    Table of Contents Main Components ............................2 Game Set Up ............................... 3 Assembly/Unpacking ..........................3 Mounting the header ..........................4 Claw Strength Set up ..........................6 Game Sequence and Behavior ........................6 Programming .............................. 7 Fare Play ..............................9 Programing Tree Fare Play ........................10 Programming Option Fare Play ......................
  • Page 3: Main Components

    Main Components...
  • Page 4: Game Set Up

    Game Set Up Assembly/Unpacking Be sure that all packing material is cleared, and the game is sturdy on the ground. Inside the playfield is a box with the header of the game. Header The claw is restrained by 5 zip ties. Cut them carefully before starting game.
  • Page 5: Mounting The Header

    Mounting the header Feed wires through the two holes and connect to existing harness. Header Back View Be sure to align lower brackets with the two designated holes.
  • Page 6 Once those are aligned use the 4 screws and washers provided with the header to secure it in place. Game Top View...
  • Page 7: Claw Strength Set Up

    Claw Strength Set up VR1 – Strength of initial claw grab in the down position (usually the highest voltage) VR2 – Strength once claw has the prize and is in motion towards prize chute (usually the lowest voltage) VR3 – Default 10% (every 10 plays the claw strength remains the same high voltage from initial grab to drop off) To set these properties you will need to have the machine powered off, and find the control panel, pictured below.
  • Page 8: Programming

    Programming Dip switch settings on Main board. Default settings are in green. Standard Settings are set to $.50 play. Dip Switch 1 0=Off 1=ON Dip Switch Setting: Function Not used Dip Switch 2 0=Off 1=ON Dip Switch Setting: Function Claw moves to middle at beginning of game play Credit Display...
  • Page 9 Dip Switch 3 0=Off 1=ON Dip Switch Setting: Function 1Coin 1Credit Coin Mech 1 1Coin 2Credits 1Pulse 1Credit Bill Acceptor 1Pulse 2Credits 4 Credits a play 1Credit 1Play 2Credits 1Play 4Credits 1Play 8Credits 1Play Credits to Play 20Credits 1Play 28Credits 1Play 4Credits 3Plays 20Credits 15Plays 15 Sec...
  • Page 10: Fare Play

    Fare Play Using the Stage 1 hand controller you can get into the programing options of your crane machine. Dial Display Screen Press the Dial in to enter the Menu Mode. Moving the Dial clockwise will move through the option. Counterclockwise goes back to the previous option on your Display Screen.
  • Page 11: Programing Tree Fare Play

    Programing Tree Fare Play Exit Lifetime $ # of Play Save Config & Play # Coins 1 Game Counters # Coins 2 $ per Play $ per Prize Reset Counters Reset Config Exit LED Display 0-99 Exit Back Forward Gantry Right Test System Left...
  • Page 12 Programming Tree Continued Exit Game Setup Pulse Per Credit Game Length U Lim Disable L Lim Disable Claw Grab Strength Claw Up Strength Game Config Claw Home Strength Up Speed Left/Right Speed Front/Back Speed Center at Start Chute Drop Delay Exit Sound Menu Sound Option Volume...
  • Page 13: Programming Option Fare Play

    Programming Option Fare Play 1. Save Configuration and Play 2. Game Counters a. Exit Counters b. Lifetime $ (it displays the amount of $ earned by the machine) #Play (The amount of games played) #Coins1 (The amount of coins inserted in coin mech.) #Coins2 (The amount of bills inserted in the bill validator) $ Per Play...
  • Page 14 4. Game Config a. Exit Game Setup b. Pulse per credit i. From 1 to 80 c. Game Length (in seconds) i. 1 to 99 d. U Lim Disable i. Yes/No e. L Lim Disable i. Yes/No Claw Grab Strength (% of 48Volts) i.
  • Page 15: Error Codes And Troubleshooting

    Error Codes and Troubleshooting Error Code Description 1 Up/Down Motor Error 2 Forward/Back Motor Error 3 Left/Right Motor Error 4 Coin Mech 1 Error 6 Forward/Back Motor Error 8 Main Controller Error 11 Sensor Test Mode 71 Drop Button Stuck Claw Error E1: Up/Down Motor Error Troubleshooting...
  • Page 16 E6: Forward/Back Motor Error Troubleshooting Check forward and back limit switches on the claw gantry. Check that motor is connected and turning on. E8: Main Controller Error Troubleshooting Check that board is receiving proper voltages. Check for floating grounds. Change ram IC chip. E11: Sensor Test Mode Troubleshooting Make sure that you are not in test mode.
  • Page 17: Components

    Components Stage One Controller Fare Play Part Number: 7100BRD020 Location: Inside lower cabinet on the top right drawer. I.D. Switch Setting: All Off (00000000) RGB Light controller board Part Number: TBA Location: Inside front door panel. I.D. Switch Settings: 00000000 (all off if only using one crane) This board links multiple cranes’...
  • Page 18 Main Controller Board Part Number: 7100BRD001 Location: Inside lower cabinet I.D Switch Settings: Defaults (see Programing for more options) SW1 – 00000000(all off) SW2 – 11000000 (1 and 2 On) SW3 – 00010010 (4 and 7 On) SW4 – 11000000 (1 and 2 On)
  • Page 19: Wiring Diagram

    Wiring Diagram:...
  • Page 21 Connector Description Wire Color J1: D Type Connector (To Crane) See Chart diagram J2: Power Connector Ground Black +24V Orange Yellow +48V Green +12V Blue J3: Speaker, Sensor Connector +12V Ground Black Sensor Out White Sensor In Brown Free Play Orange Balancer Black...
  • Page 22 Ground Black J7: Display Connector Prize Counter Yellow "Catch" Light Brown +12V Black 7 Seg Display 7 Seg Display 7 Seg Display 7 Seg Display 7 Seg Display 7 Seg Display 7 Seg Display J10: Display Connector 2 Ground Black Double 8 Digit Display (7 Seg) Pink Double 8 Digit Display (7 Seg)
