- Page 1 Redwing CDMA1X (C3111) Airlink Cellular Modem Instruction Manual for use in IS-95B Circuit Switched/Voice Mode October 2006 Copyright © 2006 Campbell Scientific (Canada) Corp.
-
Page 2: Warranty And Assistance
WARRANTY AND ASSISTANCE This equipment is warranted by CAMPBELL SCIENTIFIC (CANADA) CORP. (“CSC”) to be free from defects in materials and workmanship under normal use and service for twelve (12) months from date of shipment unless specified otherwise. ***** Batteries are not warranted. - Page 3 Redwing CDMA Table of Contents 1. Introduction..............1 2. Specifications ..............1 2.1 Base Station Requirements ...............1 2.2 Datalogger Site Equipment...............1 2.3 Power Considerations ................2 3. Configuration ...............2 3.1 Establish Cellular Service.................2 3.2 Program the Modem .................2 3.3 HyperTerminal Setup................3 3.4 Programming the Redwing’s Phone Number ...........3 3.5 Programming the Redwing for use with a datalogger ......4 3.6 Setup LoggerNet (Option A) ..............5 3.7 Setup LoggerNet (Option B) ..............6...
- Page 4 This is a blank page.
-
Page 5: Specifications
Redwing CDMA1X AirLink Cellular Modem 1. Introduction The Redwing CDMA1X modem is a full-duplex, digital cellular modem that communicates with a base station PC via Code Division Multiple Access (CDMA) network and Public Switched Telephone Network (PSTN). The Redwing CDMA1X modem is for use on Bell, Aliant, ManitobaTel, and SaskTel networks only. -
Page 6: Power Considerations
Redwing CDMA1X AirLink Cellular Modem 2.3 Power Considerations A power cable included with the modem connects to the datalogger's 12 V or switched 12 V terminal. Connection to the switched 12 V terminal allows the datalogger to switch power to the modem during scheduled transmission intervals if desired. -
Page 7: Hyperterminal Setup
Redwing CDMA1X AirLink Cellular Modem Hyperterminal Setup Under “Connect using”, select the COM port you will be using. Set COM Properties to: Bits per second (baud) = 115200 Data bits = 8 Parity = None Stop bits = 1 Flow control = None Apply power to the modem and connect it to the computer via the 9-pin serial cable. - Page 8 Redwing CDMA1X AirLink Cellular Modem Step AT Commands Response Description AT+WSPC=1,xxxxxx Unlocks the module for service (where xxxxxx represents the lock code of provisioning AT commands. your modem. Example AT+WSPC=1,123456) Enter the MDN here. The MDN is AT+WMDN=[MDN] Example: the number used to dial this device.
- Page 9 Redwing CDMA1X AirLink Cellular Modem Step AT Commands Response Description Sets auto answer in data mode. ATS0=1+CICB=0 Disables local flow control. AT+IFC=0,0 Sets the Redwings RS232 baud rate and saves settings. Use the following to determine baud rate: CR800 AT+IPR=[baud rate]; &W...
- Page 10 Redwing CDMA1X AirLink Cellular Modem 6. Enter the phone number of the CDMA phone. 7. Apply the changes and test. 3.7 Setup LoggerNet (Option B) This is a blank page. 2. Select Add Root | ComPort. 3. Add a PhoneBase to the ComPort.
- Page 11 Redwing CDMA1X AirLink Cellular Modem If you have a black SC12 cable, that is not Rev 1 or newer, it is a NOTE CS I/O cable only and will not work for RS-232. Connect the black SC12 cable between the datalogger and the SC932A. Use a 9-pin serial cable or a blue ribbon cable between the phone and the SC932A.
