viii Contents
Typical M3000 telephone configurations and dimensions 2-2
Description of display screen 4-4
Icon symbols 4-6
Idle screen state 4-7
Volume state screen 4-10
Contrast state screen 4-11
List features 4-19
Select ring screen 4-20
Dial and conference transfer dial state screen 4-29
Dial and conference transfer dialing state screen 4-30
Busy and conference transfer busy state screen 4-31
Expensive route warning tone - call back queueing state screen 4-32
Ringback and transfer ringback state screen 4-33
Active state screen 4-35
View of jacks and tabs at base of telephone 5-4
Connection of the data terminal and TADO power supply to M3000 digital telephone
5-5
Directory archiver 6-8
Call logs 7-1
Main Menu 9-3
Modify menu 9-4
Tables
Name of table 3-1
TADO data characteristics 3-2
TADO data characteristics 3-2
M3000 Touchphone features 4-1
Soft keys 4-2
Display lines 4-5
Fixed touch position functions 4-7
Programmable touch position functions 4-12
Feature touch positions description 4-14
IDLE position 4-16
Touch profile 4-18
Call processing states 4-24
M3000 Touchphone positions labels and related screen displays 4-25
Dial and conference transfer dial state 4-29
Dial and conference transfer dial state 4-31
Expensive route warning tone - call back queueing state screen 4-32
Ringback state 4-33
Active state 4-33
Conference state screens 4-36
Consultation state 4-37
Intercom dial state 4-38
Standard RS-232-C Signals 5-6
Apple Macintosh to TADO 5-6
XLANAME 8-5
IBNXLA 8-6
KBD operation exceptions 9-12
Hayes keyboard dialing prompts 9-13
Hayes keyboard dialing parameter registers 9-14
555-4001-112 Standard 05.01 March 1995
