UM2164
User manual
EVAL-L9960/L9960T
Introduction
The EVAL-L9960 and EVAL-L9960T are evaluation boards designed to provide the user a
platform for the L9960 and L9960T, that are integrated H-Bridge (Twin for L9960T) for
resistive and inductive loads for automotive applications, such as throttle control actuators
or exhaust gas recirculation control valves.
The board offers all the main input/output capabilities needed to drive a DC motor properly
and to provide diagnostic functionalities.
Full diagnostic is available through SPI. By using SPI communication, it is possible to
program L9960 and L9960T while the application is running (e.i. set the current limitation).
A dedicated pin array allows connecting easily a SPC5 discovery+ board and the EVAL-
L9960/L9960T. In association with the discovery board SPC560P-DISP a dedicated SW
allows controlling a motor control application by using a PC via a USB port.
The device is an integrated H-Bridge for resistive and inductive loads for automotive
applications, such as throttle control actuators or exhaust gas recirculation control valves.
The driving strategy is enhanced by configurable PWM / DIR pins as IN1/IN2.The H-Bridge
contains integrated free-wheel diodes. In case of freewheeling conditions, the low side or
the high side transistor is switched on in parallel of its diode to reduce power dissipation.
The integrated Serial Peripheral Interface (SPI) allows device parameters adjustment and to
control all operating modes and read out diagnostic information.
Detailed failure diagnostics on each channel is provided via SPI: short circuit to battery,
short circuit to ground, short circuit overload, over temperature. Open-load can be detected
in ON condition, for the widest application ranges.
The EVAL-L9960 and EVAL-L9960T boards are suitable for both beginners and expert
users working in standalone mode connected with any control system or combined with all
SPC5 Discovery+ boards through a computer graphic interface or though embedded
application examples.
The board is compatible with both 5V and 3.3V control systems
June 2017
DocID030232 Rev 2
1/19
www.st.com
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ST EVAL-L9960
Summary of Contents for ST EVAL-L9960
- Page 1 EVAL-L9960/L9960T Introduction The EVAL-L9960 and EVAL-L9960T are evaluation boards designed to provide the user a platform for the L9960 and L9960T, that are integrated H-Bridge (Twin for L9960T) for resistive and inductive loads for automotive applications, such as throttle control actuators or exhaust gas recirculation control valves.
-
Page 2: Table Of Contents
EVAL-L9960 & L9960T: board description ..... . . 6 EVAL-L9960 & EVAL-L9960T ........6 EVAL- L9960 / L9960T . - Page 3 UM2164 List of tables List of tables Table 1. Jumpers descriptions ............8 Table 2.
- Page 4 EVAL-L9960 & EVAL-L9960T schematic ........
-
Page 5: Hardware Description
Application Block Diagram Figure 1. Application Block Diagram A dedicated connector allows plugging the EVAL-L9960/L9960T in a SCP5 Discovery+ board easily. Further microcontroller boards can be connected to drive the evaluation boards by using an adaptor. DocID030232 Rev 2... -
Page 6: Eval-L9960 & L9960T: Board Description
EVAL-L9960 & L9960T: board description UM2164 EVAL-L9960 & L9960T: board description EVAL-L9960 & EVAL-L9960T Figure 2. EVAL-L9960 Figure 3. EVAL-L9960T 6/19 DocID030232 Rev 2... -
Page 7: Figure 4. Gate Driver Board (L9907) - Components And Connectors - Top View
UM2164 EVAL-L9960 & L9960T: board description Figure 4. Gate driver board (L9907) - components and connectors - top view DocID030232 Rev 2 7/19... -
Page 8: Eval- L9960 / L9960T
EVAL-L9960 & L9960T: board description UM2164 EVAL- L9960 / L9960T 2.2.1 Jumper description Table 1. Jumpers descriptions Name Description Type Vcc source jumper: Configurable two positions - 2-1= VcCC5= Vcc Micro jumper - 3-2= VDD5 (L7805CDT-TR) Vcc source jumper: - 2-1= VDDIO= VDD5... -
Page 9: Figure 5. Spc56 Discovery + Connector
UM2164 EVAL-L9960 & L9960T: board description Table 2. Connector & Device description (continued) J4_1,J4_2 Microcontroller connector Multipin L9960 / L9960T POWERSSO36 5V Voltage Regulator L7805CDT-TR DPAK 3,3 V Voltage Regulator LD1117DT33CTR DPAK Figure 5. SPC56 Discovery + Connector Figure 6. Motor A Connector... -
Page 10: L9960T Spi Configurator
EVAL-L9960 & L9960T: board description UM2164 Figure 7. Motor B Connector 2.2.3 L9960T SPI configurator Figure 8. L9960T SPI configurator Test Point description I: Input, O: Output 10/19 DocID030232 Rev 2... -
Page 11: Table 3. Test Point Description
UM2164 EVAL-L9960 & L9960T: board description Table 3. Test point description Pin Name Description I/O Type Name Protected Battery supply VDD5 VDD5 5V Supply Input VCC5 VCC5 5V Supply Input Micro 3,3V Supply Input 3V3_uC 3,3V Supply Input Micro VDDIO... -
Page 12: Functional Description
Jumper setting using L9960 & SPC5 Discovery+ board Table 4. Jumpers setting using L9960 Name Description Configuration Motor A Connector Motor A Motor B Connector Not Present on EVAL-L9960 VS Connector VS Connector SPC Discovery+ or other Microcontroller SPC Discovery+ or other Connector Microcontroller VCC Selector... - Page 13 UM2164 Functional description Table 5. Jumpers setting using L9960T (continued) Name Description Configuration CSN2 Selector 1-2= CSN2=CSN1 SDI2 Selector 1-2= SDI2=SDI1 SCK2 Selector 1-2= SCK2=SCK1 SDO2 Selector 1-2= SDO2=SDO1 NDIS2 pull down resistor Selector OPEN (No NDIS2 pull down resistor) NDIS1 pull down resistor Selector OPEN (No NDIS1 pull down resistor) DIS2 pull up resistor Selector...
-
Page 14: Getting Started With Eval-L9960 & Eval-L9960T
UM2164 Getting started with EVAL-L9960 & EVAL-L9960T A dedicated Graphical User Interface (GUI) is available to set and control the EVAL-L9960 & EVAL-L9960T board (ETC H/Bridge motor application boards for L9960) through the SPI protocol, manage the DIS, NDIS and IN2 pins and send PWM to IN1 pins. -
Page 15: Appendix A Board Layout
UM2164 Board layout Appendix A Board layout EVAL-L9960 & EVAL-L9960T PCB Layout Figure 9. PCB Layout – Top view DocID030232 Rev 2 15/19... -
Page 16: Figure 10. Gate Driver Board - Pcb Layout - Bottom View
Board layout UM2164 Figure 10. Gate driver board - PCB Layout – Bottom view 16/19 DocID030232 Rev 2... -
Page 17: Eval-L9960 & Eval-L9960T Schematic
UM2164 Board layout EVAL-L9960 & EVAL-L9960T schematic Figure 11. EVAL-L9960 & EVAL-L9960T schematic HE ADE R 2x34 HE ADE R 2x34 1N4007 VIGN L M217M V _ADJ V CC1 PWM_L1 PWM_L2 100K VIGN VIGN2 PWM_L3 10/1W 1N4007 L E D... -
Page 18: Revision History
Revision history UM2164 Revision history Table 6. Document revision history Date Revision Changes 30-Jan-2017 Initial release. 13-Jun-2017 Typo. 18/19 DocID030232 Rev 2... - Page 19 ST products and/or to this document at any time without notice. Purchasers should obtain the latest relevant information on ST products before placing orders. ST products are sold pursuant to ST’s terms and conditions of sale in place at the time of order acknowledgement.
