Summary of Contents for HIKVISION DS-2DF6336V-AEL

  • Page 1 Network Speed Dome User Manual UD.6L0201D1827A01 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 2 SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
  • Page 3 User Manual of Network Speed Dome IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 4 (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 5 Never attempt to disassemble the product yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.)  Please do not look directly into the laser light within 6 meters because laser is hazardous to humans. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 6 Please use a soft and dry cloth when clean inside and outside surfaces of the product cover. Do not use alkaline detergents.  Improper use or replacement of the battery may result in hazard of explosion. Please use the manufacturer recommended battery type. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 7: Table Of Contents

    Configuring Smart Tracking ....................45 Configuring PTZ Control Priority ....................46 Clearing PTZ Configurations ....................47 Chapter 6 Speed Dome Configuration ..................48 Configuring Local Parameters ....................48 Configuring Time Settings......................49 Configuring Network Settings ....................52 © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 8 Configuring NAS Settings .......................99 Initializing and Configuring Storage ..................100 Configuring Recording Schedule ..................101 Configuring Snapshot Settings .....................105 Chapter 8 Playback......................... 107 Chapter 9 Log Searching ......................111 Chapter 10 Others ........................112 © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 9 Appendix 7 24VAC Wire Gauge & Transmission Distance ..............134 Appendix 8 12VDC Wire Gauge & Transmission Distance..............135 Appendix 9 Table of Wire Gauge Standards ..................136 Appendix 10 Alarm In/Out Connections ..................137 © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 10: Chapter 1 Overview

    In manual tracking mode, when a target object goes directly beneath the dome, the video will automatically flips 180 degrees in horizontal direction to maintain continuity of tracking. This function can also be realized by auto mirror image © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 11  White Balance (WB) White balance can remove the unrealistic color casts. White balance is the white rendition function of the camera to adjust the color temperature according to the © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 12 The noise will be much less and the video will be clearer.  Dual-VCA Combine the detected VCA information into the video stream, which can be used for the second-time analysis on the back-end device. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 13: Chapter 2 Network Connection

    Figure 2-1.  Refer to the Figure 2-2 to set the network speed dome over the LAN via a switch or a router. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 14: Activating The Speed Dome

    2. Input the IP address into the address bar of the web browser, and click Enter to enter the activation interface. The default IP address of the speed dome is 192.168.1.64. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 15 SADP according to the prompts. Follow the steps to activate the speed dome. Steps: 1. Run the SADP software to search the online devices. 2. Check the device status from the device list, and select an inactive device. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 16 5. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 17 Follow the steps to activate the camera. Steps: 1. Run the client software and the control panel of the software pops up, as shown in the figure below. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 18 3. Check the device status from the device list, and select an inactive device. 4. Click the Activate button to pop up the Activation interface. 5. Create a password and input the password in the password field, and confirm the password. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 19 9. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. 10. Input the password to activate your IP address modification. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 20: Setting The Network Speed Dome Over The Wan

    You can also save the static IP in the speed dome and directly connect it to the internet without using a router. Refer to Section 2.1.2 for detailed IP address configuration of the speed dome. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 21: Dynamic Ip Connection

    5. Apply a domain name from a domain name provider. 6. Configure the DDNS settings in the setting interface of the router. 7. Visit the speed dome via the applied domain name. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 22 2. Configure the DDNS settings in the DDNS Settings interface of the network speed dome. Refer to Section 6.3.4 Configuring DDNS Settings for detailed configuration. 3. Visit the speed dome via the applied domain name.  Private Domain Name Resolution © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 23 2. Access the network speed dome through the LAN with a web browser or the client software. 3. Enable DDNS and select IP Server as the protocol type. Refer to Section 6.3.4 Configuring DDNS Settings for detailed configuration. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 24: Chapter 3 Access To The Network Speed Dome

    (5 attempts for the user/operator). Figure 3-1 Login Interface 6. Install the plug-in before viewing the live video and operating the speed dome. Please follow the installation prompts to install the plug-in. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 25 User Manual of Network Speed Dome Figure 3-2 Download and Install Plug-in Figure 3-3 Install Plug-in (1) Figure 3-4 Install Plug-in (2) © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 26: Accessing By Client Software

    Follow the installation prompts to install the client software and WinPcap. The configuration interface and live view interface of client software are shown below. Figure 3-6 iVMS-4200 Control Panel © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 27  For detailed information about client software of our company, please refer to the user manual of the software. This manual mainly introduces accessing to the network speed dome by web browser. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 28: Chapter 4 Live View

    Log in the network speed dome to enter the live view page, or you can click on the menu bar of the main page to enter the live view page. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 29: Starting Live View

    Configure the image size and stream type of the live video. 4.3 Starting Live View In the live view window as shown in Figure 4-3, click on the toolbar to start the live view of the speed dome. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 30 You can double-click on the live video to switch the current live view into full-screen or return to normal mode from the full-screen. Regional Focus: Steps: 1. Click the on the toolbar to enter the regional focus operation mode. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 31 2. Click a moving object in the live video. The speed dome will track the object automatically. Please refer to the following sections for more information:  Configuring remote recording in Section 7.3 Configuring Recording Schedule. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 32: Recording And Capturing Pictures Manually

    Click the direction buttons to control the pan/tilt movements. Click the zoom/iris/focus buttons to realize lens control. Figure 4-4 PTZ Control Panel Table 4-2 Descriptions of PTZ Control Panel Button Description © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 33: Setting / Calling A Preset

    You can configure up to 300 presets.  Calling a Preset: In the PTZ control panel, select a defined preset from the list and click to call the preset. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 34 Start panorama scan Call pattern 2 Call patrol 5 Call pattern 3 Call patrol 6 Call pattern 4 Call patrol 7 Automatically Create Patrol Call patrol 8 Start to set limit stops © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 35: Setting / Calling A Patrol

    2. Select a patrol number from 3. Click to enter the adding interface of preset, as shown in Figure 4-8. Figure 4-8 Adding Presets © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 36 Description Save a patrol Call a patrol Stop a patrol Enter the adding interface of preset Modify a preset Delete a preset Delete all the presets in the selected patrol © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 37: Setting / Calling A Pattern

    Start to record a pattern. Stop recording a pattern. Call the current pattern. Stop the current pattern. Delete the current pattern. These 4 patterns can be operated separately and with no priority level.  © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 38: Configuring Live View Parameters

     Image Size: You can scale up/down the live view image by clicking . The image size can be 4:3, 16:9, original or auto. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 39: Chapter 5 Ptz Configuration

     You can click to call the initial position. You can click to delete the initial position and restore the factory default initial position. 5.2 Configuring Basic PTZ Parameters Purpose: © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 40  Zooming Speed: The zoom speed is adjustable from level 1 to 3.  Manual Control Speed: The manual control speed can be set as Compatible, Pedestrian, Non-motor Vehicle, Motor Vehicle or Self-adaptive. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 41: Configuring Ptz Limits

    Purpose: The dome can be programmed to move within the configurable PTZ limits (left/right, up/down). Steps: 1. Enter the Limit Configuration interface: Configuration > Advanced Configuration > PTZ > Limit © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 42: Configuring Scheduled Tasks

    5.4 Configuring Scheduled Tasks Purpose: You can configure the network dome to perform a certain action automatically in a user-defined time period. Steps: 1. Enter the Scheduled Task Settings interface: © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 43 (3) Click All Day to set the schedule as all day; or click Customize and input the Start Time and End Time for each task, and click Enter on your keyboard to © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 44: Configuring Park Actions

    Scheduled Tasks function takes effect. Steps: 1. Enter the Park Action Settings interface: Configuration > Advanced Configuration> PTZ > Park Action Figure 5-7 Set the Park Action © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 45: Configuring Privacy Mask

    2. Click the PTZ control buttons to find the area you want to set the privacy mask. 3. Click ; click and drag the mouse in the live video window to draw the © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 46: Configuring Smart Tracking

    Purpose: The speed dome tracks the moving objects automatically after you configure this function. Steps: 1. Enter the Smart Tracking Settings interface: Configuration > Advanced Configuration> PTZ > Smart Tracking © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 47: Configuring Ptz Control Priority

    User cannot control it. When the Operator finishes, the User can control the speed dome after the Delay time. The Delay time can be set in Priority PTZ interface as shown follows. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 48: Clearing Ptz Configurations

    1. Enter the Clearing Configuration interface: Configuration > Advanced Configuration> PTZ > Clear Config 2. Check the checkbox of the items you want to clear. 3. Click to clear the settings. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 49: Chapter 6 Speed Dome Configuration

    MULTICAST: It͛s recommended to select the protocol type to when using the Multicast function. For other information about Multicast, refer to Section 6.3.1 Configuring TCP/IP Settings. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 50: Configuring Time Settings

    Network Time Protocol (NTP) server and manual mode. To enter the Time Settings interface: Configuration > Basic Configuration > System > Time Settings Or Configuration > Advanced Configuration > System > Time Settings © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 51 National Time Center (IP Address: 210.72.145.44). If the speed dome is set in a customized network, NTP software can be used to establish a NTP server for time synchronization. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 52 The time will be adjusted automatically when the Daylight Saving Time(DST) comes. Steps: (1) Enter the DST interface by Configuration > Advanced Configuration > System > DST (2) Check to enable the DST function. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 53: Configuring Network Settings

    IPv4 and IPv6 are both supported. Steps: 1. Enter TCP/IP Settings interface: Configuration > Basic Configuration > Network > TCP/IP Or Configuration > Advanced Configuration > Network > TCP/IP © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 54 Preferred DNS Server and Alternate DNS server.  Check the checkbox of Enable Multicast Discovery, and then the speed dome can be detected by client software in the LAN. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 55: Configuring Port Settings

    Server Port: The default port number is 8000. 3. Click to save the settings. 6.3.3 Configuring PPPoE Settings Purpose: If you have no router but only a modem, you can use Point-to-Point Protocol over Ethernet (PPPoE) function. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 56: Configuring Ddns Settings

     For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 57 (4) Enter the User Name and Password registered on the DynDNS website. (5) Click to save the settings. Figure 6-12 DynDNS Settings IP Server:  Steps: (1) Enter the Server Address of the IP Server. (2) Click to save the settings. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 58: Configuring Snmp Settings

    Before you start: Before setting the SNMP, please use the SNMP software and manage to receive the speed dome information via SNMP port. By setting the Trap Address, the speed dome © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 59 Enable SNMP v3) to enable the feature. 3. Configure the SNMP settings. The configuration of the SNMP software should be the same as the settings you configure here. 4. Click to save and finish the settings. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 60: Configuring 802.1X Settings

     For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 61: Configuring Qos Settings

    1. Enter the QoS Settings interface: Configuration >Advanced Configuration > Network > QoS Figure 6-18 QoS Settings 2. Configure the QoS settings, including video / audio DSCP, event / alarm DSCP and © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 62: Configuring Ftp Settings

     For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 63: Ϊσ͕ίͽϣιίσͽ Ε΄σ΄™ ΋͋Χχίσͽν

    The UPnP protocol allows devices to connect seamlessly and to simplify the implementation of networks in the house and corporate environments. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 64: Configuring Nat (Network Address Translation) Settings

    To port mapping with the customized port numbers: Choose And you can customize the value of the port No. by yourself. Figure 6-23 Configure the Port No. 2. Click to save the settings. 6.3.11Configuring Email Settings Purpose: © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 65 Interval: The interval refers to the time between two actions of sending attached pictures. Authentication (optional): If your email server requires authentication, check this checkbox to use authentication to log in to this server and enter the login © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 66: Configuring Https Settings

    Steps: 1. Enter the HTTPS settings interface. Configuration > Advanced Configuration > Network > HTTPS 2. Create the self-signed certificate or authorized certificate. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 67 3) After receiving the signed valid certificate, import the certificate to the device. 3. There will be the certificate information after you successfully create and install the certificate. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 68 You can click configure the HTTPS port No. on your demand; refer to Section 6.3.2 Configuring Port Settings for details. 4. Check the checkbox of Enable HTTPS and click the Save button. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 69: Configuring Video And Audio Settings

    Select the resolution of the video output. Bitrate Type: Select the bitrate type to constant or variable. Video Quality: When bitrate type is selected as Variable, 6 levels of video quality are selectable. Frame Rate: © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 70: Configuring Audio Settings

    Or Configuration > Advanced Configuration > Video / Audio > Audio Figure 6-29 Audio Settings 2. Configure the following settings. Audio Encoding: G.722.1, G.711ulaw, G.711alaw, MP2L2, PCM and G.726 selectable. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 71: Configuring Roi Settings

    ROI (Region of Interest) encoding is used to enhance the quality of images which are specified in advance. Enter the ROI Settings interface: Configuration > Advanced Configuration > Video / Audio > ROI © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 72 6. Enter a Region Name and click Save to save the settings. Dynamic Region: The device can automatically calculate the region with motion.  Set the Image Quality Enhancing level for ROI encoding. Steps: © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 73: Configuring Image Settings

    Or Configuration > Advanced Configuration> Image> Display Settings 2. You can select the Mounting Scenario in the dropdown list with different predefined image parameters. 3. Set the image parameters of the speed dome. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 74 This function varies depending on the models of speed dome. Exposure Settings  Exposure Mode The Exposure Mode can be set to Auto, Iris Priority, Shutter Priority, Manual.  Auto: © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 75 The slow shutter value can be set to Slow Shutter*2, *4, *6, *12, *16, *24 and *32. Figure 6-35 Slow Shutter Focus Settings  Focus Mode The Focus Mode can be set to Auto, Manual, Semi-auto. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 76 In Schedule mode, you can set the time schedule for day mode as shown in Figure 6-37. The rest time out of the schedule is for night mode. This function varies depending on the models of speed dome. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 77 WDR balances the brightness level of the whole image and provide clear images with details. You can enable or disable the WDR function as shown in Figure 6-38. The wide dynamic level ranges from 0 to 100. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 78 In Auto-Track mode, white balance is continuously being adjusted in real-time according to the color temperature of the scene illumination. This function varies depending on the models of speed dome. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 79 You can set the Video Standard to 50hz(PAL) or 60hz(NTSC) according to the video system in your country. This function varies depending on the models of speed dome. Capture Mode: You can set the Capture Mode to OFF, 1280*720@25fps, and 1280*960@25fps. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 80: Configuring Osd Settings

    Camera Name: Identifies the name of speed dome. You can customize the on screen display of time. Steps: 1. Enter the OSD Settings interface: Configuration > Advanced Configuration > Image > OSD Settings Figure 6-41 OSD Settings © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 81: Configuring Text Overlay Settings

    3. Input the characters in the textbox. 4. Use the mouse to click and drag the red text frame in the live view window to adjust the text overlay position. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 82: Configuring And Handling Alarms

    2. Check the checkbox of the Enable Motion Detection to enable this function. You can check the Enable Dynamic Analysis for Motion checkbox if you want the detected object get marked with rectangle in the live view. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 83 • You can draw up to 8 motion detection areas on the same image. • You can click to clear all of the areas. (3) Move the slider to set the sensitivity of the detection.  Expert © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 84 The less the value is, the easier the alarm will be triggered. 4. Set the Arming Schedule for Motion Detection. (1) Click in Figure 6-46. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 85 5. Set the Alarm Actions for Motion Detection. You can specify the linkage method when an event occurs. The following contents are about how to configure the different types of linkage method. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 86 Trigger one or more external alarm outputs when an event occurs. To trigger an alarm output when an event occurs, please refer to Section 6.6.5 Configuring Alarm Output to set the alarm output parameters. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 87: Configuring Video Loss Alarm

    Please Step 3 in Section 6.6.1 Configuring Motion Detection. 5. Click to save the settings. 6.6.3 Configuring Video Tampering Alarm Purpose: You can configure the speed dome to trigger the alarm actions when the lens is © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 88: Configuring External Alarm Input

    Configuration > Advanced Configuration> Events > Alarm Input 2. Choose the alarm input No. and the Alarm Type. The alarm type can be NO (Normally Open) and NC (Normally Closed). © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 89 No. to enable Preset Calling, Patrol Calling or Pattern Calling. 7. You can copy your settings to other alarm inputs. 8. Click to save the settings. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 90: Configuring Alarm Output

    Edit Schedule Time interface. The time schedule configuration is the same as the settings of the arming schedule for motion detection. Refer to Step 2 in Section 6.6.1 Configuring Motion Detection. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 91: Handling Exception

    2. Check the checkbox to set the actions taken for the Exception alarm. Refer to Step 3 in Section 6.6.1 Configuring Motion Detection. Figure 6-54 Exception Settings 3. Click to save the settings. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 92: Detecting Audio Exception

    Refer to Step 2 in Section 6.6.1 Configuring Motion Detection. 6. Check the checkbox to select the linkage method taken for audio exception. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 93: Configuring Dual-Vca

    Steps: 1. Enter the intrusion detection interface: Configuration > Advanced Configuration > Events > Intrusion Detection 2. Check the Enable Intrusion Detection checkbox. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 94  Detection Target: You can select human, vehicle, or all (human &vehicle) as the detection target from the dropdown list. If Human is selected, only © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 95: Configuring Line Crossing Detection

    Optionally, you can click the button to manually activate the movement, or lock the movement when the button turns to by clicking it. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 96 Refer to Step 2 in Section 6.6.1 Configuring Motion Detection. 8. Check the checkbox to select the linkage method, including Notify surveillance © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 97: Configuring Face Detection

    Notify surveillance center, send email, upload to FTP, trigger channel, smart tracking and trigger alarm output are selectable. Please refer to Step 3 in Section 6.6.1 Configuring Motion Detection. 6. Click to save the settings. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 98: Region Entrance Detection

    If Human is selected, only human beings will be identified as detection objects and as well as Vehicle. 7. Click the button to set the arming schedule. Refer to Step 2 in Section 6.6.1 Configuring Motion Detection. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 99: Region Exiting Detection

    5. Click on the live video to specify the four vertexes of the detection region, and right click to complete drawing. Repeat the step to configure other regions. Up to 4 regions can be set. You can click the button to clear all pre-defined regions. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 100: Chapter 7 Record Settings

     Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 101: Initializing And Configuring Storage

    (2) If the status of the disk is Uninitialized as shown in Figure 7-3, check the corresponding checkbox to select the disk and click to start initializing the disk. Figure 7-3 Initialize Disk Figure 7-4 Initializing © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 102: Configuring Recording Schedule

    By default, the record files of scheduled recording are stored in the SD card (if supported) or in the network disk. Steps: 1. Enter the Record Schedule Settings interface: Configuration > Advanced Configuration> Storage > Record Schedule © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 103 5 seconds, the speed dome records until 11:00:05. The Post-record time can be configured as 5 s, 10 s, 30 s, 1 min, 2 min, 5 min or 10 min. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 104 Line Crossing Detection, Audio Exception Detection and All events.  Continuous If you select Continuous, the video will be recorded automatically according to the time of the schedule.  Record Triggered by Motion Detection © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 105 You can also check any of the checkboxes before the date and click (4) Click to save the settings and exit the Edit Record Schedule © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 106: Configuring Snapshot Settings

    2. Check the Enable Timing Snapshot checkbox to enable continuous snapshot, and configure the schedule of timing snapshot. Check the Enable Event-triggered Snapshot checkbox to enable event-triggered snapshot. 3. Select the quality of the snapshot. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 107 Settings interface. Please refer to Section 6.3.8 Configuring FTP Settings for more details to configure FTP parameters. 3) Check checkbox in Motion Detection Settings or Alarm Input interface. Please refer to Step 3 in Section 6.6.1 Configuring Motion Detection. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 108: Chapter 8 Playback

    Figure 8-1 Playback Interface 2. Select the date and click Figure 8-2 Search Video 3. Click to play the video files found on this date. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 109 Figure 8-4 Set Playback Time Figure 8-5 Progress Bar The different colors of the video on the progress bar stand for the different video types as shown in Figure 8-6. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 110 3. Set the start time and end time. Click Search. The corresponding picture files are listed on the left. 4. Check the checkbox in front of the files that you need to download. 5. Click to download the files. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 111 User Manual of Network Speed Dome Figure 8-8 Picture Downloading interface © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 112: Chapter 9 Log Searching

    The matched log files will be displayed on the Log interface. Figure 9-2 Log Searching 4. To export the log files, click to save the log files in your computer. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 113: Chapter 10 Others

    Operator or User. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions for the new user. 4. Click to finish the user addition. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 114 2. Modify the User Name, Level or Password. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions. 4. Click to finish the user modification. Figure 10-3 Modify a User © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 115: Configuring Authentication

    Configuration> Advanced Configuration> Security > Anonymous Visit Figure 10-4 Anonymous Visit 2. Set the Anonymous Visit permission Enable or Disable in the drop-down list to enable or disable the anonymous visit. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 116: Configuring Ip Address Filter

    Forbid the IP addresses added in the IP Address Forbidden Filter interface to log in. Allow only the IP addresses added in the IP Allowed Address Filter interface to log in. Figure 10-6 IP Address Filter © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 117: Configuring Security Service Settings

    Alarm Input and Number of Alarm Output are displayed. The information cannot be changed in this menu. It is the reference for maintenance or modification in future. Figure 10-7 Device Information 10.7Maintenance 10.7.1Rebooting the Speed Dome © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 118: Restoring Default Settings

    Or Configuration > Advanced Configuration> System > Maintenance 2. Click to select the local configuration file and then click start importing configuration file. You need to reboot the speed dome after importing configuration file. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 119: Upgrading The System

    The upgrading process will take 1 to 10 minutes. Please do not disconnect the power of the speed dome during the upgrading process. The speed dome reboots automatically after upgrading. Figure 10-10 Remote Upgrade © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 120: Configuring Rs-485

    2. Check the checkbox to enable the supplement light function, and then the light will be turned on automatically when the illumination is not enough for the video monitoring. 3. Click the button to activate the settings. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 121: Configuring Remote Connection

    E.g. when you specify the remote connection number as 10, then the 11th remote connection cannot be established. Figure 10-12 Live View Connection Settings 3. Click the button to activate the settings. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 122: Appendix

    45 seconds after it went offline.  Search online devices manually You can also click to refresh the online device list manually. The © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 123  Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. Figure A.1.2 Modify Network Parameters © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 124: Appendix 2 Port Mapping

     In the speed dome, the 8200~8210 ports change with the 8000 port with a constant value of 200. E.g. if the 8000 port is changed to 8005, then the 8200~8210 ports should be changed to 8205~8215. Example: © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 125 The port of the network speed dome cannot conflict with other ports. For example, some web management port of the router is 80. Change the speed dome port if it is the same as the management port. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 126: Appendix 3 Statics, Interference Lightning And Surge Protection

    When the speed dome is installed in environment where is relatively insulating to the earth, e.g., cement pole or cement wall, then only the control center requires proper grounded locally. Refer to © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 127 Power Power Display Power supply board Power supply board Video cable Operating center Control line Keyboard Cement pole/wall 1.5m underground Figure A.3.2 Grounding in Cement Pole/Wall Installation © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 128 Power Power Display Power supply board Power supply board Video cable Control line Operating Center Keyboard Cement pole/wall 1.5m 1.5m underground underground Figure A.3.3 Lightening-protection Grounding in Cement Pole/Wall Installation © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 129 If the fiber optics, lightening protector or other device are applied during the transmission of speed dome, such devices as well as the video cables routing through must be proper grounded. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 130: Appendix 4 Waterproof

    Make sure that the L-shape pole mount is designed with a certain inclination angle as shown in following figure. Water won͛t flow from the pole into the speed dome with the inclination angle. θ Figure A.4.1 Customized Mount © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 131: Appendix 5 Bubble Maintenance

    1. Wipe off the water-drop or oil by soft cloth and dry the bubble. 2. Use oil free cotton cloth to wipe the bubble with alcohol or detergent. 3. Change the cloth to wipe the bubble until the bubble is clean. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 132: Appendix 6 Rs485 Bus Connection

    RS485 industry standard so that it will lead to some problems such as signal reflection, anti-jamming ability decline when the devices are faraway. At this time, the dome will be uncontrollable, or self-running, etc. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 133 3. Reconnect the RS485 wire remotely. disconnected. tightly. 4. RS485 wire is broken. 4. Change a RS485 wire. The speed 1. Reconnect the RS485 wire 1. The connection is loose. dome can tightly. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 134 3. The speed dome is too far away 3. Add a terminal resistor. smoothly. from the remote control device. 4. Too many speed domes are 4. Add a RS485 distributor. connected. © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 135: Appendix 7 24Vac Wire Gauge & Transmission Distance

    55(16) 139(42) 20(6) 32(9) 51(15) 129(39) 18(5) 30(9) 47(14) 120(36) 17(5) 28(8) 44(13) 113(34) 16(4) 26(7) 42(12) 106(32) 15(4) 25(7) 39(11) 100(30) 14(4) 23(7) 37(11) 95(28) 14(4) 22(6) 35(10) 90(27) © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 136: Appendix 8 12Vdc Wire Gauge & Transmission Distance

    21(6) 56(16) 8.1(2.3) 13(4) 20(6) 51(15) 7.5(2.1) 11.8(3.4) 18(5) 47(14) 7(2) 11(3.1) 17(5) 44(13) 6.5(1.9) 10.2(2.9) 16(4) 41(12) 6.1(1.7) 9.6(2.7) 15(4) 39(11) 5.7(1.6) 9(2.6) 14(4) 36(10) 5.4(1.5) 8.5(2.4) 13(4) 34(10) © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 137: Appendix 9 Table Of Wire Gauge Standards

    Bare Wire British Wire Wire Gauge Area of Bare Gauge(mm) Gauge SWG Wire(mm 0.750 0.4417 0.800 0.5027 0.900 0.6362 1.000 0.7854 1.250 1.2266 1.500 1.7663 2.000 3.1420 2.500 4.9080 3.000 7.0683 © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 138: Appendix 10 Alarm In/Out Connections

     For DC power supply (left diagram), the input voltage must be no more than 30VDC, 1A.  For AC power supply, the external relay must be used (right diagram) to prevent damages to the speed dome and avoid risk of electric shock. 0503001050326 © Hikvision Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 139 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

Table of Contents
