8310-001-0110
Safely and appropriately raise the rail
so that the underside of the rail tubes
is 400 mm from the ground. This is the
lowest clearance that allows assembly
of the support legs.
Standard version with trailer kit.
5
Standard version with trailer kit, hydraulics
and an extension (which is the maximum
number with hydraulics).
Standard shelves
6
Support leg
Standard version with trailer kit and two
extensions (which is the maximum number)
Standard shelves
7
Support leg
Standard shelves
4 3
Support leg
5 4
6 5
2
The wheel axle is located on rail pipe 3,
hole pair 2 (from the right)
3
The wheel axle is located on rail pipe 4,
hole pair 2 (from the right)
4
The wheel axle is located on rail pipe 3,
hole pair 2 (from the right)
TRAILERKIT 1300 KG
400 mm
Saw direction =
Direction of travel
Rail pipe 1
2 Rail pipe 1
3 2
400 mm
Rail pipe 1
11
