check the checkbox of Enable to enable scheduled recording. 3. To set the advanced settings of the camera, click to enter the advanced settings interface. © Hikvision...
  • Page 41 Channel in the Linkage Method of Alarm Input settings interface. For detailed information, refer to Section Alarm Input.  Record Triggered by Motion & Alarm: If you select Motion & Alarm, the video will be recorded when the motion and alarm are triggered at the same time. Besides © Hikvision...

  • Page 42: Configuring Capture Schedule

    After you set the scheduled task, you can click and copy the task to other days (optional). After setting the capture schedule, you can click a capture segment to display the segment capture settings interface to edit the segment capture parameters. (optional) © Hikvision...

  • Page 43: Configuring Net Hdd

    Refer to Section 6.1.2 Configuring FTP Settings for more details to configure FTP parameters. Check Upload to FTP checkbox in Motion Detection Settings or Alarm Input interface. Refer to Section 5.2.1 Configuring Motion Detection. Check the Enable Event-triggered Snapshot checkbox. 5.1.3 Configuring Net HDD Before you start: © Hikvision...
  • Page 44 After having saved successfully, you need to reboot the camera to activate the settings.  Initialize the added network disk. 1. Enter the HDD settings interface (Configuration > Storage > Storage Management > HDD Management), in which you can view the capacity, free space, status, type and property of the disk. © Hikvision...
  • Page 45 Figure 5-8 Quota Settings  Up to 8 NAS disks can be connected to the camera.  To initialize and use the memory card after insert it to the camera, refer to the steps of NAS disk initialization © Hikvision...

  • Page 46: Basic Event Configuration

    You can check the Enable Dynamic Analysis for Motion checkbox if you want the detected object get marked with rectangle in the live view. Select the configuration mode as Normal or Expert and set the corresponding motion detection parameters.  Normal © Hikvision...
  • Page 47 (2) Click to finish drawing. You can click to clear all of the areas. (3) Move the slider to set the sensitivity of the detection.  Expert © Hikvision...
  • Page 48 Percentage: When the size proportion of the moving object exceeds the predefined value, the alarm will be triggered. The less the value is, the easier the alarm will be triggered. Set the Arming Schedule for Motion Detection. (1) Click tab to enter the arming schedule setting interface. © Hikvision...
  • Page 49 (optional). Figure 5-12 Arming Time Schedule (4) After setting the arming schedule, you can click a segment to display the segment arming settings interface to edit the segment record parameters (optional). Figure 5-13 Segment Arming Settings © Hikvision...
  • Page 50 Send an email with alarm information to a user or users when an event occurs. To send the Email when an event occurs, you need to refer to Section Configuring Email Settings to set the Email parameters.  Upload to FTP/Memory/NAS © Hikvision...

  • Page 51: Configuring Video Tampering Alarm

    5.2.2 Configuring Video Tampering Alarm Purpose: You can configure the camera to trigger the alarm actions when the lens is covered. Steps: 1. Enter the Video Tampering settings interface : Configuration > Event > Basic Event > Video Tampering © Hikvision...

  • Page 52: Configuring Video Loss

    Refer to Section 5.2.1 Configuring Motion Detection. 5. Click to save the settings. 5.2.3 Configuring Video Loss Steps: Enter the Video Loss setting interface: Configuration > Event > Basic Event > Video Loss © Hikvision...

  • Page 53: Configuring Alarm Input

    Configuration > Event > Basic Event > Alarm Input 2. Choose the Alarm Input No. and the Alarm Type. The alarm type can be NO (Normally Open) and NC (Normally Closed). 3. Edit the name in to set a name for the alarm input (optional). © Hikvision...
  • Page 54 6. You can also choose the PTZ linking for the alarm input. Check the relative checkbox and select the No. to enable Preset Calling, Patrol Calling or Pattern Calling. 7. You can copy your settings to other alarm inputs. 8. Click to save the settings. Figure 5-18 Linkage Method © Hikvision...

  • Page 55: Configuring Alarm Output

    Refer to Section 5.2.1 Configuring Motion Detection. Figure 5-19 Alarm Output Settings You can copy the settings to other alarm outputs. Click to save the settings. © Hikvision...

  • Page 56: Handling Exception

    2. Check the checkbox to set the actions taken for the Exception alarm. Refer to Section 5.2.1 Configuring Motion Detection. Figure 5-20 Exception Settings Click to save the settings. 5.3 Smart Event Configuration The functions vary depending on different camera models. © Hikvision...

  • Page 57: Detecting Audio Exception

    Sensitivity: Range [1-100], the smaller the value the more severe the sound change will trigger the detection. 5. Click tab to enter the arming schedule setting interface. The time schedule configuration is the same as the settings of the arming schedule for motion © Hikvision...

  • Page 58: Configuring Face Detection

    Intrusion detection can set an area in the surveillance scene and once the area is entered, a set of alarm action is triggered. Steps: 1. Enter the intrusion detection interface: Configuration > Events > Smart Event >Intrusion Detection © Hikvision...
  • Page 59  Sensitivity: Range [1-100]. The value of the sensitivity defines the size of the object which can trigger the alarm, when the sensitivity is high, a very small object can trigger the alarm. 6. Click tab to enter the arming schedule setting interface. The time © Hikvision...

  • Page 60: Configuring Line Crossing Detection

    4. The event triggered and park action related PTZ movement will be locked for 180 seconds after you enter the line crossing detection interface. Optionally, you can click the button to manually activate the movement, or lock the movement when the button turns to by clicking it. Figure 5-24 Configuring Line © Hikvision...

  • Page 61: Configuring Region Entrance Detection

    Steps: 1. Enter the Region Entrance Detection settings interface: Configuration> Event > Smart Event> Region Entrance Detection 2. Check the checkbox of Enable to enable the Region Entrance Detection function. © Hikvision...

  • Page 62: Configuring Region Exiting Detection

    5.3.6 Configuring Region Exiting Detection Purpose: Region exiting detection function detects people, vehicle or other objects which exit from a pre-defined virtual region, and some certain actions can be taken when the alarm is triggered. © Hikvision...
  • Page 63 Notify surveillance center, send email, upload to FTP, trigger channel, smart tracking and trigger alarm output are selectable. Refer to Section 5.2.1 Configuring Motion Detection. 9. Click button to save the settings. © Hikvision...

  • Page 64: Ptz Configuration

    When there is a large amount of zoom, the pan/tilt speed will be slower for keeping the image from moving too fast on the live view image.  Preset Freezing: This function enables the live view to switch directly from one scene © Hikvision...

  • Page 65: Configuring Ptz Limits

    3. Click to save the settings. 5.4.2 Configuring PTZ Limits Purpose: The speed dome can be programmed to move within the configurable PTZ limits (left/right, up/down). Steps: Enter the Limit configuration interface: Configuration > PTZ > Limit © Hikvision...

  • Page 66: Configuring Initial Position

    The initial position is the origin of PTZ coordinates. It can be the factory default initial position. You can also customize the initial position according to your own demand.  Customize an Initial Position: Steps: Enter the Initial Position configuration interface: © Hikvision...

  • Page 67: Configuring Park Actions

    Scheduled Tasks function is prior to Park Action function. When these two functions are set at the same time, only the Scheduled Tasks function takes effect.  Park function varies depending on different camera models. Steps: 1. Enter the Park Action settings interface: Configuration > PTZ > Park Action © Hikvision...

  • Page 68: Configuring Privacy Mask

    Privacy mask enables you to cover certain areas on the live video to prevent certain spots in the surveillance area from being live viewed and recorded. Steps: 1. Enter the Privacy Mask settings interface: Configuration > PTZ > Privacy Mask Figure 5-31 Draw the Privacy Mask © Hikvision...

  • Page 69: Configuring Scheduled Tasks

    5.4.6 Configuring Scheduled Tasks Purpose: You can configure the network speed dome to perform a certain action automatically in a user-defined time period. Steps: Enter the Scheduled Task settings interface: Configuration> PTZ > Scheduled Tasks Figure 5-33 Configure Scheduled Tasks © Hikvision...

  • Page 70: Clearing Ptz Configurations

    You can clear PTZ configurations in this interface, including all presets, patrols, privacy masks, PTZ limits, scheduled tasks and park actions. Steps: 1. Enter the Clearing Configuration interface: Configuration > PTZ > Clear Config 2. Check the checkbox of the items you want to clear. © Hikvision...

  • Page 71: Configuring Smart Tracking

    Figure 5-36 Configure Smart Tracking 2. Check the Enable Smart Tracking check box to enable smart tracking function. 3. Click the PTZ buttons to select an object. 4. Click to set the current zoom ratio as the tracking zoom ratio. © Hikvision...

  • Page 72: Prioritize Ptz

    3. Set the delay time (Range 2-200s). 4. Click to save the settings. 5.4.10 Position Settings Purpose: You can set the position information in this interface. Steps: 1. Enter the Position Settings interface: Configuration > PTZ > Position Settings Figure 5-37 Position Settings © Hikvision...
  • Page 73 3. After the speed dome changes its direction, you can click Point to North and the speed dome turns back to the north direction. 4. You can manually set GPS information including longitude and latitude. 5. Click to save the settings. © Hikvision...

  • Page 74: Chapter 6 Camera Configuration

    IPv6 are both supported. Steps: Enter TCP/IP settings interface: Configuration > Network > Basic Settings > TCP/IP Figure 6-1 TCP/IP Settings 2. Configure the NIC settings, including the IPv4(IPv6) Address, IPv4(IPv6) Subnet Mask and IPv4(IPv6) Default Gateway. © Hikvision...
  • Page 75 Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. Steps: 1. Enter the DDNS settings interface: Configuration > Network > Basic Settings > DDNS 2. Check the Enable DDNS checkbox to enable this feature. © Hikvision...
  • Page 76 Purpose: If you have no router but only a modem, you can use Point-to-Point Protocol over Ethernet (PPPoE) function. Steps: 1. Enter the PPPoE settings interface: Configuration > Network > Basic Settings > PPPoE Figure 6-4 PPPoE Settings © Hikvision...
  • Page 77 Server Port: The default port number is 8000. Click to save the settings. Configuring NAT (Network Address Translation) Settings Purpose: Universal Plug and Play (UPnP™) is a networking architecture that provides compatibility among networking equipment, software and other hardware devices. The UPnP protocol allows devices © Hikvision...

  • Page 78: Advanced Settings

    Before setting the SNMP, use the SNMP software and manage to receive the camera information via SNMP port. By setting the Trap Address, the camera can send the alarm event and exception messages to the surveillance center. The SNMP version you select should be the same as that of the SNMP software. © Hikvision...
  • Page 79 The configuration of the SNMP software should be the same as the settings you configure here. 4. Click to save and finish the settings. Configuring FTP Settings Purpose: You can set a FTP server and configure the following parameters for uploading captured pictures. © Hikvision...
  • Page 80  Root directory: The files will be saved in the root of FTP server.  Parent directory: The files will be saved in a folder in FTP server. The name of folder can be defined as shown in Figure 6-9. Figure 6-9 Parent Directory © Hikvision...
  • Page 81 Configure the DNS Server settings under Configuration> Network > Basic Settings > TCP/IP before using the Email function. Steps: 1. Enter the Email settings interface: Configuration> Network > Advanced Settings > Email Figure 6-11 Email Settings 2. Configure the following settings: © Hikvision...
  • Page 82 For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a minimum of 8 characters, including © Hikvision...
  • Page 83 Click OK to save the settings. OPTION 3: Create certificate request first and continue the installation. 1) Select Create certificate request first and continue the installation. 2) Click Create to create the certificate request, and fulfill the required information. © Hikvision...
  • Page 84 The valid DSCP value ranges from 0 to 63. The DSCP value is bigger, the priority is higher. 3. Click to save the settings.  Make sure that you enable the QoS function of your network device (such as a router). © Hikvision...
  • Page 85  Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. Steps: Connect the network camera to your PC directly with a network cable. Enter the 802.1X settings interface: © Hikvision...
  • Page 86 If you need to access to the camera through the third party platform, you can enable Hikvision-CGI function. And if you need to access to the device through ONVIF protocol, you can configure ONVIF user in this interface. Refer to ONVIF standard for detailed configuration rules.

  • Page 87: Configuring Video And Audio Settings

    User Manual of Explosion-proof Dome Figure 6-18 Integration Protocol Settings 2. Check the Enable Hikvision-CGI checkbox and then select the authentication from the dropdown list. Then you can access to the camera through the third party platform. 3. Check the Enable ONVIF checkbox to enable the function.
  • Page 88 Max. Bitrate: Set the Max. bitrate. The higher value corresponds to the higher video quality, but the higher bandwidth is required. Video Encoding: Select Video Encoding from the dropdown list for different stream type. H.264+/H.265+: © Hikvision...

  • Page 89: Configuring Audio Settings

    4. Click to save the settings. 6.2.2 Configuring Audio Settings Steps: 1. Enter the Audio settings interface Configuration > Video/Audio > Audio Figure 6-20 Audio Settings © Hikvision...

  • Page 90: Configuring Roi Settings

    Region is enabled, image quality of ROI area will be enhanced and image quality of other areas will be reduced. When Dynamic Region is enabled, image quality of tracking target will be enhanced. ROI function varies depending on different camera models. Enter the ROI settings interface: Configuration >Video/Audio > ROI © Hikvision...
  • Page 91 Select a stream type. You can set the ROI function for main stream, sub-stream or third stream. Click and then drag the mouse to draw a red frame in the live view image. You can click to clear it. The number of areas supported in ROI function varies depending different camera models © Hikvision...

  • Page 92: Display Info. On Stream

    You can double click the live view to enter full screen mode and double click it again to exit. Steps: 1. Enter the Display Settings interface: Configuration > Image> Display Settings 2. You can select the Scene in the dropdown list with different predefined image parameters. 3. Set the image parameters of the speed dome. © Hikvision...
  • Page 93 The iris, shutter and gain values will be adjusted automatically according to the brightness of the environment.  Iris Priority: The value of iris needs to be adjusted manually. The shutter and gain values will be adjusted automatically according to the brightness of the environment. © Hikvision...
  • Page 94 Slow Shutter Level When slow shutter is set as ON, you can select the slow shutter level from the dropdown list. The slow shutter lever can be set to Slow Shutter*2, *3, *4, *6, *8. Figure 6-27 Slow Shutter © Hikvision...
  • Page 95 In Night mode, the image is black and white. Night mode can increase the sensitivity in low light conditions.  Scheduled-Switch: In Schedule mode, you can set the time schedule for day mode as shown in Figure 6-29. The rest time out of the schedule is for night mode. Figure 6-29 Day Night Schedule © Hikvision...
  • Page 96 You can select this mode when the speed dome is installed in outdoor environment.  Indoor You can select this mode when the speed dome is installed in indoor environment.  Fluorescent Lamp You can select this mode when there are fluorescent lamps installed near the speed dome. © Hikvision...
  • Page 97 You can set the Defog Mode to ON or OFF as you need. Figure 6-34 Defog Mode  EIS (Electronic Image Stabilization) You can set theEIS to ON or OFF as you need. Figure 6-35 Electronic Image Stabilization Video Adjustment The functions vary depending on different camera models. © Hikvision...

  • Page 98: Configuring Osd Settings

    Time: Supports for time display. Camera Name: Identifies the name of camera. You can customize the on screen display of time. Steps: 1. Enter the OSD settings interface: Configuration > Image > OSD Settings Figure 6-36 OSD Settings © Hikvision...

  • Page 99: Configuring Text Overlay Settings

    2. Check the checkbox in front of textbox to enable the on-screen display. 3. Input the characters in the textbox. 4. Use the mouse to drag the red text frame Text in the live view window to adjust the text overlay position. 5. Click to save the settings. © Hikvision...

  • Page 100: Configuring Image Parameters Switch

    (Up to 4 periods can be configured for one preset.) Figure 6-38 Link to Preset Figure 6-39 Linked Scene 4. When you enable the function of Scheduled-Switch, check the corresponding checkbox, set the time period and the linked scene. Figure 6-40 Schedule-Switch © Hikvision...

  • Page 101: Configuring System Settings

    You can follow the instructions in this section to configure the time which can be displayed on the video. There are Time Zone, Time Synchronization, and Daylight Saving Time (DST) functions for setting the time. Time Synchronization consists of auto mode by Network Time Protocol (NTP) © Hikvision...
  • Page 102 210.72.145.44). If the camera is set in a customized network, NTP software can be used to establish a NTP server for time synchronization.  Configuring Time Synchronization Manually Steps: (1) Check the Manual Time Sync radio button. (2) Click to set the system time from the pop-up calendar. © Hikvision...
  • Page 103 The time will be adjusted automatically when the Daylight Saving Time (DST) comes. Steps: 1. Enter the DST interface by Configuration > Advanced Configuration > System > DST Figure 6-46 DST Settings © Hikvision...
  • Page 104 Purpose: The RS-485 serial port is used to control the PTZ of the camera. The configuring of the PTZ parameters should be done before you control the PTZ unit. RS-485 function varies depending on different speed dome models. © Hikvision...

  • Page 105: Maintenance

     Restoring Default Settings Steps: Enter the Maintenance interface: Configuration > System > Maintenance > Upgrade & Maintenance: 2. Click to restore the default settings. Clicking restores all the parameters to default settings including the IP © Hikvision...
  • Page 106 The upgrading process will take 1 to 10 minutes. Don't disconnect power of the camera during the process. The camera reboots automatically after upgrading. Log Searching Purpose: The operation, alarm, exception and information of the camera can be stored in log files. You can also export the log files on your demand. © Hikvision...
  • Page 107 3. Input a number in text field as the upper limit of the remote connection number. E.g. when you specify the remote connection number as 10, then the 11th remote connection cannot be established. Figure 6-51 Live View Connection Settings © Hikvision...

  • Page 108: Security

    Configuration > System > Security > IP Address Filter Figure 6-52 IP Address Filter 2. Check the checkbox of Enable IP Address Filter. 3. Select the type of IP Address Filter in the dropdown list, Forbidden and Allowed are © Hikvision...
  • Page 109 Check the checkbox to enable the Illegal Login Lock function. Illegal Login Lock: Enabling illegal login lock function is to automatically lock the device IP after the admin user performing 7 failed password attempts (5 attempts for the user/operator). © Hikvision...

  • Page 110: User Management

    (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product.  Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. © Hikvision...
  • Page 111 1. Left-click to select the user from the list and click 2. Modify the User Name, Level or Password. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions. 4. Click to finish the user modification. © Hikvision...
  • Page 112 Security question setting is not cleared when you restore the camera (not to default). Steps: 1. Enter setting interface: Configuration > System > User Management > User Management 2. Click Security Question. 3. Input correct admin password. 4. Select questions and input answers. 5. Click OK to save the settings. © Hikvision...
  • Page 113 You can see the current users who are visiting the device through this interface. User information, such as user name, level, IP address, and operation time, is displayed in the User List. Click Refresh to refresh the list. © Hikvision...

  • Page 114: Appendix

    Search online devices manually You can also click to refresh the online device list manually. The newly searched devices will be added to the list. You can click on each column heading to order the information; you can © Hikvision...
  • Page 115  Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. © Hikvision...
  • Page 116 User Manual of Explosion-proof Dome Figure A.1.2 Modify Network Parameters © Hikvision...
  • Page 117 UD06978B...
