ICP DAS USA I-7530A-MR Quick Start Manual

Modbus RTU to CAN Converter
Package checklist:
The package includes the following items:
•
One I-7530A-MR hardware module
•
One Quick Start Guide
•
One software utility CD
•
One screw driver
•
One RS-232 cable (CA-0910)
Note:
If any of these items are missed or damaged, contact the local
distributors for more information. Save the shipping materials and
cartons in case you want to ship in the future.

1. Introduction

This manual introduces the user to the methods used to implement
the I-7530A-MR module into their applications in a quick and easy way.
This only provides with the basic instructions. For more detailed
information, please refer to the I-7530A-MR user manual
Fieldbus_CD:\CAN\Converter\I-7530A-MR\manual
The goal of this manual is focused on helping users to quickly
familiarize themselves with the I-7530A-MR module and the data-
exchanged between RS-232/485/422 and CAN communication interfaces.
Here, we use two I-7530A-MR modules (called the I-7530A-MR_A and
the I-7530A-MR_B) as the example to demonstrate how to use the I-
7530A-MR modules. The architecture of this example is depicted below.
