Summary of Contents for Hubble AM-5

  • Page 1 AM-5 MANUAL + SETTINGS + COMMUNICATION + TROUBLESHOOTING...
  • Page 2: Table Of Contents

    AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ INDEX INDEX _______________________________________________________________________________________________ 2 PRODUCT DESCRIPTION _____________________________________________________________________________ 3 INTERFACE & SIZE ___________________________________________________________________________________ 4 PARALLEL CONECTION OF BATTERIES _______________________________________________________________ 5 INSTALLATION NOTES _______________________________________________________________________________ 7 INTERFACE DEFINITION ____________________________________________________________________________ 10 INTERFACE FUNCTIONS ____________________________________________________________________________ 14 PARALLEL FUNCTIONS _____________________________________________________________________________ 16...
  • Page 3: Product Description

    AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ PRODUCT DESCRIPTION SMART - Every Module is equipped with an Independent BMS System EASY INSTALLATION - Just Plug & Play SAFE - Safe Lithium Iron Phosphate Battery Cell CERTIFIED - CE IEC UN38.3 MSDS MODULAR -...
  • Page 4: Interface & Size

    AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ INTERFACE & SIZE POWER SWITCH 2. BATTERY LINK 3. BATTERY LINK 4. RS232 5. CAN/RS485 -External Communication 6. DRY CONTACT 7. ADD 8. RST BATTERY + 10. BATTERY - BRACKET PLACEMENT...
  • Page 5: Parallel Conection Of Batteries

    AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ PARALLEL CONECTION OF BATTERIES Connect the positive pole and positive pole in parallel, and the negative pole and negative pole in parallel, as shown in the figure below: CORRECT METHODS OF BATTERY LINKING NOTE: DIAGRAM 1 Maximum of 4 batteries in parallel or maximum inverter current not exceeding 250Amps.
  • Page 6 AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ SOLUTION DIAGRAM INVERTER LIST SOLIS SOFAR SOLAR VICTRON LUXPOWER GROWATT HAUWEI DEYE EPEVER SUNSYNK SUNGROW SOLAR EDGE ANERN MUST SCHNEIDER KSTAR SOL ARK INVT VOLTRONIC POWER SOLAX MPP SOLAR STUDER OUTBACK POWER ENPHASE...
  • Page 7: Installation Notes

    AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ INSTALLATION NOTES As shown in the figure below, press the mounting structure on the wall surface, use a marker to draw the installation positioning hole of the fixed pendant, remove from wall and drill the holes.
  • Page 8 AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ LED WORKING STATUS INDICATION Normal Ala SOC Indication LED Status Remarks Protection Power Off Sleep All Off Normal Flash 1 Standby State Standby Indication by SOC Alarm Flash 1 Flash 3 Cell Low Voltage ALM LED OFF when...
  • Page 9 AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ DUAL SWITCH POSITION Address Switch Positions Remark Master Battery 2 Battery 3 Battery 4 Battery 5 Battery 6 Battery 7 Battery 8 Battery 9 Battery 10 Battery 11 Battery 12 Battery 13 Battery 14 Battery 15...
  • Page 10: Interface Definition

    AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ INTERFACE DEFINITION DIAGRAM OF THE COMMUNICATION INTERFACE RS232 COMMUNICATION PORT DEFINITION Interface Defined Declaration RJ12, RS232 Pin Layout PIN 1 NC (Empty) PIN 2 NC (Empty) PIN 3 TX Protection board sends data (Computer receiving data foot)
  • Page 11 AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ RS 485-1 / CAN COMMUNICATION INTERFACE DEFINITON Interface Defined Declaration Defined Declaration PIN 1 CANL PIN 1 RS485-B1 PIN 2 CGND PIN 2 RS485-A1 PIN 3 NC (empty) PIN 3 RS485-GND X1 Communication RJ45 CAN Pin...
  • Page 12 AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ RS485-2 COMMUNICATION INTERFACE DEFINITION Interface Defined Declaration Defined Declaration PIN 1 RS485-B2 PIN 1 RS485-B2 PIN 2 RS485-A2 PIN 2 RS485-A2 PIN 3 RS485-GND PIN 3 RS485-GND Battery Link A Part RS-485-2 B Part RS-485-2...
  • Page 13 AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ DRY CONTACT DESCRIPTION This BMS can provide one channel of dry contact signal, all dry contact signals are passive switches, regardless of polarity. KRY 1 (2P Terminal) BMS State Description Remark Normal Operation 1/2 pin is disconnected...
  • Page 14: Interface Functions

    INTERFACE FUNCTIONS WARNING Interfacing or plugging in any 3rd party or non-approved Hubble products or peripherals into the RS232 (serial) or RS485 (Battery Link) ports, can cause damage to the BMS and cause the BMS to malfunction. This may also result in damaging the internal cells. Plugging in non-approved Hubble products into these ports can immediately void your warranty.
  • Page 15: Communication Description

    OPTIONAL CLOUDLINK DEVICE The Hubble Cloudlink is an optional add-on to the Hubble X and AM range of products. If the device is connected to Wi-Fi it will cloud, all battery and inverter data to our cloud-server, enabling users to remotely monitor their power system.
  • Page 16: Parallel Functions

    AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ PARALLEL FUNCTIONS PARALLEL (CASCADE) FUNCTION OF BATTERY PACKS When the battery packs are cascaded, the one with the communication address of 0001 is called the master battery pack, and the other ones with the communication address are called the slave battery packs.
  • Page 17: Warning

    AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ WARNING To ensure proper use of the battery please read the manual carefully before using it. HANDLING Do not expose the battery to fire. Do not place the battery in a charger or equipment with wrong terminals connected.
  • Page 18: Completing Setup

    AM-5 MANUAL HUBBLE ENERGY ________________________________________________________________________________________________________________ COMPLETING SETUP CONGRATULATIONS! Once all the above steps have been completed you can proceed to follow the start-up instructions given by your inverter manufacturer. If you have any difficulties with setting up your system, please contact our Technical Support Department via https://www.hubbleenergy.com/.

This manual is also suitable for:

Am-10
