AM-4
MANUAL
It is important that you read this manual before attempting the installation of your
battery. Please take note of certain steps to ensure correct inverter compatibility.
Please visit
https://www.hubblelithium.co.za
WARNING:
Working with high voltage systems is dangerous. Do not attempt to modify
your inverter and battery setup unless you are certain you understand the risk.
Speak to a qualified electrician if you are unsure.
V 1.0
for the latest version of this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AM-4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hubble AM-4

Summary of Contents for Hubble AM-4

  • Page 1 V 1.0 AM-4 MANUAL It is important that you read this manual before attempting the installation of your battery. Please take note of certain steps to ensure correct inverter compatibility. Please visit https://www.hubblelithium.co.za for the latest version of this manual.

  • Page 2: Table Of Contents

    INDEX am-4 WIRE DIAGRAM section 1 installation multiple batteries communication ports Section 2 led indicators section 3 bms & maintenance section 4 completing setup...

  • Page 3: Am-4 Wire Diagram

    AM-4 WIRE DIAGRAM 1. Cover 2. Hanging Ear 3. Handle 4. Output Terminal 5. Cooling Case 6. Power Switch Communication Interface 8. Reset Switch 9. LED Lights...

  • Page 4: Installation

    The AM-4 is designed to be wall mounted or installed flat inside a cabinet. The unit is not designed to be installed upside down or sideways on a wall. When installing on a wall ensure you use Rawl bolts to secure the unit onto the wall.

  • Page 5: Multiple Batteries

    multiple batteries To connect multiple batteries, ensure you use the supplied RJ45 to RJ45 (normal LAN cable) and plug the one end into the master “Battery Link”, and the other end into battery #2. NOTE: BATTERY LINK CABLE Continue this step until all the batteries have been linked up.

  • Page 6: Communication Ports

    The The AM series models has an integrated CAN bus port on each battery. The CAN bus can be used to connect to any inverter that is CAN bus ready. The Hubble range of lithium batteries with CAN bus port can integrate with most leading inverters. For more information on CAN bus and compatible inverters see our website at www.hubblelithium.co.za...

  • Page 7: Led Indicators

    SECTION 2 led indicators LED OPERATION STATUS LED FLASH STATUS When battery is turned on you can reset the BMS operation mode to default to clear a temporary alarm status. Push the switch for 6 seconds, the BMS will reset. LEDs will flash one at the same.

  • Page 8: Bms & Maintenance

    MAINTENANCE The Hubble BMS will protect the battery and life of your battery as best possible. However, it must be noted that proper operation of the battery is recommended, and maintenance functions should be taken to ensure the maximum life of your batteries.

  • Page 9: Completing Setup

    SECTION 4 completing setup CONGRATULATIONS! Once all the above steps have been completed you can proceed to follow the start-up instructions given by your inverter manufacturer. If you have any difficulties with setting up your system, please contact our Technical Support Department via support@hubblelithium.co.za.
