AM-2
MANUAL
It is important that you read this manual before attempting the installation of your
battery. Please take note of certain steps to ensure correct inverter compatibility.
Please visit
https://www.hubblelithium.co.za
WARNING:
Working with high voltage systems is dangerous. Do not attempt to modify
your inverter and battery setup unless you are certain you understand the risk.
Speak to a qualified electrician if you are unsure.
V 2.0
for the latest version of this manual.
Advertisement
Table of Contents
Related Manuals for Hubble LITHIUM AM Series
Summary of Contents for Hubble LITHIUM AM Series
- Page 1 V 2.0 AM-2 MANUAL It is important that you read this manual before attempting the installation of your battery. Please take note of certain steps to ensure correct inverter compatibility. Please visit https://www.hubblelithium.co.za for the latest version of this manual. WARNING: Working with high voltage systems is dangerous.
- Page 2 INDEX am2 WIRE DIAGRAM section 1 installation multiple batteries communication ports section 2 INVERTER SETUP Section 3 led indicators section 4 bms & maintenance section 5 completing setup Watch the AM-2 Installation Tutorial on Youtube: https://youtu.be/F5inYAPw2qg...
-
Page 3: Wire Diagram
AM-2 WIRE DIAGRAM 1. Cover 2. Hanging Ear 3. Handle 4. Output Terminal 5. Cooling Case 6. Power Switch 7. Communication Interface 8. Reset Switch 9. LED Lights... -
Page 4: Installation
Rawl boats to secure the unit to the wall. DC ISOLATOR The Hubble AM series of batteries has an integrated electronic circuit breaker built into the BMS. The integrated electronic CB is for protecting the battery and the internal cells against overload, over current, over volt etc. - Page 5 multiple batteries To connect multiple batteries, ensure you use the supplied RJ45 to RJ45 (standard LAN cable) and plug the one end into the master “Battery Link”, and the other end into battery NOTE: BATTERY LINK CABLE #2. Continue this step until all the batteries has been linked up If you do not have a battery link cable or the cable provided is an insufficient length, you can use a...
- Page 6 GROUND OPTIONAL CLOUDLINK DEVICE The Hubble Cloudlink is an optional add-on to the Hubble X and AM range of products. As long as the device is connected to Wi-Fi it will cloud, all battery and inverter data to our cloud-server, enabling users to remotely monitor their power system.
- Page 7 If you do not have this information, we list select inverter pin layouts under “Inverter Guides” website: https://www.hubblelithium.co.za/ The below is the pin configuration for the Hubble battery CAN cable: 2 3 4 5 6 7 8 DEFINITION PLEASE NOTE: INVERTER SETUP GUIDES If you are setting up a non-axpert...
-
Page 8: Led Indicators
SECTION 3 led indicators LED OPERATION STATUS NORMAL / SOC INDICATION LEDS STATUS ALARM / REMARK PROTECTION POWER OFF Sleep All off STANDBY Normal Fash 1 Indication by SOC Standby state Alarm Flash 1 Flash 3 Cell low voltage Normal ALM LED off when Indication by SOC Cell Over-charge... - Page 9 MAINTENANCE The Hubble BMS will protect the battery and lifespan of your battery as best possible. However, it must be noted that proper operation of the battery is recommended, and maintenance functions should be taken to ensure the maximum life of your batteries.
-
Page 10: Completing Setup
SECTION 5 completing setup CONGRATULATIONS! Once all the above steps have been completed you can proceed to follow the start-up instructions given by your inverter manufacturer. If you have any difficulties with setting up your system, please contact our Technical Support Department via support@hubblelithium.co.za.
