Page 1
TS48W Register your product at www.samsung.com/global/register...
Page 2
SAMSUNG refrigerators feature the following functions. Its TDM cycle makes it possible to extend storage of food for longer peroids. TWIN Cooling TDM By monitoring the states of the freezer and the fridge Condenser compartments on a real time basis, it runs both of the...
SAFETY PRECAUTIONS PREPERATION NAME OF EACH COMPONENT PRECAUTIONS BEFORE INSTALLATION CHECKPOINTS BEFORE USE USAGE Check the following before use. BUTTON & DISPLAY PANEL Function of Each Button HOW TO STORE FOOD HOW TO CONTROL TEMP To adjust temperatures HOW TO USE DISPENSER HOW TO REPLACE WATER-PURIFYING FILTER FRESH ISLAND HOW TO STORE WINE...
Page 4
• HFC- R134a is used as a refrigerant. • The refrigerator only use ice makers which are made by samsung Electronics for the refrigerator. • The incorporated ice-makers are to be installed only by the manufacture or its service agent.
Page 5
This product has 360ºCrotating casters. Do not insert your hands into the bottom area under So, if you take your hands off the product on a the appliance. slant, it will skid on the slant and fall over.To pre- • Any sharp edges may cause personal injury. ventlt, make sure to hold the product firmly.
Remember each part name. Grill Panel Button & Display Panel Show the set functions. PREPERATION Freezer Door Dispenser supplies drink water via a water filter and ice cubes made with the ice maker.
Page 7
Remember each part name. Filter PREPERATION Freezer Door Door Handle...
Make sure to check before installation. Select an installation place Please check the followings before install the product. Check if the product can clear the doors on its way to the installation position. If the product is not able to clear the doors, it is not possible to install. Model TS48W *** 1,219...
Page 9
Select an installation place Check if the floor is flat. If the refrigerator is installed on an uneven floor, it will cause vibration and noise. Check if the floor can support the weight of the refrigera- tor and the food inside (500Kg total). It could damage the refrigerator.
Check the following Before using the refrigerator, make sure to check the followings. It will show ways to use the product safely and efficiently. before use. When plastic smells are coming from the refrigerator Open the refrigerator doors and air the inside. - With a new product, there could be plastic smells inside the refrigerator.
Function of Each Button Basic functions of each button and the display. POWER FRE. FRE.TEMP REF.TEMP POWER REF. POWER FRE. POWER REF. SOUND LOCK FRE. TEMP REF. TEMP ICE OFF SUB FREEZE QUICK COOL NEO FRESH NORMAL LOCK SOUND ICE OFF WATER CUBED ICE CRUSHED ICE...
Let's figure out the correct Each storage space provides its own storage conditions for different kinds of food. You can enjoy the optimum taste of food by storing it in a selected place. use of each storage space. Ice Bin Store ice cubes made by the ice maker.
Page 13
Dairy Bin You can store dairy products such as butter and cheese. Fridge Compartment Shelf Please put dishes or refrigerated foods with enough space between items. Fridge Door Bin You can store small packaged refriger- ated food and beverages such as milk, fruit juice and beer.
To adjust temperatures Learn how to control the fridge & the freezer temperatures. Power can be saved by keeping food in appropriate temperatures. ■ How to control freezer temperature To control the freezer temperature, follow the procedures below. Press the [FRE. TEMP] button. Freezer temperatures can be adjusted between -25°C and -17°C with an inter- val of 1°C.
Page 15
■ How to control fridge temperature To control the fridge temperature, follow the procedures below. Press the [REF. TEMP] button. Fridge temperatures can be adjusted between 0°C and 5°C with an interval of 1°C . At this time, the temperature indication bars will be illuminating, showing the temperature range (MAX, MID or MIN).
■ HOW TO USE DISPENSER Samsung refrigerators have embeded water filters. So, please use a supplied water filter when using it. Ice cubes and water first made or supplied after the installation could send out plastic smells.
Page 17
■ To get ice Press the CUBED ICE/CRUSHED ICE button and select the shape of ice. Press the glass gently against the middle of the dispenser pad. ♣ Take the glass closer to the chute to prevent ice from bouncing out of the cup. •...
Have a knowledge of water-purifying filter. What is Water-Purifying Filter? It is a parts filtering impurities that are bad for human being such as chlorine and its smell and offensive taste contained in tap water. Filtrate and Purifying Effect Filtrate of water-purifying filter is made from vegetable active carbon. Purifying Effect It is NSF(National Science Foundation) certified, and meets a standard require-...
Let's figure out the You can speed up cooling or make frozen food soft enough to cut easily with this function. Also, by adjusting the temperature of each compartment, you can Fresh Island function. store customize the storage of different kinds of food. Function selection QUICK NORMAL...
Page 20
Function selection When NEO FRESH is selected When NEO FRESH is selected, the temperature of the Fresh Island will be set to -1°C and the temperature of the fridge compartment will be maintained at -1°C regardless of its temperature setting. QUICK NORMAL LOCK...
HOW TO STORE WINE Types of wine Red Wines They are made of various red grapes which have lots of fruit flavor, fragrance, silkiness and tannin. Different from white wines, they have various levels of tannin and they work with most of red meat dishes. They taste good at room temperature (18°C ~20°C ).
Page 22
Selecting good wines A wine label is a guide to the contents of the bottle. Many wine labels lay all the information about the wine itself such as the grape, the place, the producer and the year with commendable clarity. So it is very important for you to read these labels.
Here is some information to keep food in a fresh condition. How to use the refrigerator effectively To make cold air to flow freely To maintain the fridge compartment temperature to 4°C , it sends out cold air near 0°C . So, when food containing water is placed deep inside, it could become frozen.
Page 24
To frost the surface of beer cup After pouring warm water into the cup, empty the cup when it gets warmed up. And, turn it upside down and put it in tahe freezer compartment for about 30 minutes When you take it out later, you will find frosts sitting on the surface of the cup.
Page 25
How to store food To store spices in the freezer or fridge compartment When storing spices, you need to prevent their flavors from escaping. Store it in a dry place out of reach of direct sunlight. The freezer or fridge compartment is the best suitable place to store spices. To store potatoes freshly Because potato buds contain toxins, you need to get rid of the buds.
How to clean and take care of the product. HOW TO CLEAN AND TAKE CARE OF THE PRODUCT Inside refrigerator/Accessories Wipe with a clean cloth lightly dampened with water or mild liquid dish detergent. Door gasket Wipe with a clean cloth lightly dampened with mild liq- uid dish detergent and clean the grooves with cotton balls.
Page 27
Disassembling for cleaning Before cleaning the refrigerator, flip the grille panel up as shown in the figure and set the power switch to the O (OFF). To prevent electric shock then, disassemble when turned off. Water tends to gather inside and flow down on the bot- tom.
Page 28
Dairy Bin Flip up the dairy bin cover and remove it while pushing it back. Hold the dairy bin with both hands and lift it up and out of the door. Freezer/Fridge Door Bin Hold it with both hands and lift it up and out of the door. Freezer/Fridge Shelves Tilt shelf up at front, then lift it up and out of the tracks on rear wall of refrigerator.
Make sure to check before calling for service. Problem Possible Causes What To Do Fridge or freezer Master power control set to O (OFF). Switch on the power ("I" pressed). compartment too warm. (Low cooling power) Refrigerator is unplugged. Plug in the power plug again. Press the FRE.
Page 30
Problem Possible Causes What To Do Water could contain chlorine Ice cubes are made with tap water. sending out odors. Make ice with filtered water. Clean the interior of the Interior of refrigerator needs refrigerator frequently to remove cleaning. food smells. Ice cubes have odor.
Page 31
Problem Possible Causes What To Do If you open the door again within 5~10 seconds, it could be hard to open due to the It has just closed after being Door hard to open! pressure difference between opened. the inside and the outside of the refrigerator.
TS48W*** Model Name 48" Total GROSS Freezer Room volume Fridge Room Total Storage Freezer Room volume Fridge Room Weight 260kg Width(mm) 1,219 Dimension Height(mm) 2,083 Depth(mm) Rated Voltage/Frequency AC 230~240V/50Hz Design & specifications can be changed to improve quality without any notice in advance. OTHERS Height Width...
Page 33
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal. If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.
