Display content Explanation
TEMP Current temperature
TotalVolt Battery voltage
Current Current
Res Cap Remaining battery capacity
Full Cap Battery capacity of Full charged
RelChargeState Relative Charge
AbsChargeState Absolute Charge in %
Briefly press for two times (interval time <0.5S) to exit back to main interface.
4. Error Code
History check. Briefly press (<0.5S) + or - to select "Error Code" and briefly press (<0.5S) to en-
ter into the interface. "E-CODE" indicate the error information for last ten times. "E-CODE 1"
represents the error content for the last time. "E-CODE 10" represents the error content up
to the tenth time. The maximum ten records can be kept. Error code "00" means no error.
Please see the error code table to know about the definition of the other codes.

4.3. Error code definition

DPC18 can show e-bike faults. When a fault is detected, one of the following codes will be indicated.
Error code Error definition
03 Brakes enabled
07 High voltage protection
08 Fault with motor hall sensor inside
The motor temperature reaches to the
10
max protection value
Fault with current sensor inside
12
controller
13 Controller temperature sensor failure
21 Fault with wheel speed detecting sensor
13 Battery temperature fault
21 Fault with wheel speed detecting sensor
22 BMS communication fault
25 Torque sensor torque signal fault
26 Torque sensor speed signal fault
30 Torque sensor torque signal fault
E-bike operation and maintenance manual
Display content
Cycle Times
Max Uncharge Time
Last Uncharge Time
Total Cell
Cell Voltage 1
Cell Voltage 2
Cell Voltage n
Error-shooting method
Check whether a brake cable is stuck.
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
Stop the e-bike for a rest.
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
Bring your Pedelec to your dealer or to a
specialist to have the error fixed.
Explanation
Cycle Times
Max Uncharge Time
Last Uncharge Time
The number of cell
Voltage Cell 1
Voltage Cell 2
Voltage Cell n
EN 37
