- Page 1 Manual English Intelligrab 02xx revxx The Big One 03xx revxx 22/03/2018 ELAUT nv/sa Passtraat 223 B-9100 Sint-Niklaas Belgium Tel: +32 3 780 94 80 Fax: +32 3 778 05 61 Website: www.elaut.com E- mail: support@elaut.be...
-
Page 3: Table Of Contents
Table of contents Introduction ..................... 5 Principal of operating ................5 The course of the game ................5 Result-oriented operating ................ 6 Evaluation of the payout....................6 Grabsuccess ........................6 Cashboxes ........................6 Accounts ......................... 6 Mechanical counters ....................... 6 Maintenance ................... -
Page 5: Introduction
Introduction Congratulations with the purchase of your crane with Intelli Technology. We advise you to read this manual completely so you learn the possibilities and the use of this system. Different aspects of the game can be set (more about this further in this manual). Through the LCD display and a few pushbuttons, a lot of information about the functioning of the system can be displayed. -
Page 6: Result-Oriented Operating
Result-oriented operating We assume that your machine is completely set to your wishes. If this is not the case, go to “settings”(further in this manual). Evaluation of the payout In the menu “pay-out information (displays automatic by staring up the machine) you can see the results of your crane during a short time and compare it with the expected result “current percentage xx%”... -
Page 7: Maintenance
Maintenance A key-locked door gives access to the maintenance area. Hand this key to your operator and/or maintenance personnel for filling up the machine with prizes or for cleaning purposes. The machine can stay powered for these operations. However, beware of the (possibly) moving claw. - Page 8 Working with the Intelli Programmer • The arrows “up” and “down” (1) are used to pass through the different menus and settings. • The “Select” button (2) is used to open or close the different menus or to do specific actions, like clear counters.
-
Page 9: Overview Menu
The crane is controlled electronically, but that doesn’t means that it adjusts automatically. The most imported link is, and stays, the manager. You can adjust the crane by settings desired by the managers and players. The programmer (see picture on last page) makes it easy to adjust. You walk through the different menus that are mutually linked, and adjust them by a simple push on a button. -
Page 10: Cashboxes
Cashboxes CASHBOXES coins in: amount of received coins. coin in 185.0 bill/tk in: amount of received bills. bill/tk in 100.0 #wins: amount of won prizes. #wins #dispenser: amount of won consolation prizes. #dispenser ex: ticket dispenser, chewing gum dispenser, … S clear cashboxes The “cashboxes”... -
Page 11: Payout Information
Payout information PAYOUT INFORMATION current perc: the percentage that is already paid out. i current perc. 45% “Money in” and “prize out” automatically calculate this i set perc. percentage. This is information, so not adjustable. est.price out 10.0 set perc: the desired pay out percentage. This is not products cost directly settable, but “est. -
Page 12: Bill/Token Values
Bill / token values BILL/TOKEN VALUES bill 1 value: value of a bill bill 1 value bill 1 indic: the indicated value of a bill bill 1 indic bill 2 value: value of bill/ coin/ token bill 2 value 10.0 bill 2 indic: the indicated value of a bill/ coin/ token bill 2 indic 10.0... -
Page 13: Motor Speeds
Motor speeds MOTOR SPEEDS The speed of each motor can be adjusted separately. forward motor 100% sideward motor up/down Dispenser settings DISPENCER SETTINGS pay award: the credit of tickets/chewing gums will be S pay award memorized if the dispenser is empty. By pressing “S” they S feed will be paid. -
Page 14: Diagnostics
Diagnostics DIAGNOSTICS last money: indicates the channel where the last money i last money was inserted i meter error meter error: number of times that the counters failed i coin/bill during counting i dispenser error 0 coin/bill: number of problems with the coin- or bill i pay out errors acceptor i data errors... -
Page 15: Selftest
Selftest SELFTEST claw type: the claw type will be measured by turning on T clawtype each claw type has a specific number: T cord replacement 0 = error T mech. cycle 2 = small T lamptest 3 = medium T dispenser 4 = large i coin-in 00000000... -
Page 16: Adjusting
Adjusting Remark: it is not possible to work with merchandise that contains magnetic materials because of the permanent magnetism of the axe. This will stick on the axe! After you choose the correct claw for the merchandise, you can do as follows: Go to the menu “CLAW SETTINGS”. -
Page 17: Warnings And Errors
This warning appears when the door is open. Remark: This is an option and is not installed on a standard machine. This is used for the stock management through Intelli Link. For more information, please contact Elaut or a registered dealer. ! WARNING: Display code: 4... - Page 18 ! WARNING: Display code: 9 it took to long many It takes to long before a win is registered. Check the games to win (check settings in the menu “Payout information” and also check settings and the working of the prize detector. detector) ! WARNING : grabber Display code:10...
- Page 19 ! ERROR: payout to Display code:33 high, check (claw) The payout percentage is too high for a longer period. It settings and restart can’t be adjusted. Check the claw settings as well as the regulator first regulator. The regulator has to be recalibrated before continuing the game.
-
Page 20: Extra Settings And Errors (The Big One)
Extra settings and errors (The Big One) There are a few extra setting in the program of The Big One: Game settings GAME SETTINGS win door mode: 3 possible options: game time • 0 = manual: the player can remove the prize all by 4 directions himself. -
Page 21: Error
Error ! ERROR; wind door Display code: 43 out of order.press S. There is a problem with the win door. It can be corrected in (go to SELFTEST to the SELFTEST-menu. reposition door)
