18
Plug the electrical cord into the auxiliary power supply.
19 Turn telephone right side up, and place in final position.
Response: The M3000 Touchphone display screen shows STARTING UP and
prompts PLEASE WAIT.
Note: The character displayed between the prompt PLEASE WAIT and the
string of five numbers at the bottom of the screen are codes used only for
service routines. There is no significance during M3000 Touchphone
installation.
Reset Internal Memory:
20 Touch positions 1 3 3 2 (in that order) in the number string at the bottom of the
START UP screen display. The internal memory is cleared.
Response: The M3000 Touchphone resets the directory, password, local
timer, clock, calendar, features, ring type, and volume and contrast level.
21 Print directory number on designation card.
22 Remove number lens by inserting the end of a paper clip into the hole at the
middle of the lens and levering upwards.
23
Insert designation card.
24 Snap lens with card back in place.
25 Designate button labels for key designations.
26 Fold labels, insert inside plastic button cover, and snap button cover over
movable key, pressing down on key, as required.
27 Repeat Steps 20 and 21 for all keys.
Task is complete.
Meridian 1 Options 201, 211 Meridian SL-100 M3000 Touchphone Reference Manual MSL03
CAUTION
Clearing Internal Memory
The clearing of the internal memory should only be
completed when installing the M3000 for the first time. It
does not need to be repeated when the M3000 is moved.
Installation procedures 5-3
