Installation procedures

Unpacking or packing a digital telephone

Use proper care while unpacking M3000 Touchphones. Check for damaged
containers so that appropriate claims can be made to the transport company
for items damaged in transit.
If a telephone must be returned to the factory, ensure it is packed in the
appropriate container to avoid damage during transit. Remember to include
all loose parts in the shipment, such as cords, handset, power unit, labels,
and lenses.

M2000 digital telephone installation

The step-by-step routine in Procedure 5-1 details the installation procedures
for any M3000 Touchphone. For additional installation information, refer to
the Meridian SL-100 Telephone Set/Attendant Console Installation Manual,
555-4001-212.
Procedure 5-1
M3000 Touchphone installation
1
2
3
Meridian 1 Options 201, 211 Meridian SL-100 M3000 Touchphone Reference Manual MSL03
Place telephone upside down on several sheets of soft, clean paper on a solid,
level work surface to prevent damage to movable keys and telephone face
plate.
Note: If TADO is not provided proceed to step 7.
If Installing TADO:
Remove the M3000 Touchphone stand by removing the four screws that fasten
the stand to the telephone body and lift off the locating posts in a straight,
upward motion.
Note: If the M3000 Touchphone is already connected, unplug the power supply
at the outlet and disconnect the line cord from the wall. Disconnect the power
supply, line cord, and handset from the M3000 Touchphone before removing
the stand.
Snap TADO into rear of the M3000 Touchphone with the ribbon cable and
header connector protruding from the front of the TADO.
5-1
