Board description and configuration

The board allows tuning several design parameters, giving the possibility to evaluate and optimize the
performance and switching characteristics of the power stage.
The user can select and mount the power switch of choice either in TO-220 or TO-247 package; the board also
allows installing an optional heatsink.
The demonstration board can be populated with isolated DC-DC converters in the standard SIP7 package to
supply the gate driving section, which significantly reduce the effort to supply the system and allow fast and easy
evaluation of the gate driving performances.
The board is compatible with the whole STGAP2S family in SO-8 package, so it is possible to evaluate the part
number of interest just by replacing the gate driver.
Figure 2 shows the position of the main components and connectors on the board.
Input signals and
logic supply
screw connector
JP5, JP6, JP7
Input signals
conf guration
JP22, R17, D2
VDD logic supply
conf guration
Input signals and
logic supply
stripconnector
UM2754 - Rev 1
Figure 2. Main components and connectors position
JP1, JP17
HS gate voltage
conf guration
U6 J2
isolated DCDC VH HS
converter for HS power supply connector
J10
J9
U1 U5 J1
LS isolated DCDC VH LS
STGAP2S converter for LS power supply connector
CN5 CN6 CN3
OUT HV GNDPWR
terminal terminal terminal
U2 HS
LS
STGAP2S
JP12, JP18
LS gate voltage
conf guration
UM2754
Board description and configuration
C2
HV bus
capacitor
JP8, JP9
HS gate resistor
conf guration
D3
Bootstrap
diode
JP10, JP11
LS gate resistor
conf guration
