NOTE
When the user finishes the editing process by pressing EXIT button, the controller returns to the main
screen view and this program is selected as the current program.
4.10.

PRE-SET COMFORT TEMPERATURE

Pre-set comfort temperature is used in weekly control mode and
day/night mode. Press MENU button until the comfort temperature
change screen opens up. Press
temperature.
Press MENU to confirm and move on to the next parameter or press
EXIT to confirm and return to the main screen view.
4.11.

PRE-SET ECONOMICAL TEMPERATURE

Pre-set economical temperature is used in weekly control mode and
day/night mode. Press MENU button until the economical
temperature change screen opens up. Press
desired temperature.
Press MENU to confirm and move on to the next parameter or press
EXIT to confirm and return to the main screen view.
4.12. PRE-SET TEMPERATURE HYST ERESIS
Room temperature hysteresis defines the pre-set temperature tolerance in order to prevent undesired oscillation in case
of small temperature fluctuation (within the range of 0,2 ÷ 4°C).
In order to set the hysteresis, press MENU until the hysteresis setting
screen opens up. Use
Press MENU to confirm and move on to the next parameter or press
EXIT to confirm and return to the main screen view.
Example:
Pre-set temperature : 23°C
Hysteresis : 1°C
The room regulator reports that the temperature is too low only when the room temperature drops to 22 °C.
4.13.

TEMPERATURE SENSOR CALIBRATION

Calibration should be performed while mounting or after the regulator
has been used for a long time, if the room temperature measured by the
internal sensor differs from the actual temperature. Calibration setting
range is from -10 to +10 ⁰C with the accuracy of 0,1⁰C. To calibrate the
built-in sensor, press the MENU button until the temperature sensor
calibration screen appears. Use the buttons
correction.
To confirm, press the MENU button (confirm and go on to edit the next parameter) or press EXIT to confirm and return
to the main screen view.
or to set the desired
or
or to set the desired hysteresis value.
to set the
to set the desired
18
