AM-10
MANUAL
It is important that you read this manual before attempting the installation of your
battery. Please take note of certain steps to ensure correct inverter compatibility.
Please visit
www.hubblelithium.co.za
WARNING:
Working with high voltage systems is dangerous. Do not attempt to modify
your inverter and battery setup unless you are certain you understand the risk.
Speak to a qualified electrician if you are unsure.
V 1.0
for the latest version of this manual.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hubble AM-10
Summary of Contents for Hubble AM-10
- Page 1 V 1.0 AM-10 MANUAL It is important that you read this manual before attempting the installation of your battery. Please take note of certain steps to ensure correct inverter compatibility. Please visit www.hubblelithium.co.za for the latest version of this manual.
- Page 2 INDEX product description product Specifications PARALLEL CONNECTION OF BATTERIES installation notes interface definiton interface FUNCTIONS PARALLEL FUNCTIONS warnings COMPLETING SETUP...
- Page 3 Product description SMART TECHNICAL SPECIFICATIONS Every module is equiped with an Model AM-10 independent BMS Battery Type LiFePO4 (LFP) system. Norminal Voltage (V) 51.2V Norminal Energy (KWH) 10KWH EASY Design Capacity 200AH INSTALLATION Design Years 15 Years Just plug & play.
-
Page 4: Power Switch
INTERFACE & SIZE POWER SWITCH DRY CONTACT RESET ADDRESS RS485 RS232 BATTERY LINK BATTERY + BATTERY -... -
Page 5: Connection Of Batteries
PARALLEL CONNECTION OF BATTERIES Connect the positive pole and positive pole in parallel, and the negative pole and negative pole in parallel, as shown in the figure below: INVERTER SOLUTION DIAGRAM:... - Page 6 2. As shown in the figure below, fix the attached six expansion bolts in the opening of the mounting structure, and tighten the nuts on the bolts. 3. Lift up the AM-10 battery carefully and hook it into position securely onto the wall mount bracket. BOX PENDANT OPENING POSITION...
- Page 7 TABLE 1 LED WORKING STATUS INDICATION SOC INDICATION LEDS NORMAL / ALARM STATUS REMARK / PROTECTION POWER OFF Dormancy All off Normal Fash 1 Standby state STANDBY According to the electricity instruction Alarm Flash 1 Flash 3 Cell low voltage Normal Lighting OFF According to the electricity instruction...
- Page 8 table 4 dual switch position ADDRESS CODES THE SWITCH POSITION...
- Page 9 interface definition DIAGRAM OF THE COMMUNICATION INTERFACE RS232 communication port definition: INTERFACE DEFINED DECLARATION PIN 1 NC (empty) PIN 2 NC (empty) PIN 3 TX protection board sends data (computer RJ12, RS232 pin layout receiving data foot) PIN 4 RX protection board receives data (computer sends data) PIN 5 Ground signal ground...
- Page 10 RS485-2 COMMUNICATION INTERFACE DEFINITION: INTERFACE DEFINED DECLARATION DEFINED DECLARATION PIN 1 RS485-B2 PIN 1 RS485-B2 PIN 2 RS485-A2 PIN 2 RS485-A2 PIN 3 RS485-GND PIN 3 RS485-GND Battery A part B part link ports RS-485-2 RS-485-2 PIN 4 NC (empty) PIN 4 NC (empty) Interface...
- Page 11 FUNCTIONS WARNING Interfacing or plugging in any 3rd party or non approved Hubble products or periphirals into the RS232 (serial) or RS485 (Battery Link) ports, can cause damage to the BMS and cause the BMS to malfunction. This may also result in damaging the internal cells. Plugging in non approved Hubble products into these ports can immediately void your warranty.
-
Page 12: Current Limiting Function
OPTIONAL CLOUDLINK DEVICE The Hubble Cloudlink is an optional add-on to the Hubble X and AM range of products. As long as the device is connected to Wi-Fi it will cloud, all battery and inverter data to our cloud-server, enabling users to remotely monitor their power system. - Page 13 PARALLEL FUNCTIONS PARALLEL (CASCADE) FUNCTION OF BATTERY PACKS When the battery packs are cascaded, the one with the communication address of 0001 is called the master battery pack, and the other ones with the communication address are called the slave battery packs.
- Page 14 warning TO ENSURE PROPER USE OF THE BATTERY PLEASE READ THE MANUAL CAREFULLY BEFORE USING IT. HANDLING Do not expose the battery to fire. Do not place the battery in a charger or equipment with wrong terminals connected. Avoid shorting circuiting the battery . Avoid excessive physical shock or vibration.
- Page 15 COMPLETING SETUP CONGRATULATIONS! Once all the above steps have been completed you can proceed to follow the start-up instructions given by your inverter manufacturer. If you have any difficulties with setting up your system, please contact our Technical Support Department via support@hubblelithium.co.za. Be sure to include the following information in your initial email so that we can provide you with timely assistance: 1.
