s-200
MANUAL
It is important that you read this manual before attempting the setup of your
battery. Please take note of certain steps to ensure correct inverter compatibility.
Please visit
https://www.hubblelithium.co.za
WARNING:
Working with high voltage systems is dangerous. Do not attempt to modify
your inverter and battery setup unless you are certain you understand the risk.
Speak to a qualified electrician if you are unsure.
V 1.0
for the latest version of this manual.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hubble LITHIUM S Series
Summary of Contents for Hubble LITHIUM S Series
- Page 1 V 1.0 s-200 MANUAL It is important that you read this manual before attempting the setup of your battery. Please take note of certain steps to ensure correct inverter compatibility. Please visit https://www.hubblelithium.co.za for the latest version of this manual. WARNING: Working with high voltage systems is dangerous.
-
Page 2: Single Use
battery Usage SINGLE USE: 12.8V is the maximum voltage level for singular use of batteries. SERIES: 51.2V is the maximum votlage level for 4 batteries connected in series. Batteries can only be connected in series in groups of 4 at a low voltage state. It is IMPORTANT to empty the power in each group of batteries before attempting a series connection. - Page 3 PARALLEL: In order to connect batteries in parallel all batteries must be the same model, the voltage must be in the same state and the voltage difference must be less than 0.5V to realize parallel connection. The number of parallel connections is not limited, but more connections will have higher consis- tency requirements.
- Page 4 In order to prevent leakage, heating, fire, explosion, performance degradation...etc please use the battery according to the following specifications. Hubble Lithium will not be held liable for incidents involving injury or battery malfunction caused by failure to operate in accordance with the below regulations: Handle with care and avoid vibrant vibration/movement.
- Page 5 storage & maintenance STORAGE The S-200 batteries must be stored in clean, dry, ventilated rooms at an ambient temperature of 5 ˚C ~ 25 ˚C and keep the relative humidity less than 75%. Avoid contact with corrosive liquids and away from fire and heat sources. The S-200 maintains approximately 50% ~ 60% power; therefore, it must be charged once every 15 days in storage for about 2-3 hours to prevent over discharge of the battery.
- Page 6 CONGRATULATIONS! If you have any difficulties with setting up your battery please contact our Technical Support Department via support@hubblelithium.co.za and be sure to include the following information in your initial email so that we can provide you with timely assistance: 1.
