- Page 5 1. Prepare 4 bolt assem- blies by first inserting a flat washer (#F) onto the bolts (#A). 2. Align the side panels (#1,2) to the holes along the headboard (#4), then insert 2 bolts into each end. Secure using the Allen wrench (#G). 1.
- Page 6 Insert the bars (#7,8) onto the designated slots, then insert the appropriate bolts and secure.
- Page 7 Attach Attach Align the slats (#9) to the top of the bars (#7,8) then insert a bolt (#D) into each end. Secure using the Allen wrench.
- Page 8 Align the wheels (#5,6) to the designated holes, then insert 3 bolts (#C) into each wheel and secure. Align the support legs (#12) to the holes along the slats (#11), then insert a bolt (#D) with a flat washer (#F) into each hole from above and secure.
- Page 9 Place the slats (#10) onto the slots along the side panels. Place the slat (#11) onto the slots left along the side panels, then insert a bolt (#C) with a flat washer (#F) into each end. Secure. ASSEMBLY IS COMPLETED...
