Related Manuals for ELAUT Big One X-treme
Summary of Contents for ELAUT Big One X-treme
- Page 1 : Big One X-treme 1 MANUAL 2 CABINETS 3 PRIMARY CIRCUITS 4 ELECTRONICS 5 FUNCTIONALITY 6 WIRING...
- Page 2 : Big One X-treme 1 MANUAL 2 CABINETS 3 PRIMARY CIRCUITS 4 ELECTRONICS 5 FUNCTIONALITY 6 WIRING...
- Page 3 Building X-treme Big One Building Guidelines X-treme Big One Auteur: Hoefman Dirk Document versie: V1.1...
- Page 4 Building X-treme Big One History Version Release Date Remarks V1.0 12/04/2016 First Release V1.1 02/05/2016 Chapter3, 4, 15 & 18 Document versie: V1.1...
- Page 5 Building X-treme Big One General • Each warning sign In the document is to put the focus on some detail. • Please be aware before setting up the X-treme Big One that the power entrance is located below in the “Console box”. This can be accessed through the rear of the “Console box”.
- Page 6 Building X-treme Big One Unpacking • This document contains guidelines to build the big one extreme. Everything to build the machine will be in the parcel as you see below. • A document with a list of material included in the parcel is included. You will find 2 top parts of the machine You will find 2 top...
- Page 7 Building X-treme Big One Building Instructions 1. Assembly of frame • When unpacking the frame parts you should notice that these are numbered from F1 up to F9. • Please make sure that all frames are mounted correctly & firmly fixed.
- Page 8 Building X-treme Big One • Next step is to mount panel F3 also with 5 screws. • The following panel to be mounted is F4 using the same 5 screws. Please be aware that the PCB’s for the running RGB lights are mounted on the panel F2 & F3. Do make sure these are not damaged! These are covered with some lexan/cardboard for protection.
- Page 9 Building X-treme Big One • We can now start with the upper parts F5 > F9. • First we will install frame part F5, then part F6 and part F7. • Each upper part is fixed to the lower part using screws M6x90 + washer M6 + nut M6. •...
- Page 10 Building X-treme Big One • Each corner from the top half will be fixed with 5 screws as shown below. 6050.0665 (4x) Screw M6x65 6050.0110 (1x) Screw M6x25 connections connections • The upper front F8 will be fixed in the corners as shown above and at the inside it will be fixed to the lower part with 2 times 2 connections.
- Page 11 Building X-treme Big One • The latest part to be mounted is frame F9. • Notice the frame F9 will be installed from the outside. This will be fixed with 8 screws M6x60 at the inside of the frame. 6051.0660 (Screw M6x60) Document versie: V1.1 ²...
- Page 12 Building X-treme Big One • The next step will be the assembly of the 2x “head front long” and 2x “head front short”. • Please be aware that all 4 parts are different. • At the front the “head front long“ is equipped with a bracket containing a Power supply, a RGB controller and a Domino PCB + already installed cables in a cable guide.
- Page 13 Building X-treme Big One 2. Assembly of controls casing & cables VERY IMPORTANT: NOW WE FIRST NEED TO PLACE THE PRICE CASING INSIDE THE FRAME!!! DO NOT YET FIX IT. • Now we can install the “controls casing”. The bottom rear should fit in the groove of the aluminium profile at the bottom of frame F4. Once this is at his place it can be fixed with the toggle latch.
- Page 14 Building X-treme Big One • To fix the “control casing” properly the toggle latch can be adjusted by turning the latch (see previous picture). • The grounding wire (see previous picture) from the “controls casing” should be then connected to the grounding lip of the frame F4. •...
- Page 15 Building X-treme Big One • Once the “control casing” is at its position we can now start with the cabling inside the “control casing”. • The following cables are now available: o Powercables (3x) for the RGB controller boards RGB_2 > RGB_4. o Mains cable for the TV •...
- Page 16 Building X-treme Big One • The mains cable for the TV will be guided through the same cable guides up to the mid of the rear panel F2. There we’ll need to cut a hole in the cable guide so the mains cable can could be guided up towards the TV powercord.
- Page 17 Building X-treme Big One 3. Assembly of RGB led strips and datacables • The next step is to connect all data cables (9015.1257, 9015.1258 & 9015.1259) between the controller boards and the RGB ledstrips and installing the RGB led PCB’s. •...
- Page 18 Building X-treme Big One • The cables connected to the RGB_1 board, situated at the bottom right of the controls casing, will be guided through the small cable guide (as shown in picture below. • The cables from RGB_1 up to RGB_4 will be guided outside to the corner of the frame through the holes foreseen.
- Page 19 Building X-treme Big One • In each package of a “corner piece” you should find some extra packages with the RGB led boards required to build 1 side. • Each package is marked with “Lower parts” or “Upper parts”. • We will start with the “lower parts”. These need to be fixed in each corner starting at the bottom.
- Page 20 Building X-treme Big One Completed RGB led board strip PVC print montage Document versie: V1.1 ²...
- Page 21 Building X-treme Big One • Check pictures below which show how to connect the RGB led boards to each other. • The picture below show cable 9015.1258 (datacable for upper strip). • When required the cables 9015.1258 (datacable for upper strip) and 9015.1259 ( can be glued in the corner Profile with some tape.
- Page 22 Building X-treme Big One • The pictures below show the assembly of the upper RGB led strip. PVC print montage Document versie: V1.1 ²...
- Page 23 Building X-treme Big One • Make sure that the end of the lower strip and the beginning of the upper strip join together. • Once all datacables and powercables are connected the remaining length can be folded and guided into the cable guide. •...
- Page 24 Building X-treme Big One 4. Mounting the 4 corner pieces with RGB leds. • We first connect the split cable to the upper rgb led board already present in the corner. • We can now lift the corner piece (screw thread) over the head front (holes). •...
- Page 25 Building X-treme Big One • Before fixing the 2 sides we will properly fold the present cable so it is not visible. • Then we fix each corner piece: drill the holes first with a drill of 3.6mm and then fix it with 2 selftapping screws 6170.4213.
- Page 26 Building X-treme Big One 5. Assembly of other cables coming from the controls casing • We will now guide the following cable upwards through the cable guides: o 2 loudspeakercables o Gantry cable o Mains cable • These cables can be found in the compartment at the right from the door (at rear). •...
- Page 27 Building X-treme Big One • Now we guide the cables through the following cable guides upwards > see following 3 pictures. Document versie: V1.1 ²...
- Page 28 Building X-treme Big One Document versie: V1.1 ²...
- Page 29 Building X-treme Big One 6. Mounting and connecting the loudspeakers & ledspots • To mount the ledspots we will need to dismount the bracket first. • Each bracket will be mounted on the frame (see picture below) with 2 screws M6x20 (6111.0620), 2 washers M6 (6092.0058) and 2 lock washers M6 (6090.0006).
- Page 30 Building X-treme Big One Now we can connect the cables from the ledspots to the screwless connector which can be • found on the yellow front head. At the same time we can connect the mains cable coming from the “controls casing” to the •...
- Page 31 Building X-treme Big One • The loudspeakers will be mounted at the front of the frame against the yellow front head. The holes are present in the yellow front head. Each loudspeaker will be fixed with 2 screws M4x10 (6030.0410), 4 washers M4 (6092.0042) and 4 lock washers M4 (6090.0004).
- Page 32 Building X-treme Big One 7. Connecting the RGB ledstrip in the head front long & short. • The 4 RGB ledstrips should be connected to the Domino pcb which can be found at the head front long. • 2 cables are already connected: the ledstrip from the head front long and an extension cable which is guided through the cable guide from the head front long to the other side.
- Page 33 Building X-treme Big One 8. Installing & connecting the price casing. • The price casing will be shifted up to the front panel and fixed with 2 selftapping screws (6170.4213). • We can now make the connection between the cable from the price casing and the cable from the controls casing.
- Page 34 Building X-treme Big One 9. Mounting the bottom pieces B1 up to B7. • The bottom should be installed as shown below. • All panels will be fixed against each other to fit the frame. • To fix the wooden plates to each other screws M4x40 chipboard (6150.0070) shall be used. •...
- Page 35 Building X-treme Big One • We will first fix the wooden floorplate labelled “B5” at the back of the controls casing as shown in picture below. The mounting holes in the wooden plate are already present. We only need to drill holes of 3.6mm in the aluminium frame at these locations once the plate has been well positioned (±100mm from the aluminium frame as shown in picture below).
- Page 36 Building X-treme Big One • The following pictures show this sequence. Parker screw M4.2x32 (6122.0832) Drill holes of 3.6mm first !! • Panel B1 Chipboard screw M4x40 (6150.0070) Parker screw M4.2x32 • Panel B2 (6122.0832) Drill holes of 3.6mm first !! Chipboard screw M4x40 (6150.0070) Document versie: V1.1...
- Page 37 Building X-treme Big One • Pay attention that when installing panel B2 the mains cable for the TV will be guided through the opening as shown in picture below! • Panel B3 (fix as shown in previous pictures with the appropriate screws). Document versie: V1.1 ²...
- Page 38 Building X-treme Big One • Panel B4 (fix as shown in previous pictures with the appropriate screws). Document versie: V1.1 ²...
- Page 39 Building X-treme Big One 10.Mounting the 2 inner short cover plates head. • The 2 cover plates at both sides will be installed. • The lips from the cover plates should fit into the slots from the head front. Document versie: V1.1 ²...
- Page 40 Building X-treme Big One 11.Mounting the 4 endstop X-treme Gantry. • In the packaging (normally in Box1) you should find 4 endstops. • These will be fixed in the frame with a screw M4x16 (6030.0416). Document versie: V1.1 ²...
- Page 41 Building X-treme Big One 12.Mounting the Gantry and connect. • To be able to fit (lift) the gantry minimum 2 people are required. • At both sides you should notice a round rod where the wheels of the gantry should fit. Document versie: V1.1 ²...
- Page 42 Building X-treme Big One • This part of the gantry should be held to the left when lifting. • The gantry cable coming from the controls casing shall be connected to the cable coming from the gantry. • Then the gantry cable will be guided through the cable clamps Document versie: V1.1 ²...
- Page 43 Building X-treme Big One • The available gantry cable should still be long enough so the gantry can reach every corner of the playfield. Document versie: V1.1 ²...
- Page 44 Building X-treme Big One 13.Mounting the TV and RCA cable. • Before mounting the TV we should connect the RCA cable to the camera wire as shown in picture below. • It can be fixed to the gantry by a couple of cable ties. •...
- Page 45 Building X-treme Big One • Connect the scart connector to the TV at the rear and connect then the RCA cable to this connector to the “output”. Scart connector • Now we can connect the mains cable which should already be available (coming from below). •...
- Page 46 Building X-treme Big One • We can now lift the TV + bracket on the bracket present at the rear of the frame • Make sure that it fits well on the this bracket ! • Finally we should check that the RCA cable is long enough so the gantry can reach every corner of the playfield.
- Page 47 Building X-treme Big One 14.Mounting the last cover plate. • We can now install the cover plate at the front. • The lips from the cover plates should fit into the slots from the head front. Document versie: V1.1 ²...
- Page 48 Building X-treme Big One 15.Mounting the 3 ceiling parts. • Before mounting the ceiling we need to remove the protecting foil. • The ceiling parts will be installed with the white side downwards. • We start at the rear of the frame with the first part of the ceiling. Document versie: V1.1 ²...
- Page 49 Building X-treme Big One • The ceiling will be fixed: first we drill holes with a drill of 3.6mm and then we fix it with selftapping screws 6170.4213. Document versie: V1.1 ²...
- Page 50 Building X-treme Big One 16.Mounting the 4 corner pieces head. • Before mounting the corner piece head we need to remove the protecting foil. • In all 4 corners we will mount the corner piece head each with 2 parker screws (6121.0816). Document versie: V1.1 ²...
- Page 51 Building X-treme Big One 17.Mounting the 4 Aluminium tubes on top. • When required for the customer the 4 aluminium tubes (25x25) can be mounted on top. • Therefore we will use for each tube 2 screws M4x35 (6030.0435) and 2 nut hex flange M4 (6076.0004).
- Page 52 Building X-treme Big One 18.Mounting the lexan protection round the pricing casing. • The lexan protection will be placed behind the price casing. • To fix it we will use 10 chipboard screws M4x16 (6152.4016) to fix it to the bottom plates and selftapping screws (6170.4213) to fix it to the aluminium frame.
- Page 53 Building X-treme Big One 19.Mounting the transparent white corners. • At each corner there will be 2 transparent white corners installed, the longest (L = 1900mm) below and the shortest (L = 1333) above. o Picture below shows how these corners should be fixed. Document versie: V1.1 ²...
- Page 54 Building X-treme Big One 20.Mounting the doorknob. • For transport the doorknob has been removed. • This needs to be mounted again. • All material should be present in the package. Document versie: V1.1 ²...
- Page 55 Building X-treme Big One 21.Mounting the lexan (200x690) at the door entrance. • The lexan can be mounted at the door entrance with 4 chipboard screws 4x16 (6150.0046). • Remove the protecting foil before mounting. Document versie: V1.1 ²...
- Page 56 Building X-treme Big One 22.Finish. • The X-treme Big One is now ready for testing and set-up. • At the camera there are 2 settings possible: Zoom and Focus. • The setting change can be done with a hex key which can be found in the packaging. •...
- Page 57 X-treme Big One Mat'l in container 12/04/2016 Art. Nr. Unit Productname Acties 0190.0424 1,00 ST Bottom support door 730x365 Number "B6" 0190.0425 1,00 ST Bottom support price casing 373x365 Number "B5" 0190.0426 4,00 ST Support bottom 500x365 Number "B7" 0190.0427 1,00 ST Bottom A X-treme 1862x1033 Number "B1"...
- Page 58 5460.0023 4,00 ST Cornerpiece head Box 1 5460.0024 4,00 ST corner piece X-treme 5460.0025 2,00 ST Head front long X-treme 5460.0026 2,00 ST Head front short Big One 9015.1153 1,00 ST Cable itx rgb extension 3m Box 1 9015.1257 4,00 ST Cable rgb connection 1.2m Box 1 9015.1258...
- Page 59 9235.5005 1,00 ST Gantry hp big one 4308.1773 4,00 ST Pvc prof.9276 trans wit l=1773 Transparant white to be placed in corners frame 4308.1900 4,00 ST Pvc prof.9276 trans wit l=1900 Transparant white to be placed in corners frame 8521.1866 2,00 ST Prof 58025200 wit l=1866 White aluminium square profile 25x25...
- Page 60 Manual English Intelligrab 02xx revxx The Big One 03xx revxx 15/11/2006 ELAUT nv/sa Passtraat 223 B-9100 Sint-Niklaas Belgium Tel: +32 3 780 94 80 Fax: +32 3 778 05 61 Website: www.elaut.com E- mail: support@elaut.be...
-
Page 62: Table Of Contents
Table of contents Introduction....................5 Principal of operating................5 The course of the game ................5 Result-oriented operating .................6 Evaluation of the payout ....................6 Grabsuccess........................6 Cashboxes.........................6 Accounts ..........................6 Mechanical counters......................6 Fill up the crane .........................6 Try to keep in kind of merchandise in one playfield............6 Overview menu ..................8 Intelligrab ...........................8 Intelli link ..........................8... -
Page 64: Introduction
Introduction Congratulations with the purchase of your crane with Intelli Technology. We advise you to read this manual completely so you learn the possibilities and the use of this system. Different aspects of the game can be set (more about this further in this manual). Through the LCD display and a few pushbuttons, a lot of information about the functioning of the system can be displayed. -
Page 65: Result-Oriented Operating
Result-oriented operating We assume that your machine is completely set to your wishes. If this is not the case, go to “settings”(further in this manual). Evaluation of the payout In the menu “pay-out information (displays automatic by staring up the machine) you can see the results of your crane during a short time and compare it with the expected result “current percentage xx%”... - Page 66 Working with the Intelli Programmer • The arrows “up” and “down” (1) are used to pass through the different menus and settings. • The “Select” button (2) is used to open or close the different menus or to do specific actions, like clear counters.
-
Page 67: Overview Menu
The crane is controlled electronically, but that doesn’t means that it adjusts automatically. The most imported link is, and stays, the manager. You can adjust the crane by settings desired by the managers and players. The programmer (see picture on last page) makes it easy to adjust. You walk through the different menus that are mutually linked, and adjust them by a simple push on a button. -
Page 68: Cashboxes
Cashboxes coins in: amount of received coins. CASHBOXES bill/tk in: amount of received bills. coin in 185.0 #wins: amount of won prizes. bill/tk in 100.0 #dispenser: amount of won consolation prizes. #wins ex: ticket dispenser, chewing gum dispenser, … #dispenser The “cashboxes”... -
Page 69: Payout Information
Payout information current perc: the percentage that is already paid out. PAYOUT INFORMATION “Money in” and “prize out” automatically calculate this i current perc. 45% percentage. This is information, so not adjustable. i set perc. set perc: the desired pay out percentage. This is not est.price out 10.0 directly settable, but “est. -
Page 70: Bill/Token Values
Bill / token values bill 1 value: value of a bill BILL/TOKEN VALUES bill 1 indic: the indicated value of a bill bill 1 value bill 2 value: value of bill/ coin/ token bill 1 indic bill 2 indic: the indicated value of a bill/ coin/ token bill 2 value 10.0 bill 3 value: value of bill/ coin/ token... -
Page 71: Motor Speeds
Motor speeds The speed of each motor can be adjusted separately. MOTOR SPEEDS forward motor 100% sideward motor up/down Dispenser settings pay award: the credit of tickets/chewing gums will be DISPENCER SETTINGS memorized if the dispenser is empty. By pressing “S” they S pay award will be paid. -
Page 72: Diagnostics
Diagnostics last money: indicates the channel where the last money DIAGNOSTICS was inserted i last money meter error: number of times that the counters failed i meter error during counting i coin/bill coin/bill: number of problems with the coin- or bill i dispenser error 0 acceptor i pay out errors... -
Page 73: Selftest
Selftest claw type: the claw type will be measured by turning on SELFTEST each claw type has a specific number: T clawtype 0 = error T cord replacement 2 = small T mech. cycle 3 = medium T lamptest 4 = large T dispenser 5 = big one i coin-in... -
Page 74: Adjusting
Adjusting Remark: it is not possible to work with merchandise that contains magnetic materials because of the permanent magnetism of the axe. This will stick on the axe! After you choose the correct claw for the merchandise, you can do as follows: Go to the menu “CLAW SETTINGS”. -
Page 75: Warnings And Errors
S to resume Remark: This is an option and is not installed on a standard machine. This is used for the stock management through Intelli Link. For more information, please contact Elaut or a registered dealer. Display code: 4 ! WARNING:... - Page 76 Display code: 9 ! WARNING: It takes to long before a win is registered. Check the it took to long many settings in the menu “Payout information” and also check games to win (check settings and the working of the prize detector. detector) Display code:10 ! WARNING : grabber...
- Page 77 Display code:33 ! ERROR: payout to The payout percentage is too high for a longer period. It high, check (claw) can’t be adjusted. Check the claw settings as well as the settings and restart regulator first regulator. The regulator has to be recalibrated before continuing the game.
-
Page 78: Extra Settings And Errors (The Big One)
Extra settings and errors (The Big One) There are a few extra setting in the program of The Big One: Game settings win door mode: 3 possible options: GAME SETTINGS • 0 = manual: the player can remove the prize all by game time himself. -
Page 79: Error
Error Display code: 43 ! ERROR; wind door There is a problem with the win door. It can be corrected in out of order.press S. the SELFTEST-menu. (go to SELFTEST to reposition door) - Page 81 Installing the cable gland Required material: Power cord Cable gland (5 parts) Mounting Plate Start position: • The cable gland and mounting plate are already assembled in the unit. Mounting instructions: • Dismount the cable gland from the mounting plate. Document versie: V0.0...
- Page 82 • Place the grommet round the power cord. Cosmic XL > L = 20 cm Big One X-treme > L = 40 cm • Install now the 2 parts of the cable gland housing. • The ribs of the grommet are placed sidewards!!
- Page 83 Installing the cable gland • Install the rubber ring • Slide the power cord with cable gland through the mounting plate. • Install the nut Document versie: V0.0...
- Page 84 Installing the cable gland • Connect the power cord to the power inlet. END OF THE INSTRUCTIONS Document versie: V0.0...
- Page 85 : Big One X-treme 1 MANUAL 2 CABINETS 3 PRIMARY CIRCUITS 4 ELECTRONICS 5 FUNCTIONALITY 6 WIRING...
- Page 86 THE INFORMATION AND VALUES ARE INTENDED TO ASSIST YOU AND ARE PROPERTY OF ELAUT N.V. IT IS NOT INTENDED TO AND DOES NOT CREATE ANY WARRANTIES EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR THAT THE RESULT SHOWN WILL BE ACHIEVED BY A USER FOR A PARTICULAR PURPOSE.
- Page 87 : Big One X-treme 1 MANUAL 2 CABINETS 3 PRIMARY CIRCUITS 4 ELECTRONICS 5 FUNCTIONALITY 6 WIRING...
- Page 88 ELECTRIC STRENGHT ............................. 5 IV.1.4 ABNORMAL OPERATION AND FAULT CONDITIONS ..................5 ANNEXES ....................................5 ............................5 ELECTRICAL RATING AND FUSING ..............................5 ELECTRICAL SCHEMATICS ..............................5 COMPONENT DATASHEETS REVISION LOG : .................................. 5 TECHNICAL SHEET : SAFETY REPORT OF BIG ONE X-TREME...
- Page 89 BASE ELECTRICAL CONCEPT The Big One X-treme is an amusement machine consisting of an assembly of aluminium frame cabinet panels with chipwood plate and glas panels, inaccessably closed for non authorized personel. The inside of the machine can be accessed by means of a key-locked door. Technical comparments are then accessed again with a key locked panel.
- Page 90 UL, CSA 2510.0701 Wire 0.75 browne Anixter Flame retardant, UL, CSA 2510.0706 Wire 0.75 blue Anixter Flame retardant, UL, CSA 2530.0701 Cable 3G 0.75 Helukabel Flame retardant, CE, UL, HAR, AWM TECHNICAL SHEET : SAFETY REPORT OF BIG ONE X-TREME...
- Page 91 IV ELECTRICAL SAFETY REMARK : for electric component related properties refer to component compliance reports in annex (section V) IV.1.1 EARTH LEAKAGE CURRENT Earth leakage current is mesured <1mA (Concept parameter) TECHNICAL SHEET : SAFETY REPORT OF BIG ONE X-TREME...
- Page 92 Intelli supply module connected non-detachable fan is no longer placed new connection means to monitor in the back top lights power supply exchanged with lower power version fused secundary connections for RGB lights TECHNICAL SHEET : SAFETY REPORT OF BIG ONE X-TREME...
- Page 93 Passtraat 223 Datum: 9/02/18 B9100 Sint Niklaas Revision : 01 BO xtreme primary circuit Belgium Page : 1/1 Main Fuse SMPS 12VDC Mains 200VA Entry LED Light LED Light spot spot chassis Monitor Monitor SMPS 12VDC 200VA SUPPLY Power supply chassis Signed : JDV...
- Page 94 AFZEKERING KASTEN 9/02/2018 cont tlag peek peek 2° peek 3° ^NTC smoothed peek type : Big One Extreme omschrijving : verbruikers : 512 W zekering : 230V T4,0A printbak : 115V T6,3A RGB verlichting : RGB verlichting : Led spots : diverse : cont peek...
- Page 95 : Rhenatech Gmbh,Fiber glass sleeving, Type M8172 Class F 155° C,600 V, UL nr. E201197 TECHNICAL CONSTRUCTION FILE TF11158 TEL. ++ 32 2 569 15 27 Customer Elaut NV DATE 03/2011 FAX. ++ 32 2 569 23 70 Refer to Photograph : PAGES www .
- Page 96 R S P - 2 0 0 200W Single Output with PFC Function s e r i e s ■ ‧ ‧ ‧ ‧ ‧ ‧ ‧ □ ‧ ‧ ...
- Page 97 R S P - 2 0 0 200W Single Output with PFC Function s e r i e s ■ ‧ ‧ ‧ ‧ ‧ ‧ ‧ □ ‧ ‧ ...
- Page 98 R S P - 2 0 0 U S P - 2 2 5 U S P - 2 2 5 S P - 3 2 0 200W Single Output with PFC Function s e r i e s s e r i e s s e r i e s s e r i e s Mechanical Specification...
- Page 99 L R S - 1 5 0 s e r i e s 150W Single Output Switching Power Supply Bauar t gepruft Sicherheit egel www. tuv.com ID 2000000000 ■ Features ■ Applications AC input range selectable by switch Industrial automation machinery Withstand 300VAC surge input for 5 second Industrial control system No load power consumption<0.5W...
- Page 100 L R S - 1 5 0 s e r i e s 150W Single Output Switching Power Supply SPECIFICATION MODEL LRS-150-12 LRS-150-15 LRS-150-24 LRS-150-36 LRS-150-48 DC VOLTAGE RATED CURRENT 12.5A 4.3A 3.3A 6.5A CURRENT RANGE 0 ~ 12.5A 0 ~ 4.3A 0 ~ 10A 0 ~ 6.5A 0 ~ 3.3A...
- Page 101 L R S - 1 5 0 s e r i e s 150W Single Output Switching Power Supply Block Diagram fosc : 65KHz RECTIFIERS RECTIFIERS POWER & & FILTER SWITCHING FILTER FILTER DETECTION O.L.P. CIRCUIT CONTROL O.T.P. O.V.P. Derating Curve Static Characteristics 230VAC 170 ~ 264VAC...
- Page 102 L R S - 1 5 0 s e r i e s 150W Single Output Switching Power Supply Mechanical Specification Case No.241A Unit:mm 152.5 SVR1 Terminal Pin No. Assignment Pin No. Assignment Pin No. Assignment AC/L DC OUTPUT -V AC/N DC OUTPUT +V Installation Manual...
- Page 103 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Mean Well LRS-150-48 LRS-150-24 LRS-150-36 LRS-150-15 LRS-150-12...
- Page 104 Date : PRODUCTION 11/02/18 MANUAL Rev 00 9239.0306 INTELLI SUPPLY BO EXT 230V 9239.0316 INTELLI SUPPLY BO EXT 115V ASSEMBLY 8a+b+c DESCRIPTION ART. NR. QUANTITY print voeding intellimains ext 9002.2562 print voeding intellicontroller 9002.2571 print voeding grijper xl 9002.2371 transfo RK 230VA 2x24V 2x115V 2410.0231 kabel trafo config 230V 9015.0963...
- Page 105 Commercial Lite LV340C (EU/CIS) Essential Commercial TV with Multiple Use LG Commercial Lite TVs are designed specifically for hospitality and business environments. With the use of simple user- friendly interfaces and superb images and video, the LV340C facilitates communications between businesses and their target audiences.
- Page 106 Essential Commercial TV with Multiple Use LV340C EU/CIS Dimensions Dimensions Specifications (Unit : mm / kg) 32" Type Direct LED Edge LED 74.6 DISPLAy Resolution 1,920 x 1,080 (FHD) 739 x 472 x 168 / Brightness 240cd/m 400cd/m Analog PAL / SECAM BROADCASTINg SySTEM Digital...
- Page 107 missing.txt datasheet missing Pagina 1...
- Page 108 ¡ ¢ ¢ £ ¤ ¤ ¥ ¦ § £ ¨ © EN60 320-1 Standard Sheet C14 Class I Rewirable Cold Condition (Fused) Snap Fit to Panel Fused Inlet " & " " " " PF0011/10/28 PC Snap Fit to Panel Fused Inlet "...
- Page 109 : Big One X-treme 1 MANUAL 2 CABINETS 3 PRIMARY CIRCUITS 4 ELECTRONICS 5 FUNCTIONALITY 6 WIRING...
- Page 110 Datum : 08/02/18 Big One x-treme 1 wire schematic Revisie : 01 BIG ONE X-TREME : ELECTRONICS LAYOUT 2670.0022 head light spotlight 9040.7072 spotlight RGB Ctrl / 9040.7073 1459.0006 +9002.2521 SMPS 24V 150W 9092.0150 gantry HP X-treme Camera 9235.5015 2020.0020 RGBset 4831.0097 / -98...
- Page 111 Big One X-treme supply power W/m of pcs type of lights flex strip cool white 14,4 profiel daylight 14,4 flex strip RGB 14,4 led spots ww with cc controller RGB led pcb 1,8 max location type length (pcs) factor SMPS...
- Page 112 : Big One X-treme 1 MANUAL 2 CABINETS 3 PRIMARY CIRCUITS 4 ELECTRONICS 5 FUNCTIONALITY 6 WIRING...
- Page 113 refer to machine manual...
- Page 114 : Big One X-treme 1 MANUAL 2 CABINETS 3 PRIMARY CIRCUITS 4 ELECTRONICS 5 FUNCTIONALITY 6 WIRING...
- Page 115 Rev: Comment: Comment: RGB Corners + Monitor P.8 ELAUT NV Passtraat 223 9100 Sint-Niklaas Title: Big One X-treme Title: Big One X-treme All views on connections are from wireside ! Subtitle: General Overview Subtitle: General Overview Rev: 00.0 Rev: 00.0...
- Page 116 Bill1 Purple Bill1 Bill2 Whi/Gre INH2 connections are INH1 Grey Error Bill3 Black Title: Big One X-treme Title: Big One X-treme INH2 Lock- Wh/Bl from wireside ! Blue Lock+ Subtitle: Playfield Controller Subtitle: Playfield Controller Rev: 00.0 Rev: 00.0 Wh/Red...
- Page 117 Black DC jack 2.1mm 9036.9100 3500.9130 9015.2051 To RCA connection Motor Monitor ELAUT NV ELAUT NV FWD/BWD Passtraat 223 Passtraat 223 9100 Sint-Niklaas 9100 Sint-Niklaas Title: Big One Xtreme Title: Big One Xtreme All views on connections are from wireside !
- Page 118 Green ELAUT NV ELAUT NV Passtraat 223 Passtraat 223 9100 Sint-Niklaas 9100 Sint-Niklaas Title: Big One X-treme Title: Big One X-treme All views on connections are from wireside ! Subtitle: Price Box Subtitle: Price Box Rev: 00.0 Rev: 00.0 Signed: DH...
- Page 119 Black Black BROW N BROW N Claw CMD Claw CMD 9002.2551 Conn Mini fit 6p plug Conn Mini fit 6p plug 9015.0993 ELAUT NV ELAUT NV 9239.03X6 Black Black GND 15 GND 15 Passtraat 223 Passtraat 223 To playfield Controller...
- Page 120 To ‘Display’ Intelli Controller 9015.2581 (9236.0320) ELAUT NV Passtraat 223 9100 Sint-Niklaas Title: Big One X-treme Title: Big One X-treme All views on connections are from wireside ! Subtitle: Basic I/O Subtitle: Basic I/O Rev: 00.0 Rev: 00.0 Signed: DH...
- Page 121 All views on connections are from wireside ! Green From Domino Conn microfit 6p plug Blue Green Yellow Main supply 9015.1153 ELAUT NV ELAUT NV Blue Yellow Passtraat 223 Passtraat 223 Conn microfit 6p rec 9100 Sint-Niklaas 9100 Sint-Niklaas Conn microfit 6p plug...
- Page 122 Yellow +12V Black From PSU Controls casing From Gantry 9015.2051 To Monitor From Mains entrance ELAUT NV ELAUT NV Passtraat 223 Passtraat 223 Monitor 43" 9100 Sint-Niklaas 9100 Sint-Niklaas 1575.1242 Title: Big One Title: Big One All views on connections are from wireside !
- Page 123 : Big One X-treme 1 MANUAL 2 CABINETS 3 PRIMARY CIRCUITS 4 ELECTRONICS 5 FUNCTIONALITY 6 WIRING ADDENDUM : PARTS DATASHEETS...
- Page 124 9990.9701 X-treme Big One Artikel Omschrijving approval * indicated for reference; approval defined per UNITS components 9980.9701 Basiskast X-treme Big One 9235.5015 Wagen hp X-treme 9015.1045 Kabel supply camera 12v 2020.0020 Camera X-treme camtvi8n1 9015.0939 Kabel wagen big one 9002.2331 Print wagenstop Big One mk2 9002.2332 Print grijperstop Big One mk2...
- Page 125 2420.0001 Motor 48v prijsbak Big One no marking 9015.0946 Kabel prijsbak big one 1459.0006 Rgb remote led controller no marking 9002.2621 Print rgb domino 9092.0150 voeding 150w geschakeld 24v CE, cURus, TUV, CB 9015.1159 Kabel itx rgb conn. led 180 mm 2070.1024 Luidspreker 4r 60w 102mm 9090.0949...
- Page 126 1911.0052 Relais 12v dc spdt 5a az940 UR, CSA, VDE, TUV,… 1929.1166 Switch rocker single onoff pcb UL94V-0 1950.2160 Printpl intelli programmer UL94V-0 1950.2220 Printpl intellicontroller UL94V-0 1950.2230 Printpl intellisound rev03 UL94V-0 1950.2250 Printpl intelli link driver UL94V-0 1950.2330 Printpl grijper/wagen stop big UL94V-0 1950.2340 Printpl spoel grijper xl rev1b...
- Page 127 Refer to digital version for part datasheets.
