Washroom Dispenser Service and Parts Manual
Tork Elevation H2 Xpress Mini Towel Dispenser
552120, 552228
H2 Xpress Towel Product Options:
100297 - Tork Xpress Premium Extra Soft Multifold Hand Towel, 4-Panel
101293 – Tork Advanced Multifold Hand Towel, 3-Panel
420580 - Tork Premium Multifold Hand Towel, 3-Panel
424824 - Tork Advanced Multifold Hand Towel, 3-Panel
424874 - Tork Advanced Multifold Hand Towel, 3-Panel
Essity Internal
Essity Internal
Tork Elevation H2 Xpress M ini
Tow el Dispenser (216 capacity):
H2 Xpress System: 552120 (white),
552228 (black)
Dispenser Dimensions HxWxD Inches (cm):
11.6 x 11.9 x 4.0 (29.5 x 30.2 x 10.1 cm)
1 of
7
Revision Date: 10-21-19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Elevation H2 Xpress Mini and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tork Elevation H2 Xpress Mini

  • Page 1 11.6 x 11.9 x 4.0 (29.5 x 30.2 x 10.1 cm) H2 Xpress Towel Product Options: 100297 - Tork Xpress Premium Extra Soft Multifold Hand Towel, 4-Panel 101293 – Tork Advanced Multifold Hand Towel, 3-Panel 420580 - Tork Premium Multifold Hand Towel, 3-Panel...
  • Page 2 Washroom Dispenser Service and Parts Manual Tork Elevation H2 Xpress Mini Towel Dispenser 552120, 552228 Revision Date: 10-21-19 Parts Part Description Replacement SKU H2 ELEV MINI HOOD 225522A (W hite) 205502 ELEVATION LOCK (W hite) 200260 KEY FOR ALL 200260 KEY...
  • Page 3 Washroom Dispenser Service and Parts Manual Tork Elevation H2 Xpress Mini Towel Dispenser Revision Date: 10-21-19 552120, 552228 Mounting and Filling Instructions Installation instruction sheet and mounting template are provided inside each carton. ?··- : "? 120cm e$oo < h ·...
  • Page 4 Washroom Dispenser Service and Parts Manual Tork Elevation H2 Xpress Mini Towel Dispenser Revision Date: 10-21-19 552120, 552228 Preventive M aintenance The dispenser should be cleaned an y tim e there is heavy paper dust build-up inside the dispenser. If paper dust is not a problem, approxim ately ever y year is a good frequency for cleanings.
  • Page 5 To contact the Essity Quality Coordinator, dial 1-866-722-6659 and press 6. If asked for the date code on the dispenser, see instructions below. Product Date Code Location: The assembly date code for the product can be found on the Tork Select label affixed to the inside back of the dispenser.
  • Page 6 Washroom Dispenser Service and Parts Manual Tork Elevation H2 Xpress Mini Towel Dispenser Revision Date: 10-21-19 552120, 552228 552120 - T ork Elevation H2 Xpress M ini Hand Tow el Dispenser Mounting Hole Dimensions (mm) Recommend ed M ounting Height (standard access) Bottom of towel dispenser to be located 47.25”...
  • Page 7 High and Low - Side Reach Limits Under 4.4.1, the Elevation H2 Xpress Mini dispenser can be located on an y wall surface because it protrudes 4” or less. It will com ply with ADAAG regulations as long as it is m ounted at the appropriate height for the approach specified above.
