- Page 1 AM-2 MANUAL + SETTINGS + COMMUNICATION + TROUBLESHOOTING...
-
Page 2: Table Of Contents
AM-2 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ INDEX INDEX _______________________________________________________________________________________________ 2 AM-2 WIRE DIAGRAM ________________________________________________________________________________ 3 INSTALLATION _______________________________________________________________________________________ 4 MULTIPLE BATTERIES ________________________________________________________________________________ 5 COMMUNICATION PORTS ____________________________________________________________________________ 7 INVERTER SETUP ____________________________________________________________________________________ 8 LED INDICATORS ___________________________________________________________________________________ 10 BMS & MAINTENANCE _______________________________________________________________________________ 11 COMPLETING SETUP ________________________________________________________________________________ 12 It is important that you read this manual before attempting the installation of your battery. -
Page 3: Am-2 Wire Diagram
AM-2 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ AM-2 WIRE DIAGRAM COVER 2. HANGING EAR 3. HANDLE 4. OUTPUT TERMINAL 5. COOLING CASE 6. POWER SWITCH 7. COMMUNICATION INTERFACE 8. RESET SWITCH LED LIGHTS... -
Page 4: Installation
This product may only be installed by a qualified electrician. The unit is not designed to be installed upside down or sideways on a wall. The AM-2 is designed to be wall-mounted or installed flat inside a cabinet. When installing on a wall ensure you use Rawl boats to secure the unit to the wall. -
Page 5: Multiple Batteries
AM-2 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ MULTIPLE BATTERIES To connect multiple batteries, ensure you use the supplied RJ45 to RJ45 (standard LAN cable) and plug the one end into the master “Battery Link”, and the other end into battery #2. Continue this step until all the batteries have been linked up. - Page 6 AM-2 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ CORRECT METHODS OF BATTERY LINKING NOTE: DIAGRAM 1 Maximum of 2 batteries in parallel or maximum inverter current not exceeding 250Amps. NOTE: DIAGRAM 2 The preferred method for battery paralleling is to connect each parallel battery to a busbar. Ensure all cables are the same length from each battery and ensure the cable thickness are all the same to ensure even distribution of current and load.
-
Page 7: Communication Ports
OPTIONAL CLOUDLINK DEVICE The Hubble Cloudlink is an optional add-on to the Hubble X and AM range of products. If the device is connected to Wi-Fi, it will connect all battery and inverter data to our cloud-server, enabling users to remotely monitor their power system. -
Page 8: Inverter Setup
The AM series models have an integrated CAN bus port on each battery. The CAN bus can be used to connect to any inverter that is CAN bus ready. The Hubble Energy range of lithium batteries with CAN bus port can integrate with most leading inverters. For more information on CAN bus and compatible inverters see our website at www.hubbleenergy.com... - Page 9 If you are setting up a non-Axpert type inverter, for example Deye or Sunsynk - please navigate to the Inverter Setup Guides tab on our website and select the correct corresponding inverter guide. The below is the pin configuration and reference image for the Hubble battery CAN cable: Definitions...
-
Page 10: Led Indicators
AM-2 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ LED INDICATORS LED OPERATION STATUS SOC Indication LED Normal/Ala Status Remarks /Protection Power Off Sleep All Off Normal Flash 1 Standby State Standby Indication by SOC Alarm Flash 1 Flash 3 Cell Low Voltage Normal... -
Page 11: Bms & Maintenance
MAINTENANCE The Hubble BMS will protect the battery and lifespan of your battery as best possible. However, it must be noted that proper operation of the battery is recommended, and maintenance functions should be taken to ensure the maximum life of your batteries. -
Page 12: Completing Setup
AM-2 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ COMPLETING SETUP CONGRATULATIONS! Once all the above steps have been completed you can proceed to follow the start-up instructions given by your inverter manufacturer. If you have any difficulties with setting up your system, please contact our Technical Support Department via https://www.hubbleenergy.com/.
